ETX Lithium
Battery User' s
Manual
Copyright© 2016 EarthX, Inc. All rights reserved. The information contained in this document is the property of EarthX, Inc.
EarthX reserves the right to make changes to its documents or products without notice. It is the responsibility of each user to
ensure that all applications of EarthX's products are as intended and safe based on conditions anticipated or encountered during
use. The EarthX logo is a trademark of EarthX, Inc.
Advertisement
Table of Contents
Related Manuals for EarthX ETX6A
Summary of Contents for EarthX ETX6A
- Page 1 Copyright© 2016 EarthX, Inc. All rights reserved. The information contained in this document is the property of EarthX, Inc. EarthX reserves the right to make changes to its documents or products without notice. It is the responsibility of each user to ensure that all applications of EarthX’s products are as intended and safe based on conditions anticipated or encountered during...
-
Page 2: Table Of Contents
E T X S E R I E S L I T H I U M B A T T E R I E S T able of Contents Overview ................... 1 Technology Inside ................1 Battery Cells ..................1 Battery Management System (BMS) .......... -
Page 3: Overview
B A T T E R I E S Overview EarthX’s ETX Lithium batteries are designed as a maintenance free replacement for the 12 volt lead-acid or lithium batteries. To ensure a smooth replacement process, ETX batteries are similar in dimensions to many OEM motorsport or power sport batteries. The ETX... -
Page 4: Etx - Hundred Series
E T X S E R I E S L I T H I U M B A T T E R I E S level. This ensures that the charge level of all the cells remains equal, even with the high discharge (>... - Page 5 E T X S E R I E S L I T H I U M B A T T E R I E S In the event of a charging system failure where the voltage increases to above 15.2V, the resistance to charging current increases, and above 16V the charging current is completely blocked.
-
Page 6: Specifications
S E R I E S L I T H I U M B A T T E R I E S Specifications Model: ETX6A-discontinued model as of 4-2016 Nominal Voltage 13.2 V Ah (lead-acid equivalent) Ah (1 hour discharge rate) 2.5 (1C rate) - Page 7 E T X S E R I E S L I T H I U M B A T T E R I E S Weight 1.3 lb. (.6Kg) Dimensions ETX12A 4.5in x 2.6in x 3.7in (113mmX66mmX95mm) ETX12B 5.3in x 2.6in x 4.1in (135mmX66mmX105mm) Environmental Rating (resistance to IP 66 (wash down with a high pressure...
- Page 8 E T X S E R I E S L I T H I U M B A T T E R I E S Pulse Crank Amps (PCA) 420A (3 sec @ 25 °C, voltage >9V) Cold Crank Amps (CCA) 270A (modified SAE test, 3 sec@ 0°F, voltage >7.2V) Max Continuous Discharge Amps...
- Page 9 E T X S E R I E S L I T H I U M B A T T E R I E S X86mm X155mm) ETX36E 6.6in x 3.4in x 6.9in (166mm X86mm X175mm) Environmental Rating (resistance to IP 66 (wash down with a high pressure water intrusion) washer)
- Page 10 E T X S E R I E S L I T H I U M B A T T E R I E S Amps Max Charge Amps 60A (from vehicle charging system) Life (Charge cycles) 4000 cycles @ 1C discharge rate, 25°C (20% depth of discharge) 2000 cycles @10C discharge rate, 25°C (80% depth of discharge)
-
Page 11: Discharge Versus Temperature
E T X S E R I E S L I T H I U M B A T T E R I E S Nominal Voltage 13.2 V Ah (1 hour discharge rate) 24.8 (1C rate) Pulse Crank Amps (PCA) 1200A (3 sec @ 25 °C, voltage >9V) Cold Crank Amps (CCA) 600A (modified SAE test, 3 sec@ 0°F,... -
Page 12: Self-Discharge Rates
E T X S E R I E S L I T H I U M B A T T E R I E S Cranking Amps vs Temp Lithium Lead Acid Temp Deg C Self-discharge Rates The self-discharge rate is dependent on temperature. At high temperatures (>25°C), the cell internal resistance decreases so the self-discharge rate increases. -
Page 13: Discharge Curves
E T X S E R I E S L I T H I U M B A T T E R I E S Discharge Curves Voltage is not a good indication of the state-of-charge in lithium batteries. The first graph below shows the state-of-charge versus voltage at a 1C discharge rate for the ETX12 (representative of the ETX series batteries). - Page 14 ETX12 discharge curves at a 1C rate over a wide operating temperature range. Note: there is 20% decrease in Ah and discharge voltage at -30deg C as compared to 25 deg C. All the EarthX ETX series batteries exhibit similar discharge curve profiles. ETX12A/B Discharge Curve (1C Rate)
-
Page 15: Installation
E T X S E R I E S L I T H I U M B A T T E R I E S Installation Battery Installation Lithium Iron Phosphate batteries are very robust, but if mishandled or misused they can rupture and they can burn. -
Page 16: Fault Monitoring Installation (Etx Hundred Series)
E T X S E R I E S L I T H I U M B A T T E R I E S Be careful that the positive battery terminal does not or will not touch any metal parts of the vehicle. - Page 17 E T X S E R I E S L I T H I U M B A T T E R I E S Fault Monitoring Connection to Garmin EFIS The following example details how to connect the fault monitoring output to a remote 12V LED. The positive wire (anode, typically the red wire) of the LED should be connected to the electrical bus (positive), and the negative of the LED (cathode, typically the black wire) should be connected to the fault monitor wire of the battery.
-
Page 18: Charging
Failure to follow these instructions may result in damage to the battery! The ETX Lithium battery is shipped fully charged if ordered directly from EarthX, so try to start the vehicle without charging. If ordering from an authorized dealer, it is recommended you check the voltage first and if it is above 13.3V, continue to install and start vehicle. -
Page 19: Storage
E T X S E R I E S L I T H I U M B A T T E R I E S The ETX Lithium battery is compatible with most “modern” lead-acid battery chargers or 4cell LiFePO4 battery chargers. By “modern” we mean a charger that automatically turns off when the battery is fully charged, a charger with a micro-processor, or a charger with multiple mode charging. -
Page 20: Troubleshooting
E T X S E R I E S L I T H I U M B A T T E R I E S Troubleshooting The ETX Lithium battery is an extremely reliable battery with a longer useful life than comparable lead-acid batteries. - Page 21 E T X S E R I E S L I T H I U M B A T T E R I E S The vehicle electrical system may have a short circuit or current drain: Measure the current out of the battery when the vehicle and all vehicle accessories are shutoff.
-
Page 22: Regulations
E T X S E R I E S L I T H I U M B A T T E R I E S Regulations The ETX Lithium battery was tested to the following safety regulations as outlined in: ...
