AWT MIG-200 Operator's Manual page 16

MIG Mode
Function
Inductance
Preset speed before
arc start
Pre-flow control
Spot Welding Time
Knob[6]: Adjust the wire feed speed / current
Manual MIG: wire feed speed can be adjust from 2.5-15m/min.
Synergic MIG: welding current can be adjust from 30-200A.
MMA: welding current can be adjust from 25-180A.
TIG: welding current can be adjust from 15-200A.
Knob[7]: Adjust the voltage
Manual MIG: welding voltage can be adjust from 10-27.5V
Synergic MIG: welding voltage will be auto fitted after welding
ampere is input, can micro adjust from ±3V (each value=0.1V)
Button [2]+Button [5]=INCH
Only available in MIG mode. Inching can be achieved by Pressing button[2] and [5] at the
same time . Press and hold INCH button, machine goes into quick feed mode for loading wire.
Description
Adjust soft to hard arc sparking.
Slows the wire feed speed to a pre-set speed
prior to arc initiation, improving arc starts.
Control sets time gas flow before welding.
Adjustable only in spot welding mode.
- 14 -
Setting Range
-10% to +10%
0-10 m/min
0 to 2 seconds
0 to 3 seconds
