Everbilt BLH4WHD6 Use And Care Manual

Tools RequiRed

Caulking gun

Installation

1
AsseMBlinG THe
AluMinuM PiPe
□ Press the sides of the aluminum
pipe together and lock them into
place.
4
insTAllinG THe eXHAusT Hood
□ From the outside, pass the pipe through the hole opening
until the vent cap lies flush against the outside wall
surface.

Safety Information

IMPORTANT: Vent the exhaust hood outdoors through a wall or window opening as close as possible to the dryer.

Warranty

WHAT is coVeRed
All merchandise is warranted to be free from defects in workmanship and material for one year from the date of purchase. This includes normal wear and
performance failure on items. The manufacturer will replace or repair at their option.
WHAT is noT coVeRed
This warranty only covers normal wear and performance failure. It does not cover any malfunction, performance failure or defect arising from the misuse,
abuse, neglect or modification of the product. Any damage or malfunction inflicted upon the product by the user or other external sources, or any failure to
comply with the warnings and instructions is not covered.
For further assistance visit www.HomeDepot.com.
Use and Care Guide
Louvered Exhaust Hood
Phillips screw driver
2
ATTAcHinG THe VenT cAP To
THe PiPe
□ Attach the vent cap to the pipe.
Ensure the pipe fits snug inside
the collar. Align the clips on the
collar (A) so they snap into the pipe
slots (B).
HARdWARe RequiRed (noT included)
Screws (4)
3
□ Cut a hole through the wall ¼ in.
NOTICE: Ensure the appropriate tool is used to
cut the hole in the wall according to the type of
wall material.
A B
5
secuRinG THe VenT cAP
□ Secure the vent cap to the wall by screwing it into place
and/or caulking around the reveal.
Item # 592-098/
592-164
Model # BLH4WHD6/
BLH6WHD
Latex caulking
cuTTinG A Hole THRouGH
THe WAll
diameter larger than the pipe. For
example, to accommodate a 4 in.
pipe cut a hole 4 ¼ in. in diameter.
4 ¼ in
4 in
10.8 cm
10.2 cm
HomEDEPoT.Com
