INSTALLATION
RACK MOUNTING
The steps to mount the rack are listed below:
Select a location for the inverter
-
With an IP66 protection rating, the inverter can be installed both outdoors and indoors.
-
When the inverter is running, the temperature of the chassis and heat sink will be higher. Do not install
the inverter in a location that you accidentally touch.
-
Do not install the inverter in a place where are stored a flammable or explosive material.
Installation angle
Please install the inverter vertically. If the inverter cannot be mounted vertically, it may be tilted backward to 15
degrees from vertical.
Vertical
Upside
down
11
Backward
√
Correct installation angle
×
Wrong installation angle
√
Leaning
forward
×
≤ 15°
Document No.: LDV-LT-50/60-F2-01-UM_11.2023
