- Page 1 H E A T I N G W I T H B I O M A S S PLANING FOLDER Pellet boiler www.biotech-heizung.com...
- Page 2 NOTE Optimise PDF view ADOBE ACROBAT READER In order to ensure an optimal display, the following settings can be activated when using Adobe Acrobat Reader:...
-
Page 3: Table Of Contents
3.1 EFFECTIVE HEIGHT .............................. 7 TECHNICAL DATA ..............................8 DIMENSIONS ................................10 TLM-PRO ................................10 5.2 TLM-PRO MBW ............................... 11 5.3 PZ 25 RL ................................12 5.4 PZ 25 RL MBW ..............................13 5.5 PZ 32/35 PRO ..............................14 5.6 PZ 32/35 PRO MBW ............................15 5.7 PZ 45/50/55 RL ..............................16... - Page 4 INHALTSVERZEICHNIS 7.6 DISCHARGE FROM THE BAG SILO ........................ 28 7.6.1 OPERATING PRINCIPLE ........................28 7.6.2 ASSEMBLY .............................. 29 7.6.3 GROUNDING THE BAG SILO ......................29 7.7 DISCHARGE FROM THE UNDERGROUND TANK ..................29 7.7.1 OPERATING PRINCIPLE ........................29 7.7.2 GROUNDING OF THE UNDERGROUND TANK ................29 HYDRAULIC SCHEMES ............................
-
Page 5: General Notes
This is the only way to ensure low-emission, economical and trouble-free operation of your pellet boiler. Non- ATTENTION! observance will result in the loss of the warranty. Biotech The mandatory maintenance of the unit must accepts no liability whatsoever for damage caused by the be carried out at least once a year, at the use of fuel that does not have this certification. -
Page 6: Return Boost Flow
PLANING FOLDER PELLET BOILER • Safety and monitoring devices must not be removed, be insulated with at least 25 mm. If possible, make the flue bypassed or otherwise rendered inoperative. Use a dust connection with 45° bends. A connection with 90° bends can mask during cleaning and ash disposal to avoid health cause flue gas problems. -
Page 7: Effective Height
PLANING FOLDER PELLET BOILER 3.1 EFFECTIVE HEIGHT ATTENTION: If the chimney draught regulator is installed The effective height is the flue length between the flue gas inlet directly in the flue pipe, contrary to the into the flue and the flue mouth.The flue must be adapted to the location suggested below, due to the situation local, legal regulations! Low-emission operation according to the on site, an increased dust load in the boiler... -
Page 8: Technical Data
PLANING FOLDER PELLET BOILER 4. TECHNICAL DATA Individual values are based on the standard type test. These may deviate in practice. Boiler type TLM-Pro TLM-Pro MBW PZ25RL PZ 25 RL MBW PZ 32/35 Pro Boiler class Nominal heat output (kW) - Page 9 PLANING FOLDER PELLET BOILER Individual values are based on the standard type test. These may deviate in practice. Boiler type Boiler type PZ 32/35 Pro MBW PZ 32/35 Pro MBW PZ 45/50/55 RL PZ 45/50/55 RL PZ 65/69/80 RL PZ 65/69/80 RL PZ 90/100 RL PZ 90/100 RL PZ 100/101 RL...
-
Page 10: Dimensions
PLANING FOLDER PELLET BOILER 5. DIMENSIONS 5.1 TLM-PRO 1155 Pellet boiler TLM-Pro Insert dimensions boiler (min.) A: 610 mm B: 1450 mm C: 870 mm Insert dimensions container (min.) A: 620 mm B: 1520 mm C: 670 mm Boiler 220 kg... -
Page 11: Tlm-Pro Mbw
PLANING FOLDER PELLET BOILER 5.2 TLM-PRO MBW 1155 Pellet boiler TLM-Pro MBW Insert dimensions boiler (min.) A: 610 mm B: 1450 mm C: 870 mm Insert dimensions container (min.) A: 620 mm B: 1350 mm C: 670 mm Boiler 220 kg... -
Page 12: Pz 25 Rl
PLANING FOLDER PELLET BOILER 5.3 PZ 25 RL 1305 1084 Pellet boiler PZ 25 RL Insert dimensions boiler (min.) A: 610 mm B: 1400 mm C: 720 mm Insert dimensions container (min.) A: 740 mm B: 1650 mm C: 670 mm Boiler 218 kg Container... -
Page 13: Pz 25 Rl Mbw
PLANING FOLDER PELLET BOILER 5.4 PZ 25 RL MBW 1305 1084 Pellet boiler PZ 25 RL MBW Insert dimensions boiler (min.) A: 610 mm B: 1400 mm C: 720 mm Insert dimensions container (min.) A: 740 mm B: 1500 mm C: 670 mm Boiler 218 kg... -
Page 14: Pz 32/35 Pro
PLANING FOLDER PELLET BOILER 5.5 PZ 32/35 PRO 1305 1158 Pellet boiler PZ 32/35 Pro Insert dimensions boiler (min.) A: 610 mm B: 1620 mm C: 920 mm Insert dimensions container (min.) A: 740 mm B: 1780 mm C: 670 mm Boiler 280 kg Container... -
Page 15: Pz 32/35 Pro Mbw
PLANING FOLDER PELLET BOILER 5.6 PZ 32/35 PRO MBW 1305 1158 Pellet boiler PZ 32/35 Pro MBW Insert dimensions boiler (min.) A: 610 mm B: 1620 mm C: 920 mm Insert dimensions container (min.) A: 740 mm B: 1630 mm C: 670 mm Boiler 280 kg... -
Page 16: Pz 45/50/55 Rl
PLANING FOLDER PELLET BOILER 5.7 PZ 45/50/55 RL 1505 7070 Pellet boiler PZ 45/50/55 RL Insert dimensions boiler (min.) A: 800 mm B: 1800 mm C: 800 mm Insert dimensions container (min.) A: 840 mm B: 1950 mm C: 820 mm Boiler 324 kg Container... -
Page 17: Pz 65/69 Rl
PLANING FOLDER PELLET BOILER 5.8 PZ 65/69 RL 1339 1221 1420 Pellet boiler PZ 65/69 RL Insert dimensions boiler (min.) A : 850 mm ¹ B : 1805 mm ² C : 1280 mm Insert dimensions container (min.) A : 740 mm B : 1800 mm ²... -
Page 18: Pz 80 Rl
PLANING FOLDER PELLET BOILER 5.9 PZ 80 RL 1339 1420 1221 Pellet boiler PZ 80 RL Insert dimensions boiler (min.) A: 850 mm ¹ B: 1805 mm ² C: 1280 mm Insert dimensions container (min.) A: 740 mm B: 1800 mm ² C: 1260 mm 1) When dismantling the console / motor Ash removal 2) exclusive adjustable feet (50 to 80 mm) -
Page 19: Pz 90/100 Rl
PLANING FOLDER PELLET BOILER 5.10 PZ 90/100 RL 1339 1221 1420 Pellet boiler PZ 90/100 RL Insert dimensions boiler (min.) A: 850 mm ¹ B: 1992 mm ² C: 1280 mm Insert dimensions container (min.) A: 740 mm B: 2030 mm ² C: 1260 mm 1) When dismantling the console / motor Ash removal 2) exclusive adjustable feet (50 to 80 mm) -
Page 20: Pellet Storage Room
PLANING FOLDER PELLET BOILER 6. PELLET STORAGE ROOM The pellets are delivered by a silo truck and blown into the SICHERHEITSHINWEISE / SAFETY INSTRUCTIONS SICHERHEITSHINWEISE / SAFETY INSTRUCTIONS storage room. The silo truck usually has a pump hose with für Pelletlagerräume, begehbare luftundurchlässige Fertiglager sowie Aufstellräume von luftdurchlässigen für den Aufstellraum von luftdurchlässigen Fertiglagern für Pellets ≤... -
Page 21: Size Of The Pellet Storage Room
PLANING FOLDER PELLET BOILER 6.2 SIZE OF THE PELLET STORAGE ROOM The size of the required storage space depends on the min. 500 building‘s heating load, but should be chosen large enough to store 1.5 times the annual fuel quantity. Filling nozzle If the unusable room volume is taken into account, the following rule of thumb results:... -
Page 22: Maintenance
PLANING FOLDER PELLET BOILER 6.4 MAINTENANCE The storage room must be periodically cleaned of fine particle warehouse, it should be well ventilated for at least 15 minutes. It deposits. Appropriate accessibility must therefore be provided. is very important to enter the pellet store only in the company of a second person, who should be outside the danger zone BEARING VENTILATION for safety reasons. -
Page 23: Notes On The Design Of The Filling System
PLANING FOLDER PELLET BOILER FILLING SYSTEM WITHOUT LIGHT SHAFT WITH LIGHT SHAFT Two „filling nozzles“ are required to fill a pellet store. An extraction fan is connected Closing lid Closing lid to one filling nozzle when the fuel is delivered and the pellets are blown in at the other. -
Page 24: Installations In The Pellet Store
7.1 ADJUSTATION VARIATIONS according to country-specific regulations. Other discharge systems can also be used upon request or after consultation and approval by Biotech Energietechnik GmbH. The use of non-approved discharge systems invalidates the guarantee / warranty. ELECTRICAL INSTALLATION IN THE PELLET STORAGE There must be no electrical installations such as switches, lights, junction boxes, etc. -
Page 25: Suction Point
PLANING FOLDER PELLET BOILER 7.3 SUCTION POINT Suction points fixed to the floor can be used! NOTE: The installation of an inclined floor is strongly recommended. Without an inclined floor, complete storage space discharge is not possible. With increasing operating time, the slope angle becomes steeper and steeper (increase in dust content). -
Page 26: Screw Discharge
PLANING FOLDER PELLET BOILER 7.4 SCREW DISCHARGE 7.4.1 OPERATING PRINCIPLE ATTENTION! Distance impact mat wall min. 300 mm Storage room Heating room The pellets are conveyed by the auger from the storage room to the suction point and sucked off from there. -
Page 27: Mole System
PLANING FOLDER PELLET BOILER Over the entire length Wall recess (surface smooth) 0,5-1 m 45° 45° 300 mm 300 mm Fix the auger to the floor. Mount the slide slope on the left Fix the auger to the floor on a wooden board (300 mm wide, and right with a distance of 300 mm from each other. -
Page 28: Assembly
PLANING FOLDER PELLET BOILER 7.5.2 ASSEMBLY PELLET MOLE PELLET MOLE E3 The Sonnen-Pellet Mole ® Classic is the removal system for The Pellet Mole E3 can be placed in storage rooms of almost all common storage options. Removal from the top ensures any shape thanks to the sensor technology. -
Page 29: Assembly
ATTENTION: Max. Delivery hose length for Biotech pellet sto- rage system PLS 10 m. Complete emptying of the PLS cannot be guaranteed, as this depends heavily on the pellet quality (dust content). -
Page 30: Hydraulic Schemes
8. HYDRAULIQ SCHEMES This scheme is a recommendation of the company NOTE: Biotech. Please note that this scheme must be adapted We reserve the right to make technical changes! It is to the local conditions. For this reason, we cannot essential to ensure that the return temperature of the accept any liability for the function of the system. -
Page 31: Addition For Annexe
PLANING FOLDER PELLET BOILER IMPORTANT NOTE: Information without claim to completeness, no assumption of liability. Subject to typesetting and printing errors! Shut-off devices, vents and safety measures are not shown in this schematic diagram. These must be installed specifically for the system in accordance with standards and regulations! Chimney draught regulator with EX damper in the flue! 8.1 ADDITION FOR ANNEXE Boiler... -
Page 32: Declaration Of Conformity
Maschinen/Produkte in serienmäßiger Ausführung Top Light, Top Light M, Top Light M (MBW), TLM-Pro, TLM-Pro (MBW), PZ8RL, PZ25RL, PZ25RL (MBW), PZ32RL, PZ32RL (MBW), PZ35RL, PZ35RL (MBW), PZ45RL, PZ50RL, PZ55RL, PZ65RL, PZ69RL, PZ80RL, PZ90RL, PZ100RL, PZ101RL... -
Page 33: Notes
NOTES... - Page 34 H E A T I N G W I T H B I O M A S S Natural & sustainable heating with pellet, lump and wood chip heating systems from Biotech. Your heating specialist will be happy to advise you: Biotech Energietechnik GmbH Plainfelder Straße 3...
