ALKOTA 4405G Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PERFORMANCE
DISCHARGE VOLUME........................................4.0 GPM / 15.1 LPM
PUMP HEAD PRESSURE....................................4000 PSI / 276 BAR
TEMPERATURE RISE............105°F @ 4.0 GPM / 41°C @ 15.1 LPM
COMBUSTION SMOKE/BACHARACH SCALE....#1 OR #2 SMOKE
CARBON MONOXIDE ALLOWED............................................ 0.01%
DRAFT/STACK INSTALLATION............. 0.2" - 0.04" WC READING
HEAT INPUT..............................345,800 BTU/HR / 87,141 KCAL/HR
GENERAL
MINIMUM INLET WATER PRESSURE..................40 PSI / 0.68 BAR
STACK SIZE.....................................................8" DIA / 203.2 MM DIA
WEIGHT (DRY) .......................................................340 LBS / 154 KG
HOSE, PUMP TO UNLOADER........................................K02-3228A2
HOSE, UNLOADER TO COIL..........................................K02-3238A2
SPRAY TIP...........................................(#5-15DEG) P/N J00-00040-2
HOSE, DISCHARGE..............................3/8" X 50' P/N K02-03150E1
WAND & TRIGGER GUN......................................... P/N J06-00158-B
BELT - ENGINE TO PUMP......................................... P/N R02-00246
COIL SIZE..............................................1/2"ID X 158' SCHEDULE 80
REPLACEMENT COIL ........................................... P/N 4305E-00206
COIL BACK PRESSURE (NEW)
.....................5 PSI @ 4.0 GPM / 0.34 BAR @ 15.1 LPM
COIL BACK PRESSURE REQUIRING DESCALING
........................... 50 PSI @ 4.0 GPM / 3.40 @ 15.1 LPM
PUMP & UNLOADER
PUMP............................................................................P/N N09-00053
PUMP PULLEY....................................................................R03-00794
PUMP PULLEY BUSHING..................................................R04-00001
UNLOADER..................................................................P/N C07-03800
ALKOTA MODEL 4405G
SPECIFICATIONS
PUMP ENGINE
ENGINE HORSEPOWER...........................................20 HP / 14.9 KW
ENGINE MAKE.........................................................................HONDA
ENGINE CHARGE RATE.........................................................20 AMP
ENGINE PART NUMBER....................................................F05-00402
ENGINE PULLEY................................................................R03-00744
ENGINE OIL FILTER.............................................. P/N F05-00467-01
ENGINE AIR FILTER...............................................P/N F05-00467-05
ENGINE AIR PRE-CLEANER.................................P/N F05-00467-04
ENGINE MUFFLER.................................................P/N F05-00465-01
ELECTRICAL
MACHINE VOLTAGE............12 VDC / 115V 60HZ 1PH CONTROLS
PRESSURE SWITCH ...................................................P/N F04-00790
BATTERY .......................................................................... GROUP 24
BATTERY CABLE - STARTER................................P/N F05-00248-1
BATTERY CABLE - GROUND.................................P/N F05-00238-1
BURNER
BURNER PART NUMBER............................................... V00-173140
BURNER TYPE........................................... PRESSURE ATOMIZING
FUEL TYPE.......................................KEROSENE, #1 OR #2 DIESEL
FUEL PRESSURE......................................................120 PSI / 8 BAR
FUEL NOZZLE........................(2.25 80 DEGREE B) P/N V2.25 80DB
FUEL CONSUMPTION..................................2.47 GPHR / 9.34 LPHR
FUEL PUMP......................................(DAN FOSS) P/N V-100714-001
MOTOR SPEED....................................................................3450 RPM
MOTOR VOLTAGE...................................................................12V DC
MOTOR PART NUMBER...............................................V-101126-002
2
07-02-04 Z08-04649
