Setcom KA-24IM Installation page 3

The Kx-24IM is comprised of these parts:
12-2053 x4
12-2053 x4
23-5042 X2
16-0007
16-0007
25-1183
25-1183 HDWR 71 X3
14-5028
12-0050
12-0060 X2 12-0060 X2
HDWR 71 X3
23-1050 (KA) -or- 23-1052 (KE)
23-1050 (KA) -or- 23-1051 (KE)
Refer to the User Manual for your Helmet.
Remove both cheek pads and any ear pads
Using two 1/4 inch P-Clamps and two SS-6-32 Screws.
Position the clamps onto the Boom Mic so that once
installed the side of the element that says "TALK" is
positioned within 1/4 inch of the Lips.
Page 3 of 4
Installing your Setcom Helmet Kit you will need:
23-5042 X2
12-0050
14-5028
-Large spring loaded clamp or a means to weigh down the
25-1184
installation during the (minimum of 24hr) bonding process
25-1184
-50/50 Isopropyl Alcohol (Minimum)
-A #1 Phillips type screwdriver
-A couple of lint free wipes.
Route the modular speaker cable behind the center
pad or bonnet. The long tangent
goes to the right hand
speaker.
RH Speaker
Connector
Viewing the
"TALK" side
Install a 3/16inch P-Clamp
onto the 25-1184 cable.
The P-Clamp is positioned with
one side up against the
compression ring
Verify that you have the correct model of boom mic for
your application. View The "TALK" side of the element:
736
756-22
KA is for SMA/SWA lapel Mic and
squares of self adhesive dual
The dual tangent
end goes to the
left side of
helmet
Snug all Hardware
Mounting Plate is ABS
Machine Screws are SS
DO NOT OVER TIGHTEN
KE is for SME/SWE lapel Mic
63/73 Series Cable Kits
Install Speakers. 3/4 inch
lock are provided for this
purpose.
Viewing the
"TALK" side
Fasten the 3/16 inch P-Clamp to the
mounting plate using a SS-6-32
Screw.
Connect the mic to the Red/Black
pair of the cable
DWG #19-6003 REV B
