To Pair a SpeakerMic and PTT Transmitter:
• With the SpeakerMic attached to the portable radio, hold down the PTT button on the SpeakerMic
and turn on the radio, the Status LED will slowly flash RED twice, then it will begin fast GREEN
flashing.
• Release the PTT button, unit is now in Pairing Mode.
• Turn on the power to the PTT Transmitter, the Status LED will slowly flash RED once, then it must
enter Search Mode or Sleep Mode, It must not be in Linked Mode.
• Tap the PTT button on the PTT Transmitter 3 times rapidly "triple-tap", the PTT Transmitter will
enter Pairing Mode.
Once the SpeakerMic and PTT Transmitter are placed into Pairing Mode, they will establish a
"Link" within a few seconds. Once this happens, the Status LED on both units will briefly flash
GREEN every 2 seconds to indicate the units are Linked. Wireless PTT function from the
Transmitter will now operate. A SpeakerMic and PTT Transmitter that have been Linked will retain
that Link information when powered off. When powered on again, they will re-establish the Link
within a few seconds.
Only one SpeakerMic can be paired to one PTT Transmitter at any time, there cannot be multiple
pairings.
Pair only one SpeakerMic and PTT Transmitter at a time.
Simply follow the procedures above if for any reason it is necessary to pair a SpeakerMic or PTT
Transmitter to a different unit than the one it is currently paired with.
RED flashes
Fast GREEN flashing
Slow GREEN flashing
every 2 seconds
Fast ORANGE flashing
LED turns off after
power up RED flash(s)
Steady RED
RG10001
Rev A
® ®
Portable Only Wireless Reference Guide
Status LED Chart
LED Indications
Technical Issues, Questions? Call 650-965-8020
Status
Seen during power on, 2 flashes on the
SpeakerMic, 1 flash on the PTT Transmitter.
Indicates that a SpeakerMic or PTT Transmitter
is in Pairing Mode and is seeking another unit
that is also in Pairing Mode, to establish a Link.
Indicates that a unit is in Linked Mode.
Indicates that a unit is in Search Mode and
searching for its previously Linked "partner".
Indicates the unit is in Sleep Mode and is not
Linked to another unit.
Indicates an Error, see troubleshooting tips p9.
