- Page 1 Frontload Washer SC70 Translation of the original instructions. Keep These Instructions for Future Reference. D2581EN 09/2021 738300...
-
Page 2: Table Of Contents
....................................................Service ............................. Before calling a service technician ................... Technical information ......................Technical information ........................ Program chart ......................... SC70 ............................Adjustment of the displayed washing time ................Removal ........................... Disposal / recycling of packaging ..................Quick guide ........................................................ -
Page 3: Introduction
Introduction Dear Customer, we thank you for purchasing this quality product. We hope it meets all your expectations. Scandinavian design combines pure lines, everyday functionality, and high quality. These are the key characteristics of all our products, and the reason why they are highly appreciated across the globe. -
Page 4: Safety Precautions
Safety precautions General Please read the instruction manual and save it for future reference. • Please do not use the washing machine if you have not read and understood these instructions or use first. • Failure to observe the instructions for use or inappropriate use of the washing machine may result in damage to the laundry or the appliance, or injury to the user. - Page 5 • To connect the washing machine to water supply, make sure to use the supplied water supply hose and gaskets. Water pressure has to be between 0.1 and 1 MPa (approximately 1 10 kp/cm , 1-10 bar, 10 100 N/cm •...
- Page 6 • Do not use colourants (dyes) or bleaching substances (substances for discolouration or removal of colourants) as they contain sulphuric compounds that could cause corrosion. • Excessive use of products containing chlorine compounds increases the risk of premature failure of appliance components.
- Page 7 • staff kitchen areas in shops, offices and other working environments; • farm houses; • by clients in hotels, motels and other residential type environments; • bed and breakfast type environments; • areas for communal use in blocks of flats or in launderettes. For appliances without plug, disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
- Page 8 • The washing machine is made in compliance with all relevant safety standards. This washing machine may be used by children aged 8 years and above and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, but only if they are supervised during the use of the appliance, if they have been provided relevant instructions regarding safe use of the washing machine, and if they understand the hazards of inappropriate...
- Page 9 • If the washing machine is to be transported, transport protection has to be re-installed before transport (see chapter "BEFORE USING THE APPLIANCE FOR THE FIRST TIME"). SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
-
Page 10: Washing Machine Description
Washing machine description 1. Main switch (ON/OFF) 2. Program selector knob 3. Display 4. Program selector buttons 5. Button (start/pause) 6. Dispenser tray 7. QR and AUID code (on the inside of the washing machine door) 8. Rating plate with information about the washing machine (on the inside of the wash- ing machine door) 9. -
Page 11: Dispenser Tray
Dispenser tray Prewash compartment Compartment for main wash liquid de- tergent. Use the foldable barrier (3). Compartment for main wash powder detergent. Do not use the foldable barrier (3). Softener / conditioner compartment Tab for detergent compartment remov-... -
Page 12: Before Using For The First Time
Before using for the first time Packaging Remove all packaging. Please sort the materials in compliance with local recommendations (see chapter "DISPOSAL"). Transport protection Before using the appliance, remove the three transport bolts and plastic plugs which protect the appliance during transport. Release and remove the bolts as shown in the figures. - Page 13 Cleaning Disconnect the washing machine from the power mains and open the door. Clean the washing machine drum with a damp cloth and a mild detergent. In the case of a 3 phase connection of the appliance, switch off the main socket switch. Connect the washing machine to the power mains and run the dedicated drum cleaning program.
-
Page 14: Installation And Connection
Installation and connection Positioning the washing machine The washing machine can be installed as a built-in (integrated) or a free-standing unit. Place the machine on a level surface so that the power outlet on the wall is accessible. INFORMATION! Before connecting the washing machine to the power mains, wait for at least 2 hours until it reaches room temperature. - Page 15 Washing machine installation clearances Opening the washing machine door (top view)
- Page 16 Stacking a dryer on top of a washing machine To stack a dryer on top of a washing machine, use the extra vacuum feet and the tipping guard (A+B), supplied in the cardboard box in the dryer drum. Adjusting the feet Place the washing machine so that it is stable.
- Page 17 Connection to water supply INFORMATION! The machine has to be connected to water supply by an adequately trained person. Use the water supply hose to connect the appliance. Water pressure has to be between 0.1 and 1 MPa (approximately 1 10 kp/cm , 1-10 bar, 10 100 N/cm If the hoses are newly installed, we recommend rinsing them to remove any impurities.
- Page 18 Installing the drain hose Water supply hose is supplied with the appliance. This is attached to the machine’s outlet and routed to a floor drain or drainage pipe. INFORMATION! The height of the mouth of the outlet hose must be lower than the lowest part of the outlet valve.
- Page 19 Connecting to the power mains ELECTRIC SHOCK! After installation, the washing machine should stand still for two hours before it is connected to the power mains. Connect the appliance to an earthed power outlet. After installation, the wall outlet should be freely accessible.
-
Page 20: Tips Before Washing
Tips before washing This chapter includes several tips on how to prepare the laundry for washing. Laundry sorting Sort the laundry according to: • how soiled it is, • colour, • material. Clothing 1. Close the zips and hook-and-loop fasteners so that they do not damage the fabric. 2. - Page 21 Table continued from last page Perchloroethylene R11, R113, petroleum Dry cleaning in kerosene, pure alcohol, and R113 Dry cleaning not allowed Ironing Ironing with a hot iron with a maximum temperature of 200 °C Ironing with a hot iron with a maximum temperature of 150°C Ironing with a warm iron with a maximum temperature of 110°C Ironing not allowed Natural drying...
- Page 22 Reducing allergic reactions The options include washing with the Allergy Program Cotton and Allergy Program Synthetics. These programs can be used for people with sensitive skin, such as those suffering from allergies, or small children. Saving time and energy Save time and energy by using the Quick program Economy and efficiency You can save a lot of energy by not using the programs operating at higher temperatures.
-
Page 23: Washing Process Step By Step (1-8)
Washing process step by step (1-8) STEP 1: Sort the laundry See chapter "TIPS BEFORE WASHING". INFORMATION! Use a washing net for underwire bras. Empty the pockets. Coins, nails etc. could damage the machine and the fabric. STEP 2: Turn on the main switch. Turning on Press the on/off button. - Page 24 STEP 4: Add the detergent and the conditioner. Recommended amount of detergent is usually specified on the detergent packaging. When washing a smaller amount of laundry, the amount of detergent used can be decreased. Observe manufacturers' recommendations regarding the type of detergent suitable for certain temperatures, load size, and water hardness.
- Page 25 Choose the program depending on the type of laundry and how heavily soiled it is (see chapter "TIPS BEFORE WASHING"). Estimated program duration will appear on the display. Choose between the following programs: (owner/distributor can change parameters and rename the program) Programe (factory default Description program)
- Page 26 Table continued from last page Programe (factory default Description program) MOP 60°C A program specially developed for cleaning mops. MOP 90°C A program specially developed for cleaning mops. MICROFIBRE 40°C A program specially developed for cleaning microfibre fabrics. MICROFIBRE 60°C A program specially developed for cleaning microfibre fabrics.
- Page 27 STEP 6: Choosing the program settings Using the program settings, the washing programs can be further adjusted to your wishes. See chapter: SETTINGS. (only appliance owner/distributor may change the settings) Some program settings may not be available for your selected program. Start delay Choose the delayed start when you wish the washing program to start after a certain period of time (from 1 h to 100 h after you press the Start button).
- Page 28 Adding or removing laundry after the start of the program To add laundry during washing program, you must first select the enable/disable option. (See chapter: SETTINGS). To add or remove laundry during the progress of a washing program, use the Start/Pause button to pause the program.
- Page 29 If you do not take any action within 5 minutes after the end of the program, the display will switch off to standby mode in order to save power. The display will light up again if you press the ON/OFF button. WARNING! After the washing cycle, close the water tap and pull out the washing machine plug from the power socket.
-
Page 30: Settings
Settings Only appliance owner/distributor may change the settings! (owner/distributor should check Service manual) On display Setting Description Max. RPM no Drain --> max. rpm Setting affect all programs Drain Valve/Drain Setting of draining via valve or pump, depending on the type of appliance;... - Page 31 Table continued from last page On display Setting Description Child Lock On/Off Choose between switching the Child lock On or Off. When the child lock is activated, no other function can be selected. Programmes Selected program will be shown on display Set Language Select your language - press •...
- Page 32 Table continued from last page On display Setting Description Add Clothes function is available in Wash phase on majority of the programs. Add clothes function is available also on program Rinse (only during first rinse on Rinse pro- gram). If water level is higher than al- lowed to open door, water will be pumped out.
-
Page 33: Cleaning And Maintenance
Cleaning and maintenance Cleaning the detergent compartment and door rubber gasket Press the tab to completely remove the detergent compartment from its housing. Rinse and thoroughly clean the tray. You may also remove the cap from the plug in the condi- tioner compartment (A). - Page 34 INFORMATION! Do not clean the washing machine with a jet of water! ELECTRIC SHOCK! Always disconnect the washing machine from the power mains before cleaning. In the case of a 3 phase connection of the appliance, switch off the main socket switch. Cleaning the washing machine interior against odours Modern detergents often allow washing clothes at low temperatures.
- Page 35 Table continued from last page Hold the rib with the other hand and pull it to- wards you. Lift the drum rib. Remove any objects. Place the rib into the installation slot indicated with "F" towards you. Make sure all ribs are firmly in place in their respective slots in the drum.
-
Page 36: Errors What To Do
Errors what to do? Disturbances from the environment (e.g. the power grid) may result in various error reports (see Troubleshooting table). In such case: • Switch off the appliance, wait for 1 minute, switch the appliance back on, and repeat the washing program. - Page 37 Table continued from last page Problem/error Cause What to do? Washing time is • Low inlet water temperat- • Program duration can be up to 60% longer than anti- ure. longer than initially anticipated in the nor- cipated (the time mal progress.
- Page 38 Table continued from last page Problem/error Cause What to do? There are white • This is not due to poor • Immediately rinse the laundry again. residues of wash- rinsing by your washing • Use liquid detergents that do not contain ing powder on the machine, but rather due to zeolites.
- Page 39 Table continued from last page Problem/error Cause What to do? • Increase the amount of laundry in the washing machine and restart the program (see "STEP 7: Start the wash / Adding or removing laundry after the start of the program").
- Page 40 Manual opening of washing machine door ELECTRIC SHOCK! Washing machine door may be opened manually if the appliance is not connected to the power mains and if the water has been pumped out of the machine. A. Choose the Spinning or Drain program to pump the water from the machine. If this does not work, water has to be drained from the washing machine drum manually.
- Page 41 Failure display In case of a failure while a program is in progress, the relevant Error XX is indicated on the display unit. Press the INFO button to display the error description. Switch off the appliance and turn it back on. Errors indicated on the display unit may include the following: Error Error indication on the dis-...
- Page 42 Table continued from last page Error Error indication on the dis- What to do? play unit • is the water supply hose deformed (clipped, clogged etc.), • is the pressure in the water mains between 0.1 and 1 MPa (1 10 bar). Then, press the Exit button to resume the program.
- Page 43 Table continued from last page Error Error indication on the dis- What to do? play unit Unevenly distributed laundry. Manually distribute the laundry and run the spinning pro- gram. Unable to lock door Open and firmly close the door again to final position. If the error reoccurs, call a service technician.
-
Page 44: Service
Service Before calling a service technician When you contact a service centre, please state the model (1), type (2), and serial number (3) of your washing machine. Model, type, and serial number are indicated on the rating (type) plate located on the washing machine door casing. -
Page 45: Technical Information
Technical information Technical information Height 850 mm Width 595 mm Depth 591 mm Weight 77,0 kg Drum volume 60 l Rated power See rating plate Heater power See rating plate Water pressure 0,1 1 MPa 1 10 kp/cm 10 100 N/cm Emission sound pressure level in accordance <... -
Page 46: Program Chart
Program chart SC70 7kg_1400_3kW Water consump- tion (approxim- ately, in litres) Program Heavy wash 60°C 1400 1,30 1:40 Heavy wash 90°C 1400 2,30 2:10 White/Color 20°C 1400 0,14 0:40 White/Color 40°C 1400 0,46 0:49 White/Color 60°C 1400 1,30 0:59 White/Color 60°C *... -
Page 47: Adjustment Of The Displayed Washing Time
Table continued from last page Water consump- tion (approxim- ately, in litres) Program Allergy Synthetic 60°C 1200 0,80 1:55 Cleaning 1,10 1:10 Program A 1400 Program B 1400 Program C 1400 Program D 1400 Program E 1400 Program F 1400 Program G 1400 Program H... - Page 48 Unevenly distributed laundry or lumps of laundry in the washing machine drum can cause problems such as vibration and noisy operation. The appliance can sense such lumps and will try to redistribute the laundry. Smaller loads (e.g. one towel, one sweater, one bathrobe etc.) or clothes made of materials with special geometrical properties are virtually impossible to distribute evenly across the washing machine drum (slippers, large items etc.).
-
Page 49: Removal
Removal Disposal / recycling of packaging Our product packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. To this end, packaging materials are labelled appropriately. The symbol on the product or its packaging indicates that the product should not be treated as normal household waste. -
Page 50: Quick Guide
Quick guide Sort the laundry. Close the zippers. Empty the pockets and turn them inside out. Check the laundry care symbols. Sort the laundry based on how heavily soiled it is, by colour, and by material. Switch on the main ON/OFF switch Open the washing machine door and insert the laundry.
