Operating Instructions

Washing Machine

Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and ful l your needs
for many years to come. Scandinavian design combines clean
lines, everyday functionality and high quality. These are key
characteristics of all our products and the reason they are
greatly appreciated throughout the world.
To get the most from your new machine, we recommend that
you read the operating instructions before using the machine.
The operating instructions also include information on how
you can help protect the environment.
ASKO W6444

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W6444 and is the answer not in the manual?

Questions and answers

Summary of Contents for Asko W6444

  • Page 1: Operating Instructions

    Operating Instructions Washing Machine Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and ful l your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
  • Page 2: Table Of Contents

    Contents Before using your machine for Washing the first time Sort your laundry. Transport protection Turn on the main power switch Packing material Open the washer door and load Washer door the washing Checking water hardness Add detergent and fabric softener, as required Safety instructions Select the program...
  • Page 3 Contents Installation Positioning the washing machine Adjusting the feet Connection to water supply Drainage connection Electrical installation Service Before contacting the service division Quick guide...
  • Page 4: Before Using Your Machine For The First Time

    Before using your machine for the first time Transport protection Remove any transport protection devices before installing the machine. See the "Transport protection" chapter. Packing material Sort waste materials in accordance with local guidelines. Washer door • The washer door will not open until the machine is connected to the electricity supply.
  • Page 5: Safety Instructions

    • Installation should be carried out by qualified fall below freezing, do as follows: ASKO technicians. • Empty the filter and the drainage pump. See • The machine should only be used for washing the "Care and cleaning"...
  • Page 6: Child Safety

    Child safety Keep an eye on children! • Always close the door and start the programme immediately once you have added detergent. • The appliance is not intended for use by young children or infirm persons without supervision. • Young children should be supervised to ensure that they do not play with the appliance.
  • Page 7: Description Of The Washing Machine

    Description of the washing machine 1. Main power switch 2. Detergent compartment 3. Program panel 4. Serial number plate (on inside of washer door) 5. Drainage pump cover 6. Drainage pump (behind cover) 7. Washer door Detergent compartment 1. Pre-wash 2.
  • Page 8: Advice And Tips Before Washing

    Advice and tips before washing Here are some tips that may help you before washing. Sorting your laundry Sort items according to: • how soiled they are • colour • material Clothing 1. Do up zips and close Velcro straps so that they don’t harm fabrics.
  • Page 9: Wool

    Advice and tips before washing Wool Economy and efficiency These fabrics are labelled either machine wash You can save energy by not using higher or hand wash. The Wool/hand wash program is temperature programs than necessary. • Select Quick if you just need to freshen up at least as gentle as washing by hand.
  • Page 10 Advice and tips before washing NOTE! Due to environmental concerns, we discourage the use of strong chemicals. When using agents for bleaching or stain removal, there is a risk of rust (corrosion) and discolouration of the machine.
  • Page 11: Washing

    Washing Sort your laundry. NOTE! See the "Advice and Tips before washing" Detergent overdosing does not give better section. washing results; it merely causes a greater Place underwired bras in a laundry net. impact on the environment; can also hinder the wash performance.
  • Page 12: Select The Program

    Washing Select the program Door opening Temperature Super rinse Program name Spin Time Start/Stop You select a program by turning the program selector. An LED lights up beside the selected program and the estimated program time is shown in the display. The program time is based on the time last taken by the same program.
  • Page 13 Washing 6. Easy Care 8. Wool/hand wash Program for blended materials, permanent press A gentle laundry program for wool, silk and shirts and functional sports clothing. The program garments that should be washed by hand. The has a high water level and as such is also suitable highest temperature is 30 °C.
  • Page 14: Program Chart

    Washing Program chart Water consump- Energy consump- Program time Pre- Number of (approx. hrs and Spin Speed Max. load tion tion Program wash Temp. °C Rinses ( kg) (approx. liter) (approx. kWh) min.) 1. Auto 1400 2:45 2. Heavy 1400 2:40 1400 1,13...
  • Page 15: Select Options

    Washing Select options You can select options to adjust the wash program to suit your own specific requirements. The available options depend on the selected program. If the option is available for the selected program, the symbols lights up when you press the button. The machine will remember the options you select for each program (with one exception –...
  • Page 16: Close The Washer Door And Press The Start/Stop Button

    Washing Close the washer door and Once the program has finished press the Start/Stop button Once the program has finished, "End" appears in the display. Time remaining The washer door opens automatically once the When the program starts an estimated program program has finished.
  • Page 17: Settings

    Settings You can change the following settings: Automatic door opening. Extra rinses. Door opening If you choose Automatic door opening the Washer door will open once the program has finished. 1. Turn off the machine using the main power switch. 2.
  • Page 18: Care And Cleaning

    Care and cleaning Cleaning the trap and the drainage Cleaning the detergent pump compartment The washing machine has a trap where smaller NOTE! objects such as coins and hairpins can collect. Do not run the detergent compartment through To clean the trap and the drainage pump, do as a dishwasher! follows: 1.
  • Page 19: Cleaning The Inside Of The Machine To Avoid Unpleasant Smells

    Care and cleaning Cleaning the inside of the machine to avoid unpleasant smells Modern detergents often allow clothes to be washed at low temperatures. This means that small deposits can build up in the machine. These, in turn, may lead to unpleasant smells developing; especially if constantly using cold wash.
  • Page 20: Rinse Holes Under The Agitator

    Care and cleaning Rinse holes under the agitator If you have hard water If you suspect that objects such as nails or paper If you live in an area with hard water (high clips may have fallen into the wash drum, you limescale content), a greyish-white coating may should check the space under the agitator.
  • Page 21: Troubleshooting

    Troubleshooting The washer door will not open 1. Check that the main power switch is on. 2. Is there power? Check your home’s fuses (circuit breakers). The washer door cannot be opened with the Door opening button (with the key symbol) if power is off. If nothing else works, the washer door can be opened as follows: WARNING!
  • Page 22: Error Messages

    Troubleshooting F12 Water inlet fault Error messages Check: If an error occurs during the program a message • that the tap on the water pipe is open. is shown on the display. To exit the message after • that the filter in the machine’s water inlet is not taking measures, turn the machine off and then blocked.
  • Page 23: Technical Information

    Technical information Technical data Height: 850 mm Width: 595 mm Depth: 585 mm Weight: 73 kg Cylinder volume: 60 l Max. washing capacity: 7 kg Spin speed (rpm): 400-1400 Rated power: See type plate. Heater output: See type plate. Water pressure: 0,1-1 MPa 1-10 kp/cm 10-100 N/cm...
  • Page 24 Technical information Loading procedure for standard test: When loading the machine for testing according to AS/NZS 2040:2005 it shall be loaded according to the table below. Garments are placed on top of each other in layers and the soil swatches should be placed inside the wash drum in the direction shown in the table, seen from above.
  • Page 25: Transport Protection

    Transport protection Your washing machine has transport protection of Type A or Type B. Type A NOTE! Before the machine is used, the three transport If the machine is to be moved and transported, screws should be removed as shown below. the transport screws must be refitted to prevent damage to the machine through shaking.
  • Page 26 Transport protection Type B Remove the three transport bolts and the plastic plugs for locking the machine for transport before using the machine. NOTE! If the machine is to be transported, the bolts and plastic plugs for locking the machine during transport must be installed to prevent damage to the machine through shaking.
  • Page 27: Installation

    Installation Positioning the washing machine Connection to water supply The washing machine can be installed as a built-in Water connection should be carried out by an or freestanding unit. Position the machine so that appropriately qualified person. Connect the the electrical plug is easily accessible. machine using the accompanying supply hose.
  • Page 28: Drainage Connection

    Installation Drainage connection Electrical installation The machine is supplied with a drainage hose Connect the machine by plugging it into an attached, which must be connected to a drain. earthed wall socket. The electrical wall socket See the examples below. The height must be must be placed outside of the installation area to 600–900 mm above floor level.
  • Page 29: Service

    Service Before contacting the service Model Number division Before you contact the service division, make sure Serial that you know the model number (located on the Number front panel), and serial number. The model designation can be found on the panel. The type designation and serial number can be found on the type plate on the inside of the washer door.
  • Page 30 Your notes...
  • Page 31 Your notes...
  • Page 32: Quick Guide

    Quick guide Washing fabric softener into the compartment on 1. Empty pockets and refasten zips. the right with the -symbol. 2. Read the item’s laundry label. 2. If you use liquid detergent, follow the 3. Sorting laundry. detergent manufacturer’s recommendations. NOTE! Select the program Place underwired bras in a laundry net.
