TRENDnet TE100-S88E Specifications

TE100-S88E
8-Port 10/100Mbps N-Way Ethernet Switch
TRENDnet's TE100-S88E, 8-port palm-sized 10/100Mbps N-
way Ethernet Switch, present the perfect choice for small
workgroups for any desktop space. They allow users to simply
plug any port to either a 10Mbps or 100Mbps network to
multiply bandwidth, boost response time and satisfy heavy
load demands. With 8 ports readily available, The TE100-
S88E is easy to install and expand. The N-way ports
automatically negotiate between 10Base-T and 100Base-TX
network speeds, as well as between half- and full-duplex
modes. Thus, any port is capable of uplinking to Fast Ethernet
or downlinking to Ethernet. The TE100-S88E provide cost-
effective, and high-performance solutions.
FEATURES
Compliant with IEEE 802.3 and IEEE 802.3µ
standards
8-port N-way 10/100M auto-detection
1 uplink/MDI-II connector for easy expansion
(shares with port 1)
Half- or full-duplex for each port
Operates at maximum packet filtering and
forwarding rate
Supports for store-and-forward of packet switching
256KB RAM buffer memory
Filtering Address Table up to 8K entries (per device)
Compact design for external power adapter
Comprehensive LED indications for port status
Network looped detecting
5 Year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Flexible:
Connects both 10Mbps and 100Mbps
segments to one network.
Performance:
All ports are full-duplex which double
network speed.
Easy-To-Use:
Built-in address self-learning
technology.
Reliable:
Store-and-Forward Ethernet packet
switching provides low latency and
high data integrity.
Compatible:
Complies with 10Base-T, IEEE802.3
and 100Base-TX, IEEE802.3µ
standards
TE100-S88E (11-17-2002)
