Single Acting Hollow Hole Cylinder
MODEL: 6CH12T03
Maximum Operating Pressure 10,000 PSI
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES
6CH12T03-M0_042015
OWNER/ OPERATOR MANUAL
J.H. Williams Tool Group
6969 Jamesson Road,
Midland, GA 31820
Rated Capacity: 12 Ton
Printed in Taiwan
Advertisement
Table of Contents
Related Manuals for Williams 6CH12T03
Summary of Contents for Williams 6CH12T03
- Page 1 J.H. Williams Tool Group 6969 Jamesson Road, Midland, GA 31820 OWNER/ OPERATOR MANUAL Single Acting Hollow Hole Cylinder MODEL: 6CH12T03 Rated Capacity: 12 Ton Maximum Operating Pressure 10,000 PSI This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
- Page 2 (a load dropped suddenly, unexpectedly upon it), discontinue use components and recognize the hazards associated with its use. until checked out by a Williams authorized service center. Owners 2. Verify that the product and the application are compatible. If in...
- Page 3 10,000 psi. Never try to disassemble a hydraulic cylinder, refer • Do not connect a cylinder to a pump with higher pressure rating. repairs to qualified, authorized personal. Contact Williams • Do not subject cylinder to a shock loads, a load dropped tech service for authorized service center.
- Page 4 (never exceed 400 hours). Follow pump manufacturers 1. Secure load by other means. instructions for changing and adding hydraulic fluid. Use only good quality hydraulic fluid. We recommend Mobil DTE13M or 2. Depressurize pump and hose. equivalent when using with hand pump or air pump; Williams 3. Remove the cylinder from application. Oil (F01) or equivalent when using with electric pump. Never use brake fluid, transmission fluid, turbine oil, motor oil, alcohol, 4. Disconnect and replace with new coupler.
- Page 5 Figure 2 - Illustration to bleed air from system TROUBLESHOOTING GUIDE The following information is intended as an aid in determining if problem exists. Cylinders should be repaired only by authorized Williams Service Center. For repair service, contact service center in your area.
- Page 6 (*) - indicates items included in, and available only as part of Seal Kit N/A - part is not available as replacement Note: To ensure safe and reliable performance, replace worn or damaged parts with Williams Authorized Replacement Parts only.
- Page 7 (*) - indicates items included in, and available only as part of Seal Kit N/A - part is not available as replacement Note: To ensure safe and reliable performance, replace worn or damaged parts with Williams Authorized Replacement Parts only.
- Page 8 • This warranty does not cover ordinary wear and tear, overloading, alterations (including repairs or attempted repairs not performed by Williams or one of its authorized personnel), improper fluid use, or use of the product in any manner for which the product was not intended or the use of which is not in accordance with the instructions or warnings provided with the product.
