Single Acting Aluminum Cylinders
MODELS:
6CA30T02, 6CA30T04, 6CA30T06
6CA50T02, 6CA50T04, 6CA50T06, 6CA50T10
6CA75T04, 6CA75T06
6CA100T02, 6CA100T04, 6CA100T06 & 6CA100T10
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Read, understand, and follow the instructions before using the device.
• The operating instructions and safety information must be communicated in the language of the operator prior
to use.
• Failure to do so may cause personal injury or property damage.
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES
