Williams 6CF05T03 Owner's/Operator's Manual

Single acting, flat body cylinders 5 to 50 tons
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODELS: 6CF05T03, 6CF10T05, 6CF20T05, 6CF30T05 & 6CF50T05
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
• Leer, comprender, y seguir las instrucciónes antes de utilizar el aparato.
• El manual de instrucciónes y la información de seguridad deben estar comunicado en lengua del operador
antes del uso.
• No seguir estas indicaciónes puede causar daños personales o materiales.
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES
6CF05T03-M0_062017
OWNER/ OPERATOR MANUAL
Single Acting,
Flat Body Cylinders
CAPACITY: 5 TO 50 TONS
Model No. H2405
(Max. Operating Pressure 10,000 PSI)
Approved By:
Date: 2013.01.31
!
ADVERTENCIA
Checked By:
Drawn By: 姚宏龍
File name: H2405_1301OUT
J.H. Williams Tool Group
6969 Jamesson Road,
Midland, GA 31820
Printed in Taiwan
