USER'S MANUAL (PART 2)
AIR CONDITIONER FOR ELECTRICAL ENCLOSURE
AVC035.000 / AVC035.010 / AVC035.020 / AVC0350.001 / AVC035.011 / AVC035.021
Document: UMA-CDZ-AVC035xxAE-03
Description
Original user's manual for air conditioner AVC035 series
Language: English
Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE
UMA-CDZ-AVC035xxAE-03
INDOOR APPLICATION
AVC035
Date
ISSUE
26/02/2016
REV. 01
18/01/2017
REV. 02
19/02/2019
REV. 03
25/06/2020
Name
Ascheri M.
Ascheri M.
Ascheri M.
Ascheri M.
Page 1/20
Advertisement
Table of Contents
Related Manuals for Alfa Electric AVC035.000
Summary of Contents for Alfa Electric AVC035.000
- Page 1 USER’S MANUAL (PART 2) AIR CONDITIONER FOR ELECTRICAL ENCLOSURE INDOOR APPLICATION AVC035 AVC035.000 / AVC035.010 / AVC035.020 / AVC0350.001 / AVC035.011 / AVC035.021 Document: UMA-CDZ-AVC035xxAE-03 Date Name Description ISSUE 26/02/2016 Ascheri M. REV. 01 18/01/2017 Ascheri M. Original user’s manual for air conditioner AVC035 series REV.
-
Page 2: Table Of Contents
4.1 - DIGITAL THERMOSTAT Page 17 4.2 - MECHANICAL THERMOSTAT 5-SPARE PARTS LIST Page 18 Page 18 5.1 - SPARE PARTS FOR AVC035.000, AVC035.010, AVC035.020 Page 18 5.2 - SPARE PARTS FOR AVC035.001, AVC035.011, AVC035.021 WARRANTY Page 19 CONFORMITY DECLARATION... -
Page 3: 1-Technical Data
1 - TECHNICAL DATA Features Unit AVC035.000 AVC035.001 AVC035.010 AVC035.011 AVC035.020 AVC035.021 Power supply V/Hz 230V/1ph/50-60 115V/1ph/50-60 400V/2ph/50-60 Dimensions HxWxD 430x280x170 Cooling capacity 350/370 A35A35 Cooling capacity 200/220 A35A50 Max current 1.5/1.6 3/3.2 0.9/1 Delayed fuse Absorbed electric power 290/320... -
Page 4: 2-Installation
2 - INSTALLATION 2.1 PRODUCT HANDLING AIR CONDITIONER AVC series must be handled in upright position and protected against accidental tipping over. Air conditioners AVC035 series are fitted with female blind threaded insert to screw male lifting eye bolts. The air conditioner handling, when unpacked, can be done thanks to lifting eye bolt. If lifting eye bolts are not included, please provide an adequate M6 male lifting eye bolt (2) and screw it inside blind threaded (1) insert placed on top of the air conditioner Check the proper fixing of eye bolts before lift the air conditioner. -
Page 5: Fitting
2.3 FITTING 1) Make the fixing hole on the enclosure as is shown in the drilling template Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 5/20 UMA-CDZ-AVC035xxAE-03... - Page 6 Deburr all sharp edges to avoid accidental injuries 2) Apply the gasket (included in fixing kit) on the back panel of the air conditioner; 3) Lift the air conditioner by lifting eyebolt and place it near the enclosure wall 4) Mount the air conditioner on the electrical cabinet according to the drilling template with M6X16 screws and washers against unscrewing (included in mounting kit) 5) Connect the condensate drain pipe as is shown in picture below Air conditioner produces condensate because the moist air inside of the...
-
Page 7: 3-Electrical Connection
The enclosure must be IP 54 protected, if enclosure is not airtight, condensate production could increase. The enclosure IP54 degree is guaranteed only if the air conditioner is proper mounted. 3 - ELECTRICAL CONNECTION The electrical installation must be carried out by a qualified electrician who is responsible for compliance with the applicable standards and regulations. -
Page 8: Wiring Diagram
3.1 WIRING DIAGRAM 3.1.1 AVC035.000 Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 8/20 UMA-CDZ-AVC035xxAE-03... -
Page 9: Avc035.010
3.1.2 AVC035.010 Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 9/20 UMA-CDZ-AVC035xxAE-03... -
Page 10: Avc035.020
3.1.3 AVC035.020 Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 10/20 UMA-CDZ-AVC035xxAE-03... -
Page 11: Avc035.001
3.1.4 AVC035.001 Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 11/20 UMA-CDZ-AVC035xxAE-03... -
Page 12: Avc035.011
3.1.5 AVC035.011 Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 12/20 UMA-CDZ-AVC035xxAE-03... -
Page 13: Avc035.021
3.1.6 AVC035.021 Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 13/20 UMA-CDZ-AVC035xxAE-03... -
Page 14: 4-Starting And Adjustment
4 - STARTING AND ADJUSTMENT After finishing assembly of the conditioner, wait approx. 30 min. before starting it (the oil must collect in the compressor to ensure lubrication and cooling). The air conditioner operates automatically, that is to say, after insertion, the evaporator fan operates continuously making the air inside the cabinet circulate. - Page 15 evaporator sensor -20~+20℉ 0~60 Defrost cycle 30min 0: Cancel defrost function Maximum defrost time 1~99 0~45℃ Defrost stop temperature 7℃ ℃/℉ 32~115℉ Compressor start and stop 00: Disable in the mode of “run/stop in 01：Enable a proportional time” Compressor start time in case of cabinet sensor 01~60 fault...
- Page 16 2) Press the button again to display the parameter value of , and modify the temperature set- point by pressing WARNING: temperature which unit starts to work is St+C1. For example: St=31, C1=4 compressor and condenser fan turn on at 35°C (31°C+4°C) Parameter adjustment 1) When shows, press...
-
Page 17: Mechanical Thermostat
4.2 MECHANICAL THERMOSTAT (only for AVC035.000, AVC035.010, AVC035.020) Before any operation TURN OFF the power of electrical enclosure WARNING: the air conditioner is designed to operate at 35 ° C cabinet temperature. If the set point is changed the performance of the unit will vary. -
Page 18: 5-Spare Parts List
5 – SPARE PARTS LIST SPARE PARTS LIST 5.1- SPARE PARTS FOR AVC035.000, AVC035.010, AVC035.020 REFERRED TO WIRING DESCRIPTION CODE DIAGRAM (page 8-10) Evaporator fan A2175HBL-TC Compressor BSA357DT Condenser fan VCENT190D230V Compressor capacitor CON6.3UFS2M8F Condenser fan capacitor CON2UFS2M8F Regulating thermostat TERMOSTTR2 5.2- SPARE PARTS FOR AVC035.001, AVC035.011, AVC035.021... -
Page 19: Warranty
WARRANTY Alfa Electric Division of: ALFA PLASTIC s.a.s. Via Della Valle, 39 – 20048 CARATE BRIANZA (MI) Tel. +39 (0362) 903.539 – Fax +39 (0362) 975.133 Mail: info@alfaelectric.com www.alfaelectric.com guarantees that the product is free from any quality defects. The product is guaranteed for a period of 12 months from the date of delivery, provided it operates under the following conditions: 1. -
Page 20: Conformity Declaration
UE DECLARATION OF CONFORMITY Alfa Electric Division of: ALFA PLASTIC s.a.s. Via Della Valle, 39 – 20841 CARATE BRIANZA (MB) Tel. +39 (0362) 903.539 – Fax +39 (0362) 975.133 Mail: info@alfaelectric.com www.alfaelectric.com DECLARE THAT THE AIR CONDITIONER FOR ELECTRICAL CABINETS...
