- Page 1 OWNER’S MANUAL BOTTOM FREEZER REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. GR-B28ANSPP www.lg.com P/No. : MFL62184520...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS PRODUCT FEATURES HOW TO USE Before Use Control Panel IMPORTANT SAFETY - Control Panel Features INSTRUCTIONS Automatic Icemaker - Automatic Icemaker (Freezer Room) COMPONENTS - Turning the Automatic Icemaker On or Off Refrigerator Interior - When You Should Turn the Icemaker Off - Normal Sounds You May Hear - Preparing for Vacation... -
Page 3: Product Features
PRODUCT FEATURES PRODUCT FEATURES * Depending on the model, some of the following functions may not be available. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer drawer remains open. If a refrigerator door or freezer drawer is left open for more than 60 seconds, a warning alarm sounds in 30 second intervals. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product. - Page 5 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. Do not use this product for special purposes (storage of medicine or test materials or on ships, etc).
- Page 6 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. CAUTION Installation The refrigerator must be properly installed in accordance with the Installer Instructions that were taped to the front of the refrigerator.
-
Page 7: Components
Fixed Door Bin needs. Modular Door Bins Modular Door Bins Crispers LG’s crispers preserve humidity and help Fixed Door Bin vegetables stay crisp. Auto Closing Hinge Fixed Door Bin When you slightly push the door of Glide’N’Serve... -
Page 8: Installation
INSTALLATION INSTALLATION Unpacking Your Refrigerator Choosing the Proper Location Select a place where a water supply can WARNING be easily connected for the automatic icemaker. Use two or more people to move and install the refrigerator. Failure to do so NOTE can result in back or other injury. -
Page 9: Ambient Temperature
INSTALLATION Ambient Temperature Removing/Assembling the Refrigerator Door Handles Install this appliance in an area where the temperature is between 13°C and 43°C. If the temperature around the appliance is too low or NOTE high, cooling ability may be adversely affected. Removing the doors is always Do not store the refrigerator in Direct Sunlight recommended when it is necessary to... -
Page 10: Removing/Assembling The Freezer Drawer Handle
INSTALLATION Removing/Assembling the Removing/Assembling the Freezer Drawer Handle Doors and Drawers Removing the Handles Removing the doors is always recommended when it is necessary to move the refrigerator through a narrow opening. Loosen the set screws located on the lower side of the handle with a in. -
Page 11: Removing The Left Refrigerator Door
INSTALLATION Removing the Left Refrigerator Door Removing the Right Refrigerator Door Open the door. Remove the top hinge cover screw (1 ). Lift up the cover (2). Remove the cover. Open the door. Remove the top hinge cover screw (1 ). Rotate the hinge lever (3) clockwise. -
Page 12: Assembling The Left Refrigerator Door
INSTALLATION Assembling the Left Refrigerator Assembling the Right Refrigerator Door Door Install the right-side door first. Install the left refrigerator door after the right door is installed. Lower the door onto the middle hinge pin. Make sure that the plastic sleeve is Lower the door onto the middle hinge pin. -
Page 13: Removing The Freezer Drawers
INSTALLATION Holding both sides of the door pull up to Removing the Freezer Drawers separate the door from the rails. The top, middle and bottom drawers are all removed in the same way. CAUTION Use two or more people to remove and install the freezer drawer. -
Page 14: Assembling The Freezer Drawers
INSTALLATION Lower door into final position and tighten Assembling the Freezer Drawers the screws. With both hands, pull out each rail simultaneously until both rails are fully extended. With the drawer pulled out to full extension, insert the drawer and ice bin in the rail assembly. -
Page 15: Connecting The Water Line
INSTALLATION Connecting the Water Line Before You Begin Water Pressure This water line installation is not covered by the A cold water supply. The water pressure must refrigerator warranty. Follow these instructions be between 140 and 860 kPa on models without carefully to minimize the risk of expensive water a water filter and between 275 and 860 kPa on damage. -
Page 16: Leveling And Door Alignment
INSTALLATION Leveling and Door Alignment Leveling Door Alignment After installing, plug the refrigerator’s power Both the left and right refrigerator doors have cord into a 3-prong grounded outlet and push an adjustable nut, located on the bottom hinge, the refrigerator into the final position. to raise and lower them to align properly. -
Page 17: How To Use
HOW TO USE HOW TO USE Before use Clean the refrigerator. Clean your refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator,. -
Page 18: Control Panel
HOW TO USE Control Panel * Depending on the model, some of the following functions may not be available. Control Panel Features Freezer Freezer Alarm Alarm When the power is connected to the Press the button to adjust the refrigerator, door alarm is initially set ON temperature in the freezer compartment. -
Page 19: Automatic Icemaker
HOW TO USE When You Should Turn the Automatic Icemaker Icemaker Off Automatic Icemaker (Freezer Room) When the water supply will be shut off for several hours. * Depending on the model, some of the When the ice bin is removed for more following functions may not be available. -
Page 20: Storing Food
HOW TO USE Storing Food Food Preservation Location Each compartment inside the refrigerator is designed to store different types of food. Store your food in the optimal space to enjoy the freshest taste. Adjustable Refrigerator Shelf Dairy product bin Adjustable shelves to Store milk products such as meet your individual butter and cheese. -
Page 21: Food Storage Tips
HOW TO USE Storing Frozen Food Food Storage Tips * The following tips may not be applicable NOTE depending on the model. Check a freezer guide or a reliable cookbook for further information about preparing food Wrap or store food in the refrigerator in airtight for freezing or food storage times. -
Page 22: Humidity Controlled Crisper And Glide'n'serve
HOW TO USE Storing Frozen Food (continued) Humidity Controlled Crisper and Glide’N’Serve Packaging Packaging Successful freezing depends on correct Humidity Controlled Crisper packaging. When you close and seal the You can control the amount of humidity in the package, it must not allow air or moisture in or moisture-sealed crispers. -
Page 23: Detaching And Assembling The Storage Bins
HOW TO USE Detaching and Assembling the Selection Button Storage Bins When “MEAT” is selected, the temperature of the Glide‘N’Serve can be kept around 1°C. This feature helps Glide’N’Serve and Humidity keep meat or fish fresh for a longer Controlled Crisper time. - Page 24 HOW TO USE To Remove the Glass Ice Bin (Pantry drawer not shown for clarity) To separate the ice bin, pull out the drawer to full extension. Gently lift and pull out the ice Lift up the glass under the crisper cover, and bin.
-
Page 25: Adjusting The Refrigerator Shelves
HOW TO USE Using the Folding Shelf Adjusting the Refrigerator Shelves You can store taller items by simply pushing the front half of the shelf underneath the back The shelves in your refrigerator are adjustable half of the shelf. Pull the front of the shelf to meet your individual storage needs. -
Page 26: Maintenance Cleaning
MAINTENANCE MAINTENANCE Cleaning Both the refrigerator and freezer sections defrost automatically; however, clean both sections about once a month to prevent odors. Wipe up spills immediately. Always unplug the refrigeration before cleaning. General Cleaning Tips General Cleaning Tips Inside Walls (allow freezer to warm Inside Walls (allow freezer to warm up so the cloth will not stick) up so the cloth will not stick) -
Page 27: Light Bulb Replacement
MAINTENANCE When you move Light bulb replacement When you are moving your refrigerator to a new home, follow these steps to prepare it for the WARNING move. Electrical Shock Hazard Remove all food from the refrigerator and Before replacing a Compartment Lamp, pack all frozen food in dry ice. -
Page 28: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Review the Troubleshooting section before calling for service; doing so will save you both time and money. Problem Possible Causes Solutions Refrigerator and The refrigerator control is set to Turn the control ON. Refer to the Setting the Freezer section OFF (some models). - Page 29 TROUBLESHOOTING Problem Possible Causes Solutions Refrigerator or Refrigerator was recently It may take up to 24 hours for each compartment Freezer section is installed. to reach the desired temperature. too warm. Air vents are blocked. Rearrange items to allow air to flow throughout the compartment.
- Page 30 TROUBLESHOOTING Problem Possible Causes Solutions Interior moisture Doors are opened often or for When the doors are opened often or for long buildup. long periods of time. periods of time, warm, humid air enters the compartment. This raises the temperature and moisture level within the compartment.
- Page 31 TROUBLESHOOTING Problem Possible Causes Solutions Frost or ice Condensation from food with a This is normal for food items with a high water crystals on frozen high water content has frozen content. food (inside of inside of the food package. sealed package).
- Page 32 TROUBLESHOOTING Problem Possible Causes Solutions Icemaker is not Doors are opened often or for If the doors of the unit are opened often, ambient making enough long periods of time. air will warm the refrigerator which will prevent ice (continued). the unit from maintaining the set temperature.
- Page 33 TROUBLESHOOTING Problem Possible Causes Solutions Icemaker is Icemaker shutoff (arm/sensor) Empty the ice bin. If your icemaker is equipped making too much is obstructed. with an ice shutoff arm, make sure that the arm ice. moves freely. If your icemaker is equipped with the electronic ice shutoff sensor, make sure that there is a clear path between the two sensors.
- Page 34 TROUBLESHOOTING Problem Possible Causes Solutions Pulsating or Your refrigerator is designed Normal Operation High-Pitched to run more efficiently to keep Sound your food items at the desired temperature. The high efficiency compressor may cause your new refrigerator to run longer than your old one, but it is still more energy efficient than previous models.
- Page 37 Printed in Korea...
