- Page 1 E315 E315/24V Product Guide Programmable Extension Timer today, tomorrow and in the future mselectronics.co.uk...
- Page 2 1. IMPORTANT: ensure all electrical connections are isolated before commencing any work on the unit. 2. The E315 is designed to be mounted into a 20mm (or deeper) single-gang UK pattress or back box. 3. Connect the wiring to the terminal blocks on the extension timer as shown in Figure 1 (or any suitably appropriate form).
- Page 3 To remove the screw covers without damage, use an adhesive putty such as blu-tack as an aid. Operation Operation Modes The E315 has 3 operating modes: Standby: Power-saving mode where the dimmed LED displays show “0” on all digits. Setting Up: Bright LED displays with the currently selected display blinking.
- Page 4 Product Warranty MS Electronics guarantees all their products against manufacturing defects for 3 years from the purchase date. If your product is found to be faulty, MS Electronics will, at their discretion, repair or replace the product free of charge.
