- Page 1 E313 Product Guide Programmable Extension Timer with Delay today, tomorrow and in the future mselectronics.co.uk Issue 1.2...
-
Page 2: Product Overview
2. Ensure the control panel has a hole cut-out of the correct size to mount the E313 extension timer (see Figure 2). 3. Unscrew the 4 screws on the face of the E313 to remove the back cover, plus the 2 screws holding the mounting bracket to the back cover. -
Page 3: Technical Specification
Hold “Increase” until the digit shows “4”. g. Hold “Start” to start the extension running. The E313 will count down 16 hours before enabling the relay output for 4 hours. Additional Operating Guidelines a. The extension may be cancelled at any time by holding down the “Stop” button. - Page 4 Technical Support For further help or information on this and the other products in the MS Electronics range visit www.mselectronics.co.uk or call 0333 666 1176. Alternatively, email techsupport@mselectronics.co.uk Additional copies of this product guide can be downloaded from our website.
