- Page 1 E314 E314/24V energy saving controls Product Guide Programmable Extension Timer with Delay today, tomorrow and in the future mselectronics.co.uk...
-
Page 2: Product Overview
Product Overview The E314 is a single-shot extension timer designed to control plant equipment such as heating, lighting or air-conditioning systems outside of normal occupancy hours. A voltage-free changeover relay output capable of switching loads of up to 16A, 250V AC is activated for a configurable Extension time period after the configurable Delay period has elapsed. This enables equipment to be automatically activated at the correct time in the future without the user being present, also bypassing difficult reprogramming procedures often encountered when used in conjunction with conventional control equipment. -
Page 3: Technical Specification
Operation Operation Modes The E314 has 3 operating modes: Standby: Power-saving mode where the dimmed LED displays show “0” on all digits. Setting Up: Bright LED displays with the currently selected display blinking. This mode is used to choose the desired Delay and Extension periods. - Page 4 Product Warranty MS Electronics guarantees all their products against manufacturing defects for 5 years from the purchase date. If your product is found to be faulty, MS Electronics will, at their discretion, repair or replace the product free of charge.
