ASSEMBLY INSTRUCTIONS
ITEM NO: BED1008 TWIN/FULL/QUEEN
REMINDER DO NOT OVER TIGHTEN ALL BOLTS UNTIL THE BED IS FULLY SET-UP
1
2
3
Headboard
Footboard
HB Leg
1pc
1pc
2pcs
7
8
9
Side Rail Feet
Support Rail
Support Leg
2pcs
2pcs
2pcs
13
Wingback
2pcs
A
B
C
Bolt
Bolt
Bolt
5/16"×1-1/4"
5/16"×2"
5/16"×1"
8PCS
15PCS
14PCS
H
G
Box Wrench
Allen Key
5/16"
5/16"
1PC
1PC
4
5
6
Headboard Crossband
Headboard Crossband
FB Feet
Side Rail
1pc
1pc
2pcs
4pcs
10
11
12
Center Crossband
Slats
Center Support Leg
1pc
1pc
12pcs
D
E
F
Flat washer
Bolt
Nut
5/16"*19MM
5/16"×5"
5/16"
2PCS
2PCS
41PCS
STEP 1:
STEP 1:
At the back of headboard ( Part 1 ) install the HB leg ( Part 2 ) by using hard ware
provided .
Use allen key (Part G ) to screw in bolt (Part B ) and washer ( Part F ) on each
side ( 2 Bolts & 2 Washers on each side ) . Do not forget about the washer as
this will keep your bed sturdy !
F
B
G
2
B
F
1
2
4PCS
4PCS
F
B
G
Advertisement
Related Manuals for Husky BED1008
Summary of Contents for Husky BED1008
- Page 1 At the back of headboard ( Part 1 ) install the HB leg ( Part 2 ) by using hard ware provided . ITEM NO: BED1008 TWIN/FULL/QUEEN Use allen key (Part G ) to screw in bolt (Part B ) and washer ( Part F ) on each side ( 2 Bolts &...
- Page 2 STEP 2 : STEP 2 : On the headboard (Part 1), install the HB crossband (Part 5) by STEP 3 : Turn the footboard (Part 3) over and screw in using hardware provided. Use the Allen Key (Part G) to screw in the the footboard legs (Parts 4) bolt (Part C) and the washer (Part F) on each side (2 Bolts &...
- Page 3 STEP 5: First, lock in your side rail and the footboard in (Look at STEP 5: First, lock in your side rail and the footboard in (Look at STEP 4 : Now its time to connect the side rails (Part 6), you must line STEP 4 : Now its time to connect the side rails (Part 6), you must line photo).You will now take one side of the completed Side Rail and photo).You will now take one side of the completed Side Rail and...
- Page 4 STEP 6: You will be doing the same thing for Step 6 that you STEP 7: This step requires to properly bolt on the Center Support Rail (Part 8). step 5 (Only difference is your now connecting the right side rail), On each side of the center support rail, you will install 2 support leg (Part 9) please refer to step 5 if you are lost.
- Page 5 STEP 8: Take the center support rail from Step 7 and lay it in the middle of the STEP 9: Similar to Step 8, you will use the 2 bolts (Part C) and 2 washers (Part F) and screw in the bolts to the footboard from the center support rail. bed from headboard to footboard.
- Page 6 STEP 11: This one is easy! Simply take one bolt (Part B) and one washer (Part F) STEP 10: Take Part 11 (Center Crossband) and install that in the middle (As shown and bolt that into center where the center support rail and cross band lay on top of in the photo) by simply using Part A (Bolts) and Part F (Washers) and bolt them into each other as shown in photo.
- Page 7 STEP 12: Take Part 13 ( Wingback ) and install that on the both side of STEP 13 ： Simply take 2 bolts ( Part D ) and 2 washer ( Part F ) and bolt that in headboard ( As shown in the photo ) by using Part B ( Bolts ) and Part F to the bottom holes on HB leg and wingback than you guy can tighten up all the ( Washers ) and bolt them into the holes, make sure the holes are lined up bolts used on step12 and step 13...
- Page 8 STEP 14: Put the back fabric down to bottom,than smooth it by STEP 15: You're almost there ! Simply lay the Slats on the sides of velcro stick right . the side ralls (On the Inside) you can roll them out and the velcro stick right on (Part 12)
- Page 9 STEP 16: Congratulations, you made it to the end! Time to sleep like a baby and forget to leave us a positive review when you wake up =) don't...
