USE AND CARE GUIDE
Husky 61 in. Hutch with 2-Drawer Riser Cabinet
Questions, problems, missing parts?
Before returning to the store, call
Husky Customer Service
8 a.m – 7 p.m., EST, Monday-Friday
9 a.m – 6 p.m., EST, Saturday
1-888-HD-HUSKY
HUSKYTOOLS.COM
We appreciate the trust and con dence you have placed in Husky through the purchase of this
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
THANK YOU
improvement needs. Thank you for choosing Husky!
Item # 1000000000
Model # H61HUTCH
hutch & riser
.
We strive to continually
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Husky H61HUTCH
Summary of Contents for Husky H61HUTCH
- Page 1 THANK YOU hutch & riser We appreciate the trust and con dence you have placed in Husky through the purchase of this We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..........2 Assembly ............... 6 Safety Information ..........2 Cordless Power Tool Battery Chargers ....11 Warranty ..............4 .... - Page 3 CAUTION: RISK OF ELECTRICAL SHOCK: This unit has one power supply cord. Make sure the cord is unplugged before any servicing or cleaning. HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
-
Page 4: Warranty
Contact the Customer Service Team at 1-888-HD-HUSKY or visit www.huskytools.com. Specifications riser drawer) 120 lbs. - Page 5 Package Contents (continued) NOTE: Hutch keys are attached to door. NOTE: Riser cabinet keys are inside drawer. Part Description Quantity Hutch Riser HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
-
Page 6: Assembly
Assembly The 61 in. Hutch and Riser Cabinet is designed to speci cally t only on the Husky 61 in. 15-Drawer Heavy Duty Workbench Model # H61MWC15HP SKU # 1005517358 The wood top on the H61MWC15HP will be reused as the top for the 2-Drawer Riser Cabinet. - Page 7 2. Ensure the four 3/8 in. holes drilled in Step 2 align with the threaded holes in the Riser. 3. Attach the wood top to the riser with 8 bolts previously removed from the H61MWC15HP cabinet. HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
- Page 8 Attach the hutch to the riser 1. Place the Hutch on the Riser after the wood top is installed. 2. Open the Hutch door. 3. Use 4 pcs M6*48mm ange bolts (CC) in the 4 corners and tighten with a 8mm socket or wrench. Using a 3/32 in.
- Page 9 Use the Cable clips (II) to attach the power cord from the LED light and route the wire along the backwall to either the USB in the Hutch or the H61MWC15HP cabinet. Double-sided tape on back HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
- Page 10 Attach the shelf in the hutch Put the shelf into the inner cavity of Hutch at the desired height and fasten the 5 pcs Shelf Clips (EE) to the pegboard to align with the notches in the shelf. Attach the storage hooks Hex socket botton cap bolt 1.
-
Page 11: Cordless Power Tool Battery Chargers
Do NOT place or attempt to charge lead acid, car type batteries in Hutch. Maintenance □ Lubricate the slides semi-annually with high-quality bearing grease. Periodically clean the drawer fronts, drawer trim, and other surfaces with a mild detergent and water. □ □ HUSKYTOOLS.COM 11 11 Please contact 1-888-HD-HUSKY for further assistance. -
Page 12: Replacement Parts
Replacement Parts For assistance with replacement parts please call 1-888-HD-HUSKY. HUTCH Part Description Quantity Badge Lock Outlet Outlet Panel Cover Rubber Grommet Storage Hook Storage Hook Bolt Shelf LED light and Cord Gas strut Shelf clip Cable clip RISER Part... - Page 13 Questions, problems, missing parts? Before returning to the store call Husky Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday 9 a.m. - 6 p.m., EST, Saturday 1-888-HD-HUSKY HUSKYTOOLS.COM Retain this manual for future use.
