Page 1: Operating Instructions
Advanced security made easy 7” LCD Screen with PNP-51 Operating Instructions SW346-7MC www.swannsecurity.com SR346-7MC-60100-131109... -
Page 2: Before You Begin
Before You Begin FCC Verification: NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are de- signed to provide reasonable protection against harmful interference in a residen- tial installation. -
Page 3: Table Of Contents
Table of Contents Before You Begin Table of Contents Package Contents Overview Layout of Remote Control Layout of Monitor and Camera Connection Guide Mounting Using the Menus Additional Functions Troubleshooting Technical Specifications Technical Support Warranty Information Package Contents 7” Color LCD Monitor and Accessories PNP-51 Camera and Stand Video Cable 3ft / 1m RCA Cable 60ft / 18m... -
Page 4: Overview
Overview Congratulations on your purchase of this Swann 7” Monitor and Camera package! You’ve chosen a simple and versatile monitoring system. Featuring both audio and video, this kit represents a great entry level monitoring solution. Additionally, the included PNP-51 features night vision, with a range of approximately 16 feet/5m. -
Page 5: Layout Of Monitor And Camera
Layout of Monitor and Camera POWER/MODE: Press and hold for three seconds to turn screen ON or OFF. Press once to switch between AV1 and AV2 in- puts. Controls: : Navigates in the menu system. VOL + / -: Increases or decreases the audio volume of the speakers or the headphone output. -
Page 6: Connection Guide
Connection Guide Connecting the PNP-51 to the 7” Monitor is a relatively straight forward operation. These devices are designed to be plug-and-play ready - so you just need to plug it all in! Plug the yellow and red RCA con- nections from the PNP-51 into exten- sion cable. - Page 7 Plug the 3.5mm end of the RCA to 3.5mm adaptor into one of the AV inputs on the monitor. RCA con- the DC +12V input on the monitor. The best way to connect a recording device to the system is to insert it between the RCA connections in step 1.
-
Page 8: Mounting
Mounting Mounting the Monitor: Included in the kit is a monitor stand. This can either be used to stand the monitor upon a table or other flat surface, or can be screwed to a wall or ceiling to mount the monitor more creatively. To assemble and use the included monitor stand: Mounting the PNP-51: •... -
Page 9: Using The Menus
Using the Menus Accessing the Menus The menus are accessed by pressing the MENU button on either the monitor or the remote control. Pressing MENU again will take you to the next submenu. These menus and their respective options are as follows: Picture Menu •... -
Page 10: Additional Functions
Additional Functions Changing the Aspect Ratio: How and Why key on the remote and the ZOOM function in the menu will make black bars appear on the sides of the monitor, squeezing the image to a size which mimics the shape of a standard television screen. Basically, if things in the picture seem ‘stretched’, then you’ve probably got a video signal which should be square which is being warped and distorted to fit the wider screen. -
Page 11: Troubleshooting
Troubleshooting Problem: At night, I only see a white screen. Solution: If the PNP-51 is looking through a window, the infrared light will ‘bounce back’ off the glass and effectively blind the camera. If you want to see outside, put the camera outside. -
Page 12: Warranty Information
Swann. The end user is responsible for all freight charges incurred to send the product to Swann’s repair centres. The end user is responsible for all shipping costs incurred when shipping from and to any country other than the country of origin.
