- Page 1 OPERATING AND MAINTENANCE MANUAL MOD. TR 70 - TR 75/E...
-
Page 2: Safety Standards
Thank you for choosing this machine. We are sure that its performance will meet your requi- rements. It is in your interest to keep the machine in perfect running order. In this handbook you will find the necessary instructions on how to use and service it. SAFETY STANDARDS Throughout the manual this symbol indica- tes important information warning you of... -
Page 3: Electrical Shock
WEAR ADEQUATE CLOTHING Be sure to wear tight-fitting clothing without any loose parts. Never wear open or unfaste- ned jackets, shirts or overalls. IMPORTANT To prevent accidents and ensure best performance the machine must not be modified or altered unless authorised by the manufacturer. Nor must it be used in conditions or for purposes other than those for which it has been expressly desi- gned. - Page 4 INDEX - SAFETY STANDARDS AND GENERAL WARNINGS page 16-17 - TECHNICAL SPECIFICATIONS OF MODELS page - INSTRUCTIONS page - 1. PREPARING THE MACHINE page - 2. OPERATING PRINCIPLE page - 3. USE OF THE MACHINE page 21-22 3.1 USEFUL ADVICE IN ORDER TO OBTAIN GOOD DOUGH page 3.2 QUANTITIES IN ORDER TO OBTAIN GOOD DOUGH page 22-23...
-
Page 5: Specifications Table
TECHNICAL SPECIFICATIONS OF MODEL TR 70 - TR 75/E SPECIFICATIONS TABLE Model Kneading Mass Motor Maximum production Length Width Height capacity power per hour daN/h (based on the kind ≅kg ≅kg of drawplate used) TR 70 0.38 TR 75/E 0.55... - Page 6 (only 75/E). drawplate. • Power: Model 1-phase standard power 1-phase optional power TR 70 230/50 Hz. 110/60 Hz. 220/60 Hz. 1-phase optional power TR 75/E Standard power supp. - three phase 400/50 Hz.
-
Page 7: Preparing The Machine
1. PREPARING THE MACHINE Prepare the machine before every pro- cess cycle. BE SURE that the machine, especially parts which come in contact with food products (extrusion sleeve, Archimedean screw, pool, mixer and draw- plate) are perfectly clean (see chapter 6 CLEANING on page 25). - Page 8 3.2 QUANTITIES IN ORDER TO OBTAIN GOOD DOUGH Pour the desired quantity of flour into the pool; it needs 7 eggs per kilo of flour: Model Flour kg. Number of eggs Grams of pasta product TR 70 1.350 1,2* 1.650 1.350 TR 75/E 2.700...
- Page 9 Add the liquid part pouring it slowly but quickly through the small hole in the cover. At the end of the kneading operation, which Fig. 4 - TR 70 Panel should take around 10 minutes, make sure the product has the right thickness and should look like coffee beans (check throu- gh the small holes of the cover).
-
Page 10: Installation & Connection
noodles (spaghetti or tagliatelle) and in the Remove straps, packing and polystyrene second case is especially short noodles strips. Dispose of this material according to the regulations in force. Lift the machine (macaroni, etc.). If the product is quite wet and tends to be and place on the installation site. - Page 11 (Fig. 11 ) the mixer rotates in a clockwise direction and the Archimedean screw must rotate in the same direction (check through the slots in the lid); for model TR 70, on the 70÷80 other hand, in the “drawplate position” 70÷80 (Fig.
- Page 12 • Mixer: make sure the external shovel is in the upper vertical position (Fig. 13 (only this position allows the disassem- bling of the piece). For model TR 70: remove the mixer, pull out the knob (Fig. 13 ) until the mixer disengages;...
-
Page 13: Maintenance And Adjustment
•remove power supply plug from power mains socket; •clean coated surfaces with soft cloth and disinfect with alcohol; •to clean internal parts of machine: - turn the machine and lay it down on a side; - clean the internal parts with the help of a soft cloth and blow with a compressed air jet. - Page 14 8. MACHINE WHIRR The whirring noise emitted by the machine has been measured on an identical sample machine in compliance with standard DIN 45635. A constant value not exceeding 70_dB(A) was measured as stated in the manufacturer’s test report. 9. DISMANTLING AND DEMOLISHING THE MACHINE If machine needs to be dismantled and/or demolished, its components do not entail a degree of danger that requires any particular precaution.
