EMAC VDX-6324 User Manual

Dm&p vortex86dx 800mhz half-size cpu module with 4s/4usb/vga/lcd/lan/gpio/pwmx16 256mb ddr2 onboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
To learn more about EMAC's products and services and how they can help your project
http://ftp.emacinc.com/Tech_Info/About_EMAC_Products_and_Services.pdf
Authorized Distributor, Integrator, and Value-Added Reseller
Manual downloaded from
ftp.emacinc.com
For purchase information please contact
info@emacinc.com
For technical support please submit a ticket at
www.emacinc.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VDX-6324 and is the answer not in the manual?

Questions and answers

Related Manuals for EMAC VDX-6324

Summary of Contents for EMAC VDX-6324

  • Page 1 To learn more about EMAC’s products and services and how they can help your project http://ftp.emacinc.com/Tech_Info/About_EMAC_Products_and_Services.pdf Authorized Distributor, Integrator, and Value-Added Reseller Manual downloaded from ftp.emacinc.com For purchase information please contact info@emacinc.com For technical support please submit a ticket at...
  • Page 2 Full 16-bit ISA Bus VDX-6324RD DM&P Vortex86DX 800MHz Half-Size CPU Module with 4S/4USB/VGA/LCD/LAN/GPIO/PWMx16 256MB DDR2 Onboard User’s Manual (Revision 1.2A)
  • Page 3 Copyright The information in this manual is subject to change without notice for continuous improvement in the product. All rights are reserved. The manufacturer assumes no responsibility for any inaccuracies that may be contained in this document. And makes no commitment to update or to keep current the information contained in this manual.

  • Page 4: Table Of Contents

    T a b l e C o n t e n t s T a b l e o f C o n t e n t s ............. iii C h a p t e r 1 Introduction……………………………………………1 Packing List ............1 Product Description ..........
  • Page 5 This page is blank...

  • Page 6: Chapter 1 Introduction

    C h a p t e r Introduction Packing List Product Name Package Embedded Vortex86DX CPU All-in-One Board Manual & Drivers CD x 1 RS232 cable x 3 PRINT cable x1 VDX-6324RD IDE cable x 1 USB cable x 2 (USB port x 2 GPIO cable x 1 Vortex86DX-6324RD...

  • Page 7: Product Description

    Product Description The VDX-6324RD family of low-power x86 embedded controller is designed to meet Half-Size specification with full 16-bit ISA Bus, and integrated with the following features.   800MHz Vortex86DX System-On-Chip Onboard 4MB SPI Flash   VGA, TFT/LVDS LCD support up to PC/104-Plus expansion bus ...

  • Page 8: Specifications

    Specifications Features VDX-6324RD DM&P SoC CPU Vortex86DX- 800MHz Real Time Clock with Lithium Battery Backup L1:16K I-Cache, 16K D-Cache, L2 Cache 128KB Cache AMI BIOS BIOS PC/104 Standard Compliant (Optional: PCI-104) Bus Interface 256 /512MB DDR2 onboard System Memory Software programmable from 30.5 us to 512 seconds x2 Watchdog Timer sets(W atchdog 1 fully compatible with M6117D) XGI Volari Z9s Chipset...
  • Page 9 2.54mm  26-pin box header for Print x1 Connectors 2.54mm  10-pin box header for RS-232 x3 2.54mm  10-pin box header for USB x2 2.54mm  20-pin box header for 16-bit GPIO x1 2.54mm  3-pin header for RS-485 x1 2.54mm ...

  • Page 10: Board Dimension

    Board Dimension Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 11: Chapter 2 Installation

    C h a p t e r 2 Installation Board Outline (Note1: COM2 RS232/422/485 is selected by BIOS setting) (Note2: PCI-104 connector is optional: VI/O setting: +5V only) Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 12: Connectors & Jumpers Location

    Connectors & Jumpers Location Connectors Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...
  • Page 13 Jumpers & LEDs Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 14: Connectors & Jumpers Summary

    Connectors & Jumpers Summary Summary Table Description Type of Connections Pin nbrs. 44-pin Box Header, 2.0 , 22x2 USB1 10-pin Box Header, 2.54 , 5x2 USB2 10-pin Box Header, 2.54 , 5x2 JTAG 6-pin Wafer, 1.25 , 6x1 Reset 2-pin Pin Header, 2,54,1x2 PS/2 Keyboard &...
  • Page 15 IDE- IDE Active LED (Green ) LED-SMD MTBF- MTBF-Out (Orange) LED-SMD CF1 Compact Flash 50-pin Type I/II CF Connector SP1 BUZZER Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 16: Pin Assignments & Jumper Settings

    Pin Assignments & Jumper Settings J1: IDE (44 Pins) Pin # Signal Name Pin # Signal Name IDERST IDED7 IDED8 IDED6 IDED9 IDED5 IDED10 IDED4 IDED11 IDED3 IDED12 IDED2 IDED13 IDED1 IDED14 IDED0 IDED15 IDEREQ IDEIOW IDEIOR ICHRDY IDEACK IDEINT IDESA1 IDECBLID IDESA0...
  • Page 17 J3: USB 2 Pin # Signal Name Pin # Signal Name LUSBD2- LUSBD3- LUSBD2+ LUSBD3+ GGND GGND J4: JTAG Pin # Signal Name Pin # Signal Name J5: RESET Pin # Signal Name Pin # Signal Name Reset J8: PS/2 KBD / Mouse Pin # Signal Name Pin # Signal Name KBCLK...
  • Page 18 J9: COM 1 (Optional: TTL/ GPIO-P4) Signal Signal Pin # Pin # Name Name DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 J10: COM2 RS232 / RS422 / RS485 (Optional: TTL) Pin # Signal Name Pin # Signal Name DCD2/ 422TX- / RS485- RXD2 / 422TX+ / RS485+ TXD2 / 422RX+ DTR2 / 422RX-...
  • Page 19 J12: RS485 (Auto direction) Pin # Signal Name RS485＋ RS485－ J17: Power Connector – 4-pin Header (P4 Molex 5mm) Signal Pin # Name +12V J18: Power Connector (Terminal Block 5.0mm) Pin # Signal Name J19: COM3 (Optional: TTL) Pin # Signal Name Pin # Signal Name DCD3 RXD3...
  • Page 20 J20: PRINT Pin # Signal Name Pin # Signal Name STB- AFD- ERR- INIT- SLIN- ACK- BUSY SLCT J21: COM4 (Optional: TTL) Pin # Signal Name Pin # Signal Name DCD4 RXD4 TXD4 DTR4 DSR4 RTS4 CTS4 Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...
  • Page 21 J22: PC104 Connector – 64pin Pin # Signal Name Pin # Signal Name IOCHCHK * RESETDRV IRQ9 DRQ2 -12V +12V IOCHRDY SMEMW * SA19 SMEMR * SA18 IOW * SA17 IOR * SA16 DACK3 * SA15 DRQ3 SA14 DACK1 * SA13 DRQ1 SA12...
  • Page 22 J24: PC104 Connector – 40pin Pin # Signal Name Pin # Signal Name MEMCS16 * SBHE * IOCS16 * SA23 IRQ10 SA22 IRQ11 SA21 IRQ12 SA20 IRQ15 SA19 IRQ14 SA18 DACK0 * SA17 DRQ0 MEMR * DACK5 * MEMW * DRQ5 DACK6 * DRQ6...
  • Page 23 J27: PC/104 + (Optional) VI/O setting: +5V only If you need to use VI/O as +3.3V, please use VDX-6324RD-FD-Plus Pin # AD00 VI/O(+5V) AD02 AD01 AD05 AD04 AD03 C/BE0# AD07 AD06 AD09 AD08 AD11 VI/O(+5V) AD10 AD14 AD13 AD12 +3.3V C/BE1# AD15 +3.3V...
  • Page 24 J28: VGA (D-Sub connector) Pin # Signal Name Pin # Signal Name R OUT G OUT B OUT DDCDAT HSYNC VSYNC DDCCLK J29: LCD Connector Pin # Signal Name Pin # Signal Name +3.3V +3.3V LCLK LHSYNC LVSYNC LBACKL LVDDEN (Please refer to Appendix A, for TFT Flat Panel Data Output) Vortex86DX-6324RD Vortex86DX...
  • Page 25 J30~J35: Display type setup (CRT /LCD) Connector Pin # Signal Name GPIOA GPIOB GPIOC GPIOD GPIOE GPIOF (Please refer to Appendix D, for Display type setup) J36: LAN Pin # Signal Name Pin # Signal Name Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...
  • Page 26 J37: LINE OUT (Optional) Pin # Signal Name LOUTR LOUTL J38: MIC-IN (Optional) Pin # Signal Name MICVREF MIC-IN J41: Console Redirection (Optional: Pin 1 & Pin 2 short) Pin # Signal Name Pin # Signal Name Console_Red Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 27: System Mapping

    System Mapping Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...
  • Page 28 Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...
  • Page 29 Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 30: Watchdog Timer

    Watchdog Timer There are two watchdog timers in Vortex86SX/DX CPU. One is compatible with M6117D watchdog timer and the other is new. The M6117D compatible watchdog timer is called WDT0 and new one is called WDT1. Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 31: Gpio

    GPIO (General Purpose Input / Output) 40 GPIO pins are provided by the Vortex86SX/DX for general usage in the system. All GPIO pins are independent and can be configured as inputs or outputs, with or without pull-up/pull-down resistors. Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 32: Spi Flash

    SPI flash (Serial Peripheral Interface) As SPI Flash Serial Peripheral Interface) offers many benefits including: reduced controller pin count, smaller and simpler PCBs, reduced switching noise, less power consumption, and lower system cost Many of users may consider using a formatted SPI flash to boot for the system or emulate SPI flash as Floppy (A: Driver or B: Driver).

  • Page 33: Pwm

    PWM (Pulse-width modulation) Pulse-width modulation (PWM) of a signal or power source involves the modulation of its duty cycle, to either convey information over a communications channel or control the amount of power sent to a load. The popular applications of pulse width modulation are in speed control of electric motors, volume control of Class D audio amplifiers or brightness control of light sources and many other power electronics applications.

  • Page 34: Ide To Sd

    IDE to SD (Micro-SD) Vortex86DX SoC also built-in simulation circuit to adapt SD to IDE in order to allow your system to recognize Micro-SD card as C: or D: Driver SD-1917: 44 pins IDE to SD Adapter is an ideal solution for industrial PC or embedded system and 44 pins IDE to SD Adapter can be easily installed on all Vortex86DX-63xx CPU boards.

  • Page 35: Chapter 3 Driver Installation

    C h a p t e r Driver Installation The Vortex86DX processor also use external Display chip ““Volari™ Z9s” which is an ultra low powered graphics chipset with total power consumption at around 1-1.5 W. It is capable in providing VGA display output upto 1600x1200. With DVO interface, developers could easily connect flat Panel to support TFT and LVDS output.

  • Page 36: Appendix

    Appendix TFT Flat Panel Data Output Vortex86DX-6324RD Vortex86DX Half-Size CPU Module...

  • Page 37: Tft Flat Panel Support List

    TFT Flat Panel Support List Size Brand Resolution Model No. 5.7” Data image 320x240 FG050701DSSWBG01 5.7” Optrex 320x240 55264GD057J-FW-ABN 5.7” TOSHIBA 320x240 LTA057A343F 5.7” Sharp 320x240 (QVGA / VGA) LQ057Q3DC02 5.7” Kyocera 320x240 (QVGA / VGA) TCG057QV1AC-G10 5.7” 320x240 (QVGA / VGA) PD057VU4 /U5 5.7”...
  • Page 38 Size Brand Resolution Model No. 8” 800x600 (TFT 24bits) A080SN01 V0 8.4” Sharp 800x600 LQ084S3DG01 10.4” 640x480 PD104VT1/VT2 10.4” 640x480 NL6448AC33-18 10.4” 640x480 NL6448AC33-29 10.4” 640x480 NL6448BC33-59 10.4” Sharp 640x480 LQ104V1DG51/DG61 10.4” Sharp 640x480 LQ10d368 11” Sharp 800x480 LQ110Y3DG01 12.1” 800x600 NL8060BC31-01 Vortex86DX-6324RD...

  • Page 39: Lvds Flat Panel Support List

    LVDS Flat Panel Support List If you would like to use LVDS Flat Panel with Vortex86SX / Vortex86DX series, please contact our regional sales to get ICOP-0096 information ICOP–0096 : 18-bit TFT to LVDS converter and Cable-LVDS-30: LVDS Cable 30cm Approved LVDS Flat Panel List Size Brand...

  • Page 40: Flat Panel Hardware Setting

    D. Flat Panel Hardware Setting: The Vortex86DX-6324RD offers the Hardware setting for the various TFT LCD Flat Panels support and please make sure the jumper setting (J30~J35) before you connect the LCD. Display type setup Connector Note: "C" means close; "X" means open Vortex86DX-6324RD Vortex86DX...

  • Page 41: Flat Panel Wiring And Lighting

    E. Flat Panel Wiring and Lighting  Hardware Before you connect the TFT LCD Flat Panel with Vortex86DX-6324RD, please make sure that the input Voltage of LCD is +3.3V or Not  BIOS Please contact or e-mail our regional sales to get the special BIOS for any TFT LCD Flat Panels.

  • Page 42: Tcp/Ip Library For Dos Real Mode

    TCP/IP library for DOS real mode DSock is a TCP/IP library for DOS real mode, which is used by RSIP. It provides simple C functions for programmer to write Internet applications. ICOP also provide Internet examples using DSock: BOOTP/DHCP, FTP server, SMTP client/server, HTTP server, TELNET server, Talk client/server, etc.

  • Page 43: Bios Default Setting

    BIOS Default setting If the system cannot be booted after BIOS changes are made, Please follow below procedures in order to restore the CMOS as default setting.  Press “End” Key, when the power on  Press <Del> to enter the AMI BIOS setup ...

  • Page 44: Warranty

    Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
