EMAC CFC2 User Manual

Pci eden400 half-sized sbc with sodimm/vga lcd/lvds/lan and cfc2
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PCI-6871
PCI Eden400 Half-sized SBC
with SODIMM/VGA
LCD/LVDS/LAN and CFC2
Users' Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CFC2 and is the answer not in the manual?

Questions and answers

Related Manuals for EMAC CFC2

Summary of Contents for EMAC CFC2

  • Page 1 PCI-6871 PCI Eden400 Half-sized SBC with SODIMM/VGA LCD/LVDS/LAN and CFC2 Users’ Manual...
  • Page 2 Acknowledgements Award is a trademark of Award Software International, Inc. VIA is a trademark of VIA Technologies, Inc. IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Corporation. Intel and Pentium are trademarks of Intel Corporation. Microsoft Windows® is a registered trademark of Microsoft Corp.

  • Page 3: Additional Information And Assistance

    • Product name and serial number • Description of your peripheral attachments • Description of your software (operating system, version, application software, etc.) • A complete description of the problem • The exact wording of any error messages Description LCD/LVDS/LAN and CFC2...
  • Page 4 PCI-6871 User’s Manual...

  • Page 5: Table Of Contents

    Table of Contents Chapter 1 General Information ...1 Introduction ... 2 Features ... 3 Specifications ... 3 1.3.1 1.3.2 1.3.3 1.3.4 1.3.5 Board layout: dimensions... 5 Chapter 2 Installation ...7 Jumpers... 8 Connectors... 8 Locating jumpers... 10 Locating Connectors ... 11 Setting Jumpers ...
  • Page 6 2.19.2 Flat panel display connector (CN18) ... 21 2.19.3 Extension flat panel connector (CN17) ... 21 2.19.4 LVDS LCD panel connector (CN21) ... 21 2.19.5 Panel type selection (S1)... 22 2.20 Ethernet configuration... 22 2.20.1 100Base-T connector (CN15)... 23 2.20.2 Network boot ... 23 2.20.3 LAN controller power select (JP2) ...
  • Page 7 Table of Contents 5.2.1 5.2.2 5.2.3 5.2.4 5.2.5 Further Information ... 73 Chapter 6 Audio Setup...75 Introduction ... 76 DOS utilities... 76 6.2.1 6.2.2 Driver installation... 77 6.3.1 6.3.2 6.3.3 6.3.4 Chapter 7 PCI Bus Ethernet Interface...93 Introduction ... 94 Installation of Ethernet driver ...
  • Page 8 C.14 CRT Display Connector (CN12)... 131 C.15 Flat Panel Connector (CN18)... 132 C.16 Extended Flat Panel Display Connector (CN17) ... 133 C.17 LCD Signal Mapping ... 134 C.18 LVDS Connector (CN21)... 135 C.19 COM Port Connector (CN19, CN20)... 136 C.20 CompactFlash Card Connector (CN28) ...

  • Page 9: Chapter 1 General Information

    General Information This chapter gives background information on the PCI-6871. Sections include: • Introduction • Features • Specifications • Board layout and dimensions Chapter 1 General Information...

  • Page 10: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Introduction The new PCI-6871 is a half-sized CPU card with onboard VIA Eden400 C3 EBGA fanless CPU. The VIA Eden processor uses advanced 0.13µ CMOS technology with 128KB L1 cache memory and 64KB L2 cache memory on die. This board with Eden400 CPU can operate without a fan at temperatures up to 60°...

  • Page 11: Features

    1.2 Features • Embedded low power VIA Eden C3 EGBA 400MHz processor • Half-sized CPU card with PCI golden finger • Fanless operation at 60° C. • 1 onboard RJ-45 connector supports 10/100Base-T Ethernet • 4X AGP graphics for high performance applications •...

  • Page 12: Vga/Lcd/Lvds Interface

    • Keyboard/mouse connector: Supports standard PC/AT keyboard and a PS/2 mouse • Power management: Supports power saving modes including Nor- mal/Standby/Suspend modes. APM 1.2 compliant • Watchdog timer: 62 level timer intervals • USB: Four universal serial bus ports • PC/104 expansion: PC/104 connector for ISA control board •...

  • Page 13: Board Layout: Dimensions

    1.4 Board layout: dimensions Figure 1.1: Board layout: dimensions (component side) Chapter 1 General Information...
  • Page 14 Figure 1.2: Board layout: dimensions (solder side) PCI-6871 User’s Manual...

  • Page 15: Chapter 2 Installation

    Installation This chapter explains the setup procedures of PCI-6871 hardware, including instruc- tions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure. Chapter 2 Installation...

  • Page 16: Jumpers

    Chapter 2 Installation 2.1 Jumpers The PCI-6871 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function CMOS clear LAN power select RS-232/422/485 select Watch-Dog output selct...
  • Page 17 Table 2.2: Connectors IR CON CN10 Audio I/F CN11 MAIN PWR CON CN12 D-SUB VGA CN13 HDD, PWR LED CON & WDT Output CN14 DIO CON CN15 LAN RJ45 CON CN16 PC104 CN17 LCD CON2 (10*2) CN18 LCD CON1 (20*2) CN19 COM1 CN20...

  • Page 18: Locating Jumpers

    2.3 Locating jumpers Figure 2.1: Jumper locations PCI-6871 User’s Manual...

  • Page 19: Locating Connectors

    2.4 Locating Connectors Figure 2.2: Connectors (component side) Chapter 2 Installation...

  • Page 20: Setting Jumpers

    2.5 Setting Jumpers You may configure your card to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric cir- cuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 21: Clear Cmos (Jp1)

    2.6 Clear CMOS (JP1) Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS.” Before turning on the power supply, set the jumper back to “3.0 V Battery On.” This jumper is used to erase CMOS data and reset system BIOS informa- tion.

  • Page 22: Installing System Memory (Sodimms)

    2.7 Installing system memory (SODIMMs) You can install anywhere from 32 to 512 MB of SDRAM into your PCI-6871 Se- ries card. The card provides two 144-pin SODIMM sockets. Each socket ac- cepts 32/64/128/256/512 MB 3.3 V power level SODIMMs. If only one SODIMM module is installed, it may be installed in either SODIMM socket on the solder side of the PCI-6871 Series card.

  • Page 23: Ide, Cdrom Hard Drive Connector (Cn1, Cn7)

    Important: Only use standard form SODIMM memory modules (as shown in the diagram below). Standardized dimensions ensure a proper fit. Check with your memory supplier about the SODIMM modules you will use. 2.8 IDE, CDROM hard drive connector (CN1, CN7) The PCI-6871 provides 2 IDE channels which you can attach up to four Enhanced Integrated Device Electronics hard disk drives or CDROM to the PCI-6871’s internal controller.

  • Page 24: Connecting The Hard Drive

    2.8.1 Connecting the hard drive Connecting drives is done in a daisy-chain fashion. It requires one of two cables (not included in this package), depending on the drive size. 1.8" and 2.5" drives need a 1 x 44-pin to 2 x 44-pin flat-cable connector. 3.5" drives use a 1 x 44-pin to 2 x 40-pin connector.

  • Page 25: Connecting The Floppy Drive

    2.10.1 Connecting the floppy drive Plug the 34-pin flat-cable connector into CN6. Make sure that the red wire corresponds to pin one on the connector. Attach the appropriate connector on the other end of the cable to the floppy drive(s). You can use only one connector in the set. The set on the end (after the twist in the cable) connects to the A: drive.

  • Page 26: Power & Hdd Led, Reset (Cn13, Cn8)

    standard PC/AT BIOS will report an error or fail during power-on self- test (POST) after a reset. The PCI-6871’s BIOS standard setup menu allows you to select “All, But Keyboard” under the “Halt On” selection. This allows no-keyboard operation in embedded system applications, without the system halting under POST.

  • Page 27: Atx Power Control Connector (Cn3, Cn5)

    2.15 ATX power control connector (CN3, CN5) 2.15.1 ATX feature connector (CN3) and soft power switch connector (CN5) The PCI-6871 can support an advanced soft power switch function, if an ATX power supply is used. To enable the soft power switch function: Get the specially designed ATX-to-EBX power cable (PCI-6871 optional item, part no.

  • Page 28: Ir Connector (Cn9)

    2.16 IR connector (CN9) This connector supports the optional wireless infrared transmitting and receiving module. This module mounts on the system case. You must configure the setting through BIOS setup. 2.17 Audio interfaces (CN10) The Audio link is a 10 pin connector; the PCI-6871 can support AC97 Audio with the addition of optional PCM-231A-00A1.

  • Page 29: Crt Display Connector (Cn12)

    2.19.1 CRT display connector (CN12) CN12 is a standard 15-pin D-SUB connector commonly used for VGA. The pin assignments for CRT display connector CN12 are detailed in Appendix C. 2.19.2 Flat panel display connector (CN18) CN18 consists of a 40-pin connector which can support a 24-bit LCD panel.

  • Page 30: Panel Type Selection (S1)

    2.19.5 Panel type selection (S1) S1 is an 8 segment DIP switch for DSTN/TFT panel type and resolution functions. Table 2.4: S1 Panel Type select OFF ON OFF OFF OFF ON OFF ON OFF OFF ON OFF OFF OFF OFF ON OFF OFF OFF ON OFF ON...

  • Page 31: 100Base-T Connector (Cn15)

    2.20.1 100Base-T connector (CN15) CN15 is an RJ-45 connector with LED.. 2.20.2 Network boot The Network Boot feature can be utilized by incorporating the Boot ROM image files for the appropriate network operating system. The Boot ROM BIOS files are included in the system BIOS, which is on the utility CD disc.

  • Page 32: Usb Connectors (Cn4, Cn23)

    Table 2.6: Watchdog timer action (JP4) *System reset * default setting 2.22 USB connectors (CN4, CN23) The PCI-6871 board provides up to four USB (Universal Serial Bus) ports, with USB3 and USB4 optional. This gives complete Plug and Play, and hot attach/detach for up to 127 external devices. The USB interfaces comply with USB specification Rev.
  • Page 33 Software Configuration This chapter details the software configura- tion information. It shows you how to config- ure the card to match your application requirements. The AWARD System BIOS is covered in Chapter 4. Sections include: • Introduction • Connections for standard LCDs •...

  • Page 34: Chapter 3 Software Configuration

    Chapter 3 Software Configuration 3.1 Introduction The PCI-6871 system BIOS and custom drivers are located in a 256 Kbyte, Flash ROM device, designated U18. A single Flash chip holds the system BIOS, VGA BIOS and network Boot ROM image. The display can be configured via CMOS settings.

  • Page 35: Connections To Three Standard Lcds

    3.2 Connections to Three Standard LCDs The following tables illustrate typical LCD connection pinouts for the PCI-6871. 3.2.1 Connections to Toshiba LTM10C209A Table 3.1: Connections to Toshiba LTM10C209A LTM10C209A Name ENAB (640 x 480 TFT color LCD) PCI-6871 CN18 Name SHFCLK M/DE Chapter 3 Software Configuration...

  • Page 36: Connections To (1024 X 768 Tft Color Lcd)

    Table 3.1: Connections to Toshiba LTM10C209A 3.2.2 Connections to Toshiba LTM15C151A Table 3.2: Connections to Toshiba LTM15C151A Name CN1-1 CN1-2 NCLK CN1-3 CN1-4 CN1-5 CN1-6 CN1-7 CN1-8 CN1-9 CN1-10 CN1-11 CN1-12 CN1-13 CN1-14 CN1-15 CN1-16 CN1-17 CN1-18 CN1-19 CN1-20 CN1-21 CN1-22 CN1-23 CN1-24...

  • Page 37: Connections To (800 X 600 Tft Color Lcd)

    Table 3.2: Connections to Toshiba CN1-25 CN1-26 ENAB CN1-27 CN1-28 CN1-29 CN1-30 3.2.3 Connections to Toshiba LTM12C275A Table 3.3: Connections to Toshiba LTM12C275A LTM12C275A Name NCLK LTM15C151A CN 10-13 PD34 CN 11-37 M/DE CN 11-34 CN 11-1 CN 11-2 CN 11-8 (800 x 600 TFT color LCD) PCI-6871 CN18 Name...

  • Page 38: Ethernet Software Configuration

    Table 3.3: Connections to Toshiba LTM12C275A ENAB 3.3 Ethernet software configuration The PCI-6871’s on-board Ethernet interface supports all major network operating systems. To configure the medium type, to view the current configuration, or to run diagnostics, do the following: Power the PCI-6871 on. Make sure that the RSET8139.EXE file is located in the working drive.
  • Page 39 Note For Ethernet installation, please see Chapter 7 Chapter 3 Software Configuration...
  • Page 40 PCI-6871 User’s Manual...
  • Page 41 Chapter 4 Ducks that Need Love! Award BIOS Setup This chapter describes how to set BIOS configuration data. Chapter 4 Award BIOS Setup...

  • Page 42: Chapter 4 Award Bios Setup

    Chapter 4 Award BIOS Setup 4.1 System test and initialization These routines test and initialize board hardware. If the routines encoun- ter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal.

  • Page 43: Award Bios Setup

    4.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 4.2.1 Entering setup Power on the computer and press <Del>...

  • Page 44: Standard Cmos Features Setup

    4.2.2 Standard CMOS Features setup When you choose the Standard CMOS Features option from the Initial Setup Screen menu, the screen shown below is displayed. This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is high- lighted, on-line help information is displayed in the left bottom of the Menu screen.

  • Page 45: Advanced Bios Features Setup

    4.2.3 Advanced BIOS Features setup By choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6871 Series. Figure 4.3: Advanced BIOS Features setup Chapter 4 Award BIOS Setup...

  • Page 46: Advanced Chipset Features Setup

    4.2.4 Advanced Chipset Features setup By choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6871 Series. Figure 4.4: Advanced Chipset Features setup PCI-6871 User’s Manual...

  • Page 47: Integrated Peripherals

    4.2.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below. Here we see the manufacturer’s default values for the PCI-6871 Series. Figure 4.5: Integrated Peripherals 4.2.6 Power Management Setup By choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed.

  • Page 48: Pnp/Pci Configurations

    4.2.7 PnP/PCI Configurations By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6871 Series. Figure 4.7: PnP/PCI Configurations 4.2.8 PC Health Status The PC Health Status option displays information such as CPU and moth- erboard temperatures, fan speeds, and core voltage.

  • Page 49: Frequency/Voltage Control

    4.2.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6871 Figure 4.9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.

  • Page 50: Load Optimized Defaults

    4.2.10 Load Optimized Defaults Load Optimized Defaults loads the default system values directly from ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load auto- matically when you turn the PCI-6871 Series system on. Figure 4.10: Load BIOS defaults screen 4.2.11 Set Password Note...

  • Page 51: Save & Exit Setup

    At the “Confirm Password” prompt, retype the desired password, then press <Enter>. Select Save to CMOS and EXIT, type <Y>, then <Enter>. To Change Password Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,”...

  • Page 52: Exit Without Saving

    4.2.13 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the Setup pro- gram without recording any new values or changing old ones. PCI-6871 User’s Manual...
  • Page 53 PCI SVGA Setup • Introduction • Installation of SVGA drivers -for Windows 95/98/Me -for Windows NT/2000/XP • Further information Chapter 5 PCI SVGA Setup...

  • Page 54: Chapter 5 Pci Svga Setup

    (color and monochrome VGA) in high-resolution modes while maintaining complete IBM VGA compatibility. Digital monitors (i.e. MDA, CGA, and EGA) are NOT supported. Multiple frequency (multisync) monitors are handled as if they were analog monitors.

  • Page 55: Dual/Simultaneous Display

    5.1.4 Dual/Simultaneous Display The PCI-6871 uses a VIA Twister VT8606T LCD controller that is capa- ble of providing simultaneous dual view display of the same content on a flat panel and CRT. To set up dual view (simultaneus mode) under Windows 9x, Windows ME, Windows NT/2000/XP, follow these steps: Step 1.

  • Page 56: Installation Of The Svga Driver

    5.2 Installation of the SVGA Driver Complete the following steps to install the SVGA driver. Follow the pro- cedures in the flow chart that apply to the operating system that you are using within your PCI-6871. Notes: 1. The windows illustrations in this chapter are intended as examples only.
  • Page 57 Step 2. Choose the "Adapter" tab, then press the "Change..." button. Step 3. Press the "Have Disk" button. Chapter 5 PCI SVGA Setup...
  • Page 58 Step 4. Type in the path: D:\slotPC\6871\VGA\Win9x_Me D:\slotPC\6871\VGA\Win9x_Me Step 5. Select the highlighted item, and click the "OK" button. PCI-6871 User’s Manual...
  • Page 59 Step 6. "S3 GraphicsTwister" appears under the adapter tab. Click the "Apply" button, then the "OK" button. Step 7. Press “Yes” to reboot. Chapter 5 PCI SVGA Setup...

  • Page 60: Installation For Windows 98/Me

    5.2.2 Installation for Windows 98/Me Step 1. Select "Start", "Settings", "Control Panel", "Display", and "Set- tings," then press the "Advanced..." button. PCI-6871 User’s Manual...
  • Page 61 Step 2. Select “Adapter,” then “Change.” Chapter 5 PCI SVGA Setup...
  • Page 62 Step 3. Press “Next,” then “Display a list...” Step 4. Press the “Have disk...” button. PCI-6871 User’s Manual...
  • Page 63 Step 5. Insert the CD into the CD-ROM drive. Type in the path D:\slotPC\6871\VGA\Win9x_Me Then press “OK” D:\slotPC\6871\VGA\Win9x_Me Step 6. Select the highlighted item, then click “OK.” Chapter 5 PCI SVGA Setup...
  • Page 64 Step 7. "S3 Graphics Twister"appears under the adapter tab. Click the "Apply" button. Step 8. Press “Yes” to reboot. PCI-6871 User’s Manual...

  • Page 65: Installation For Windows Nt

    5.2.3 Installation for Windows NT Note: Service Pack X (X = 3, 4, 5, 6,...) must be installed first, before you install the Windows NT VGA driver. Step 1. Select "Start", "Settings", "Control Panel" and double click the "Display" icon. Chapter 5 PCI SVGA Setup...
  • Page 66 Step 2. Choose the "Settings" tab, and press the "Display Type" button. PCI-6871 User’s Manual...
  • Page 67 Step 3. Press the "Change..." button. Chapter 5 PCI SVGA Setup...
  • Page 68 Step 4. Click the "Have Disk..." button. Step 5. Type the path: D:\slotPC\VGA\WinNT Press the "OK" button. D:\slotPC\VGA\WinNT PCI-6871 User’s Manual...
  • Page 69 Step 6. Select the highlighted item, and click the "OK" button. Step 7. Press "Yes" to proceed. Step 8. Press "OK" to reboot. Chapter 5 PCI SVGA Setup...

  • Page 70: Installation For Windows 2000

    5.2.4 Installation for Windows 2000 Step 1. Select "System", "Settings", "Control Panel" and double click the "system" icon. PCI-6871 User’s Manual...
  • Page 71 Step 2. Choose the "Video Controller (VGA Compatible)” button. Chapter 5 PCI SVGA Setup...
  • Page 72 Step 3. Choose the "Drive" button, press “Update Driver...” button. PCI-6871 User’s Manual...
  • Page 73 Step 4. Choose "Display a list of..." , then press “Next” button. Step 5. Choose “Display adapters”, press “Next” button. Chapter 5 PCI SVGA Setup...
  • Page 74 Step 6. Click the “Have Disk” button. Step 7. Type the path D:\slotPC\6871\VGA\Win2000 press the “OK” button. D:\slotPC\VGA\Win2000 PCI-6871 User’s Manual...

  • Page 75: Installation For Windows Xp

    Step 8. Press “Finish" to reboot. 5.2.5 Installation for Windows XP Step 1. Select "System", "Settings", "Control Panel" and double click the "system" icon. Chapter 5 PCI SVGA Setup...
  • Page 76 Step 2. Choose “Hardware” and “Device Manager”, press “OK” button. PCI-6871 User’s Manual...
  • Page 77 Step 3. Choose “Video Controller (VGA Compatible), press “OK” but- ton. Chapter 5 PCI SVGA Setup...
  • Page 78 Step 4. Choose "Driver”, “Update Driver”, press “OK” button. Step 5. Choose “Install from a list...” , press “Next”. PCI-6871 User’s Manual...
  • Page 79 Step 6. Choose “Don’t search. I will...”, press “Next” button. Step 7. Choose “Display adapters”, press “Next” button. Chapter 5 PCI SVGA Setup...
  • Page 80 Step 8. Type the path D:\slotPC\6871\VGA\WinXP then press “OK” button. D:\slotPC\6871\VGA\Win2000 Step 9. Choose “S3 Graphics Twister + S3 Hotkey” then press “Next” button. PCI-6871 User’s Manual...

  • Page 81: Further Information

    Step 10. Press “Finish" to reboot. 5.3 Further Information For further information about the AGP/VGA installation in your PCI- 6871, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: VIA website: www.via.com.tw manufacturers website: www.emacinc.com Chapter 5 PCI SVGA Setup...
  • Page 82 PCI-6871 User’s Manual...
  • Page 83 Audio Setup The PCI-6871 is equipped with an audio interface that records and plays back CD-quality audio. This chapter provides instructions for installing the software drivers included on the audio driver diskettes. Chapter 6 Audio Setup...

  • Page 84: Chapter 6 Audio Setup

    Chapter 6 Audio Setup 6.1 Introduction The PCI-6871 supports AC97 audio through the optional audio module PCM-231A-00A1. 6.2 DOS utilities 6.2.1 VIA Sound Blaster Pro compatible set up program Please "Enable" the Sound Blaster setting in the BIOS before playing Sound Blaster compatible DOS games.

  • Page 85: Driver Installation

    Step 3. The program will copy the relative files into the directory which you assign. Next, the program will insert the following new line into the AUTOEXEC.BAT and copy the original AUTOEXEC.BAT to AUTOEXEC.VIA. C: \VIAUDIO\VIAUDIO.COM Step 4. Reboot the system when the installation is complete. Step 5.
  • Page 86 Step 1. Click "Start" and select "Settings". Click "Control Panel" and double-click "Add New Hardware". Step 2. In the Add New Hardware Wizard window, click "Next". PCI-6871 User’s Manual...
  • Page 87 Step 3. In the following Add New Hardware Wizard window, click "Next" for Windows to search for Plug and Play devices. Step 4. In the following Add New Hardware Wizard window, select "No, the device isn't in the list."and click "Next". Chapter 6 Audio Setup...
  • Page 88 Step 5. In the following Add New Hardware Wizard window, select "No, I want to select..." and click "Next". Step 6. In the following Add New Hardware Wizard window, select "Sound, video and game controllers" and click "Next". PCI-6871 User’s Manual...
  • Page 89 Step 7. In the following Add New Hardware Wizard window, click "Have Disk...". Step 8. In the Install From Disk window, click "Browse". Chapter 6 Audio Setup...
  • Page 90 Step 9. In the Open window, select "D:\slotPC\6871\Audio\98se_Me_2k_xp\WIN95_98. Step 10. In the Install From Disk window, click" OK". \6871\Audio\98se_Me_2K_XP\WIN95_98 PCI-6871 User’s Manual...
  • Page 91 Step 11. In the Select Device window, select "VIA PCI Audio Controller (WDM)" and click "OK". Step 12. In the Add New Hardware Wizard window, click "Next". Chapter 6 Audio Setup...
  • Page 92 Step 13. The Copying Files... window will appear. Step 14. In the Add New Hardware Wizard window, click "Finish". Then reboot the system. PCI-6871 User’s Manual...

  • Page 93: Windows Nt Drivers

    6.3.3 Windows NT drivers Step 1. Click "Start" and select "Settings". Click "Control Panel" and double-click "Multimedia". Step 2. In the Multimedia Properties window, select the "Devices" tab. Then select the "Audio Devices" item, and click "Add...". Chapter 6 Audio Setup...
  • Page 94 Step 3. In the Add window, select the "Unlisted..." item and click "OK". Step 4. When the Install Driver window appears, insert the utility disc into the CD-ROM drive. Type: D:\slotPC\6871\Audio\WinNT\ Then click "OK". D:\slotPC\6871\Audio\WinNT PCI-6871 User’s Manual...
  • Page 95 Step 5. In the Add Unlisted or Updated Driver window, select the "VIA PCI Audio controller" item. Then click "OK". Step 6. In the System Setting Change window, click "Restart Now". Chapter 6 Audio Setup...

  • Page 96: Windows 2000 Drivers

    6.3.4 Windows 2000 Drivers Step 1. Select “System”, “Setting”, “Control Panel” and double click “system” icon. Step 2. Choose “Multimedia Audio Controller” button. PCI-6871 User’s Manual...
  • Page 97 Step 3. Choose “Driver button, press “Update Driver” button. Step 4. Choose “Sound, video and game controllers”, press “Next” Chapter 6 Audio Setup...
  • Page 98 Step 5. Click the “Have Disk...” button Step 6. Type the path D:\slotPC\6871\Audio\98se_Me_2k_xp\Win2000 press the “ok” button. Step 7. Click “Have Disk” button PCI-6871 User’s Manual...
  • Page 99 Step 8. Press “Next” button Step 9. Press “Finish” to reboot Chapter 6 Audio Setup...
  • Page 100 PCI-6871 User’s Manual...
  • Page 101 PCI Bus Ethernet Inter- face This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet drivers for Windows 98/2000/NT • Further information Chapter 7 PCI Bus Ethernet Interface...

  • Page 102: Chapter 7 Pci Bus Ethernet Interface

    If you want to set up your Ethernet connection under the MS-DOS or Windows 3.1 environment, you should first check your server system model. For example, MS-NT, IBM-LAN server, and so on. Then choose the correct driver to install in your biscuit PC.

  • Page 103: Installation For Windows 98

    7.2.2 Installation for Windows 98 Step 1. a. Select "Start", "Settings". "Control Panel". b. Double click "Network". Step 2. a. Click "Add" and prepare to install network functions. Chapter 7 PCI Bus Ethernet Interface...
  • Page 104 Step 3. a. Select the "Adapter" item to add the Ethernet card. Step 4. a. Click "Have Disk" to install the driver. Step 5. a. Insert the CD into the D: drive b. Fill in "D:\slotPC\6871\LAN\” c. Click "OK" D:\slotPC\6871\LAN\ PCI-6871 User’s Manual...
  • Page 105 Step 6. a. Choose the "Realtek RTL8139(A/B/C/8130) PCI Fast Ethernet" item. b. Click "OK". Step 7. a. Make sure the configurations of relative items are set correctly. b. Click "OK" to reboot. Chapter 7 PCI Bus Ethernet Interface...

  • Page 106: Installation For Windows 2000

    7.2.3 Installation for Windows 2000 Step 1. Open Device Manager, PCI-6871 User’s Manual...
  • Page 107 Step 2. Chapter 7 PCI Bus Ethernet Interface...
  • Page 108 Step 3. Step 4. PCI-6871 User’s Manual...
  • Page 109 Step 5. Step 6. Chapter 7 PCI Bus Ethernet Interface...
  • Page 110 Step 7. Step 8. PCI-6871 User’s Manual...

  • Page 111: Installation For Windows Nt

    Step 9. 7.2.4 Installation for Windows NT Step 1. a. Select "Start", "Settings", "Control Panel" b. Double click "Network" Step 2. a. Choose type of network. Chapter 7 PCI Bus Ethernet Interface...
  • Page 112 b. Click "Next" Step 3. a. Click "Select from list..." PCI-6871 User’s Manual...
  • Page 113 Step 4. Click “Have Disk.” Step 5. a. Insert the Utility CD ROM b. Fill in the correct path: D:\slotPC\6871\LAN\8139C\winnt4 c. Click "OK". D:\slotPC\6871\LAN\8139C\WinNT4 Chapter 7 PCI Bus Ethernet Interface...
  • Page 114 Step 6. Check the highlighted item, and click “OK.” PCI-6871 User’s Manual...
  • Page 115 Click “Next” to continue setup. Step 8. Choose the networking protocols, then click "Next" Chapter 7 PCI Bus Ethernet Interface...
  • Page 116 Step 9. Select the correct Network Services then click "Next" Step 10. Click “Next” to continue setup. PCI-6871 User’s Manual...

  • Page 117: Further Information

    Click “Next” to start the network. 7.3 Further information Realtek website: Intel website: Manufacturer's website: www.realtek.com.tw www.intel.com www.emacinc.com Chapter 7 PCI Bus Ethernet Interface...
  • Page 118 PCI-6871 User’s Manual...
  • Page 119 Programming the Watchdog Timer The PCI-6871 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned envi- ronments.

  • Page 120: Appendix A Programming The Watchdog Timer

    Appendix A Programming the Watchdog Timer A.1 Supported Input Timing Modes In order to program the watchdog timer, you must write a program which writes I/O port address 443 (hex). The output data is a value of time inter- val. The value range is from 01 (hex) to 3E (hex), and the related time interval is 1 sec.
  • Page 121 The following example shows how you might program the watchdog timer in BASIC: REM Watchdog timer example program OUT &H443, data watchdog GOSUB 1000 OUT &H443, data GOSUB 2000 OUT &H443, data X=INP (&H443) 1000 Subroutine #1, your application task 1070 RETURN 2000...
  • Page 122 PCI-6871 Users’ Manual...

  • Page 123: Appendix B Installing Pc/104 Modules

    Installing PC/104 Modules This appendix gives instructions for installing PC/104 modules. Appx. B...
  • Page 124 Appendix B Installing PC/104 Modules B.1 Installing PC/104 Modules The PCI-6871's PC/104 connectors give you the flexibility to attach PC/ 104 modules. Installing these modules on the PCI-6871 is quick and simple. The fol- lowing steps show how to mount the PC/104 modules: Remove the PCI-6871 from your system, paying particular atten- tion to the safety instructions already mentioned above.
  • Page 125 PC/104 Mounting Support Male Female PCI-6871 Series PC/104 module PC/104 module PCA-6751 Series Figure B.1: PC/104 module mounting diagram Appx. B...
  • Page 126 Figure B.2: PC/104 module dimensions (mm) (±0.1) PCI-6871 Users’ Manual...
  • Page 127 Table B.1: PCI-6871 Series PC/104 connectors (CN16) Signal (CN16) Number Row A — IOCHCHK* IOCHRDY SA19 SA18 SA17 SA16 SA15 SA14 SA13 SA12 SA11 SA10 Row B Row C — SBHE* RESETDRV LA23 +5 V LA22 IRQ9 LA21 -5 V LA20 DRQ2 LA19...
  • Page 128 Table B.1: PCI-6871 Series PC/104 connectors (CN16) Signal (CN16) Number Row A *active low PCI-6871 Users’ Manual Row B Row C IRQ6 — IRQ5 — IRQ4 — IRQ3 — DACK2* — — BALE — +5 V — — — — Row D —...
  • Page 129 Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • CPU Fan Power Connector • Ethernet 10/100Base-T Connector • Audio Connector • Main Power Connector • Keyboard and PS/2 Mouse Connector • Floppy Drive Connector •...

  • Page 130: Appendix C Pin Assignments

    Appendix C Pin Assignments C.1 CPU Fan Power Connector (FAN 1) Table C.1: CPU Fan Power Connector (FAN 1) Signal Fan speed signal input C.2 Ethernet 10/100Base-T Connector (CN15) Table C.2: Ethernet 10/100Base-T connector (CN15) Signal PCI-6871 User’s Manual...

  • Page 131: Audio Connector (Cn10)

    C.3 Audio Connector (CN10) Table C.3: Audio connector (CN10) Signal DATA in DATA out Signal BitCLK SYNC ACRST reserved Appx. C...

  • Page 132: Main Power Connector (Cn11)

    C.4 Main Power Connector (CN11) Table C.4: Main Power Connector (CN11) Signal +5 V +5 V PCI-6871 User’s Manual...

  • Page 133: Keyboard And Ps/2 Mouse Connector (Cn25)

    C.5 Keyboard and PS/2 Mouse Connector (CN25) Table C.5: Keyboard and mouse connector (CN25) Signal KB CLOCK KB DATA MS CLOCK +5V (KB VCC) MS DATA Appx. C...

  • Page 134: Floppy Disk Drive Connector (Cn6)

    C.6 Floppy Disk Drive Connector (CN6) Table C.6: Floppy Disk Drive Connector (CN6) Signal *low active PCI-6871 User’s Manual Signal DENSITY SELECT* DRIVE TYPE INDEX* MOTOR O* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA*...

  • Page 135: Ide Hard Drive Connector (Cn1, Cn7)

    C.7 IDE Hard Drive Connector (CN1, CN7) Table C.7: IDE HDD connector (CN1, CN7) Signal IDE RESET* DATA 7 DATA 6 DATA 5 DATA 4 DATA 3 DATA 2 DATA 1 DATA 0 SIGNAL GND HDD 0 IO WRITE IO READ HD READY HDACK 0* IRQ14...

  • Page 136: Parallel Port Connector (Cn2)

    C.8 Parallel Port Connector (CN2) Table C.8: Parallel Port Connector (CN2) Signal STROBE* ACK* BUSY SLCT * low active PCI-6871 User’s Manual Signal AUTOFD* INIT* SLCTINI*...

  • Page 137: Hdd, Pwr Led Con & Wdt Output (Cn13)

    C.9 HDD, PWR LED CON & WDT output (CN13) Table C.9: HDD, PWR LED CON & WDT output (CN13) Signal WDT output power LED+ (+5V) HDD LED + power LED - (GND) HDD LED - C.10 Reset Button Connector (CN8) Table C.10: Reset Button Connector (CN8) Signal Reset signal input...

  • Page 138: Usb Connector (Cn20, Cn28)

    C.11 USB Connector (CN20, CN28) Table C.11: USB Connector (CN20, CN28) Signal +5 V Chassis GND C.12 LCD Inverter Backlight Connector (CN27) Table C.12: LCD Inverter Backlight Connector (CN27) Signal +12 V ENABKL +5 V PCI-6871 User’s Manual Signal +5 V...

  • Page 139: C.13 Ir Connector (Cn9)

    C.13 IR Connector (CN9) Table C.13: IR Connector (CN9) Signal VCC (5 V) N.C. C.14 CRT Display Connector (CN12) Table C.14: CRT Display Connector (CN12) Signal GREEN BLUE Signal S-DATA H-SYNC V-SYNC S-CLK Appx. C...

  • Page 140: Flat Panel Connector (Cn18)

    C.15 Flat Panel Connector (CN18) Table C.15: Flat Panel Connector (CN18) Signal VDDSAFE5 (+5v output) VDDSAFE3 (+3.3 v SHFCLK M/DE Note: The model number of the CN18 socket is DF13A-40DP-1.25V (Hirose Electric Co., Ltd.) PCI-6871 User’s Manual output) Signal VDDSAFE5 (+5v output) VDDSAFE3 (+3.3 v output) ENAVEE...

  • Page 141: Extended Flat Panel Display Connector (Cn17)

    C.16 Extended Flat Panel Display Connector (CN17) Table C.16: Extended Flat Panel Display Connector (CN17) Signal Note: The model number of the CN17 socket is DF13A-20DP-1.25V (Hirose Electric Co., Ltd.) Signal Appx. C...

  • Page 142: Lcd Signal Mapping

    C.17 LCD Signal Mapping Table C.17: LCD Signal Mapping 16-bit Name DSTN PD10 PD11 PD12 PD13 PD14 PD15 PD16 PD17 PD18 PD19 PD20 PD21 PD22 PD23 PD24 PD25 PD26 PD27 PD28 PD29 PD30 PD31 PD32 PD33 PD34 PD35 PCI-6871 User’s Manual 24-bit 18-bit DSTN...

  • Page 143: Lvds Connector (Cn21)

    C.18 LVDS Connector (CN21) Table C.18: LVDS Connector (CN21) Signal TX0+(Channel 1) TX0-(Channel 1) TX1+(Channel 1) TX1-(Channel 1) TX2+(Channel 1) TX2-(Channel 1) TX3+(Channel 1) TX3-(Channel 1) VDD (+3.3V) Signal TX0+(Channel 2) TX0-(Channel 2) TX1+(Channel 2) TX1-(Channel 2) TX2+(Channel 2) TX2-(Channel 2) TX3+(Channel 2) TX3-(Channel 2) VDD (+3.3V)

  • Page 144: Com Port Connector (Cn19, Cn20)

    C.19 COM Port Connector (CN19, CN20) Table C.19: COM Port Connector (CN19, CN20) Signal RLSD1 (DCD1) DTR1 RLSD2 (DCD2) DTR2 RLSD3 (DCD3) DTR3 RLSD4 (DCD4) DTR4 PCI-6871 User’s Manual Signal DSR1 RTS1 CTS1 DSR2 RTS2 CTS2 DSR3 RTS3 CTS3 DSR4 RTS4 CTS4...

  • Page 145: Compactflash Card Connector (Cn28)

    C.20 CompactFlash Card Connector (CN28) Table C.20: CompactFlash Card Connector (CN28) Signal *CS0 *ATA SEL +5 V *CD2 *VS1 *IOWR INTRQ *CSEL *RESER *INPACK *DASP * low active Signal -IOCS16 -CD1 -CS1 -IORD +5 V -VS2 IORDY -REG -PDIAG Appx. C...

  • Page 146: Atx Power Feature Connector (Cn3)

    C.21 ATX Power Feature Connector (CN3) Table C.21: ATX Power Feature Connector (CN3) Signal 5VSB (Stand by voltage) PS. ON# C.22 LCD Backlight Connector (CN24) Table C.22: ATX Power Feature Connector (CN24) Signal to VR pin 1 to VR pin 2 to VR pin 3 PCI-6871 User’s Manual...

  • Page 147: External Keyboard Connector (Cn26)

    C.23 External Keyboard Connector (CN26) Table C.23: External Keyboard Connector (CN26) Signal DATA Appx. C...
  • Page 148 PCI-6871 User’s Manual...
  • Page 149 System Assignments This appendix contains information of a detailed nature. It includes: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments Appx. D...

  • Page 150: D.1 System I/O Ports

    Appendix D System Assignments D.1 System I/O Ports Table D.1: System I/O ports Addr. range (Hex) 000-01F 020-021 040-05F 060-06F 070-07F 080-09F 0A0-0BF 0C0-0DF 0F8-0FF 1F0-1F8 200-207 278-27F 2E8-2EF 2F8-2FF 300-31F 360-36F 378-37F 380-38F 3A0-3AF 3B0-3BF 3C0-3CF 3D0-3DF 3E8-3EF 3F0-3F7 3F8-3FF * PNP audio I/O map range from 220 ~ 250H (16 bytes) MPU-401 select from 300 ~ 330H (2 bytes)

  • Page 151: 1St Mb Memory Map

    D.2 1st MB memory map Table D.2: 1st MB memory map Addr. range (Hex) F0000h - FFFFFh *CC000h - EFFFFh C0000h - CBFFFh B8000h - BFFFFh B0000h - B7FFFh A0000h - AFFFFh 00000h - 9FFFFh * If Ethernet boot ROM is disabled (Ethernet ROM occupies about 16 KB) * E0000 - EFFFF is reserved for BIOS POST D.3 DMA channel assignments Table D.3: DMA channel assignments...

  • Page 152: D.4 Interrupt Assignments

    D.4 Interrupt assignments Table D.4: Interrupt assignments Interrupt# Interrupt source IRQ 0 Interval timer IRQ 1 Keyboard IRQ 2 Interrupt from controller 2 (cascade) IRQ 3 COM2 IRQ 4 COM1 IRQ 5 COM4 IRQ 6 IRQ 7 LPT1 IRQ 8 IRQ 9 Reserved (audio) IRQ 10...

  • Page 153: Appendix E Optional Extras For The Pci-6871

    Optional Extras for the PCI-6871 Appx. E...

  • Page 154: E.3 Audio Module

    E.1 Optional USB cable (CN20) Optional USB cable (2.0mm) E.2 ATX Power Control Cable E.3 Audio module Audio module with Line-in, Line out, mic PCI-6871 User’s Manual part no.: 1703100260 part no.: 1703200100 part no.: PCM-231A-00A1...

This manual is also suitable for:

Lcd/lvds/lanPci eden400Pci-6871

Table of Contents
