Instruction and
Reference Guide
Model BLGT18A
To register your machine warranty and receive Baby Lock product updates and offers, go to
babylock.com. If you have questions with registration, visit your Authorized Baby Lock Retailer.
Baby Lock Consumer Helpline: 800-313-4110
www.babylock.com
Brought to you by Tacony Corporation
®
Advertisement
Table of Contents
Related Manuals for Baby Lock Gallant XL
Summary of Contents for Baby Lock Gallant XL
- Page 1 Instruction and Reference Guide Model BLGT18A To register your machine warranty and receive Baby Lock product updates and offers, go to babylock.com. If you have questions with registration, visit your Authorized Baby Lock Retailer. Baby Lock Consumer Helpline: 800-313-4110 www.babylock.com Brought to you by Tacony Corporation ®...
-
Page 2: How To Use This Manual
How to Use This Manual Special Information NOTE: A NOTE indicates important information that helps you make better use of your Baby Lock product. Â IMPORTANT: An IMPORTANT note provides information that is essential to properly using your Baby Lock product. -
Page 3: Table Of Contents
Save these instructions ..........................6 Recommended Use and Storage ........................7 About Your Machine ....................... 9 Get to Know Your Gallant XL........................10 Left Side View (picture shown with optional rear handlebars) ............. 10 Right Side View (picture shown without handlebars) ................11 Rear View .............................. - Page 4 Cruise Mode ............................41 Precision Mode ............................41 Manual Mode ............................42 Alerts ................................43 Machine Maintenance ....................45 Clean and Oil Your Gallant XL ........................45 Maintenance Schedule ..........................46 Troubleshooting ......................47 Appendix 1 ........................53 Gallant XL User Manual...
-
Page 5: Congratulations On Your Purchase
Congratulations on Your Purchase! Remember, if you ever have questions, an authorized Baby Lock retailer can help you. If the retailer is not available, contact Baby Lock Product Support, Monday through Friday, 8:30 AM to 5:00 PM Central Time (1-800-313-4110). -
Page 6: Important Safety Information
See the full Declaration of Conformity in the Appendix. Â IMPORTANT: Do not operate your Gallant XL quilting machine until you have completely read the information contained in this manual. Please keep all packaging and order information for warranty purposes. -
Page 7: Save These Instructions
This machine is intended for household use. These are the original instructions. Disclaimer Baby Lock and its retailers are in no way legally responsible or liable for damage to the Gallant XL when used improperly or not in accordance with the guidelines stated in this manual or when used on machine quilting frames not recommended by Baby Lock. -
Page 8: Recommended Use And Storage
To increase the life of your machine 1. Do not store your Gallant XL in areas exposed to direct sunlight or high humidity. Never use or store the machine near a heater, an iron, a halogen lamp or other hot items. - Page 9 • Overheating • Poor performance • Shortened battery life 4. If the product is stored at a temperature above or below the recommended operating range, allow the machine to acclimate to the operating environment before use. To repair or adjust the machine If the machine is not functioning properly or needs adjustment, first check the troubleshooting chart in the appendix to inspect and adjust the machine yourself.
-
Page 10: About Your Machine
The Gallant XL uses high-tech electronics and an innovative user interface to offer greater functionality and ease of operation to home quilters than ever before conceived in the quilting industry. The Gallant XL quilting machine is a high quality machine that incorporates robust design features and is easy to maintain. -
Page 11: Get To Know Your Gallant Xl
Get to Know Your Gallant XL Left Side View (picture shown with optional rear handlebars) 1. Spool pin 2. Thread mast 3. Rear handlebars (optional accessory) 4. Machine encoder connector 5. Machine encoder 6. Front handlebars 7. Front touchscreen display 8. -
Page 12: Right Side View (Picture Shown Without Handlebars)
23. 9-pin connection plug for the optional laser Close-up view of tension assembly area 24. Three-hole thread guide 25. Thread guide 26. Take-up spring 27. Top tension assembly 28. Thread stirrup 29. Take-up lever 30. Lower thread guide | 11 Gallant XL User Manual... -
Page 13: Rear View
Rear View Back View 31. Rear handlebar mounting holes (3) 32. Rear handlebar connection cover 33. Carriage encoder connection jack 34. Carriage encoder cable clip 35. Power input module with fuse holder 12 | www.babylock.com... - Page 14 2. Place the machine on the carriage. U CAUTION: It is suggested to have two people when lifting the Gallant XL. Always lift from the throat of the machine, not from the handlebars, needle bar area or needle bar.
-
Page 15: Power Cord
O (off) position. Front Handlebars The Gallant XL comes with handlebars for the front of the machine. Optional rear handlebars are available for quilting with pantographs or pattern boards. The front handlebars are used for most other quilting activities. -
Page 16: Touchscreen Display
Touchscreen Display The Gallant XL comes with one 7-inch touchscreen front display. To install the front display 1. Locate the three screws for the touchscreen bracket. Line up the white touchscreen bracket and the black connector piece with the holes on top of the Gallant XL. -
Page 17: Spool Pin And Thread Mast
Spool Pin and Thread Mast To install the spool pin on the machine 1. You'll need the spool pin with nut and washer. 2. Remove the nut and washer. 3. Place the washer against the top of the machine cover. 4. -
Page 18: Optional Accessories
3. Slide the washer onto the laser pin threads and screw the laser pin all the way into the side of the machine. 4. While holding the laser pin, firmly tighten the nut with the 8mm wrench (provided). | 17 Gallant XL User Manual... -
Page 19: Ruler Base
Ruler Base If you plan to use rulers and templates with your Gallant XL, you will need to attach the ruler base to give you a large, stable surface on which to rest the ruler or template. The ruler base, rulers, and templates are optional accessories. -
Page 20: Rear Laser Light
Never point it in a direction that would project the beam into someone’s eyes. If the laser should stop working, ensure the plug is firmly seated into the Gallant XL laser port. | 19... -
Page 21: Horizontal Spool Pin
The optional Horizontal Spool Pin allows threads that feed horizontally from the side of the spool. Examples would be straight-wound spools or mylar holographic threads. The Horizontal Spool Pin kit comes with 3 parts; a threaded post, a pin and a clamp. The Gallant XL does not require the threaded post, so set that aside. -
Page 22: Operating Instructions
 IMPORTANT: Refer to the safety instructions. Lighting The Gallant XL includes bright LED lights above the needle, making it easy for you to see your quilting. If needed, adjust the intensity of the lights to suit your environment. Machine Needle Use only the recommended needle system for your Gallant XL quilting machine. - Page 23 2.5mm hex wrench to tighten it just a bit more. The Gallant XL runs at very high speeds and this ensures the needle will not loosen while quilting. However, do not over-tighten the needle clamp screw, as this may strip the threads of the screw.
-
Page 24: Hopping Feet
4. Fully tighten the screw with the 2.5mm hex wrench. Â IMPORTANT: The Gallant XL does not have a presser foot lever, or top tension release, like a home sewing machine. On a home sewing machine the top tension is released when the presser foot is raised, allowing the thread to come freely out of the machine. -
Page 25: Bobbin And Bobbin Tension
To wind the bobbin The Gallant XL comes with a separate bobbin winder. For full instructions about using the bobbin winder, see the instruction manual that is packaged with the bobbin winder. To insert the bobbin into the bobbin case... - Page 26 NOTE: Do not insert the bobbin case into the machine by lifting the release lever on bobbin case. Use the lever only for removing the bobbin case. | 25 Gallant XL User Manual...
-
Page 27: Quilting With The Gallant Xl
Quilting with the Gallant XL Preparing to Quilt  IMPORTANT: Make sure your machine has been cleaned, oiled, has a new needle, and that the tracks on the frame are free from threads or other debris. 1. If the machine isn’t already plugged in, plug it in now. - Page 28 Backing Pole Backing Pole Top Pole Top Pole L E A D E R S T O P FA B R I C B A C K I N G FA B R I C | 27 Gallant XL User Manual...
-
Page 29: Threading The Machine
Threading the Machine Use the visual guide on the following page as well as the instructions below to thread your machine. Baby Lock recommends that you select and use only high-quality threads for your quilts. To thread the machine 1. Place thread cone onto spool pin (1) at the top of the machine; insert the thread through the thread- mast eyelet (2) from back to front, continuing to the three hole thread guide (3). - Page 30 2. Thread mast eyelet 3. Three hole thread guide 4. Thread guide 5. Top tension assembly 6. Take-up spring 7. Thread stirrup 8. Take-up lever 9. Lower thread guide 10. Needle bar thread guide 11. Needle | 29 Gallant XL User Manual...
-
Page 31: Top Tension
Top Tension One of the joys of quilting with the Gallant XL is its ability to utilize many different types of thread. Quilt with almost any high-quality thread as long as you first adjust the bobbin tension and then adjust the top tension to suit the thread chosen. -
Page 32: Tension Quick Start Guide
Solution: Turn the top tension dial counterclockwise to loosen the top tension. 4. If thread looks like Diagram B Problem: The top thread is too loose. Solution: Turn the top tension dial clockwise to tighten the top tension. | 31 Gallant XL User Manual... -
Page 33: Free-Motion Quilting
“ QUILTING TIP: When quilting, relax your hands and maintain a light touch on the handlebars. Gripping the handlebars too tightly means you are trying too hard and you won't quilt smoothly. The Gallant XL, in combination with the frame system will give you a smooth even glide while stitching. -
Page 34: Gallant Xl Screen Navigation
Gallant XL Screen Navigation Complete detailed information for navigation and operation can be found on the following pages. Home Screen The home screen is the main stitching screen that looks like this or something similar to this. The machine's touchscreen will need to be showing the Home Screen when you are stitching. -
Page 35: Main Menu
Home (stitching screen) Overspeed Alarm Lights Gallant XL Information Updates Diagnostics Lights When you click on the Lights icon on the main menu, you will be taken to this screen. This will allow you to adjust the brightness of the light under the nose of the machine. -
Page 36: Stitching
To turn the alarm off, select the icon on the left that has the line going through it. When the alarm is OFF, the alarm will not sound, regardless of how fast you move the machine. Press the Menu symbol to go back to the Main Menu. | 35 Gallant XL User Manual... -
Page 37: Information
The Machine information is on top. The Display information is below. Press the Menu symbol to go back to the Main Menu. Diagnostics You may be asked to perform diagnostic tests by Baby Lock's Product Support team or an authorized Baby Lock retailer. Motors Handlebars... - Page 38 Play/Pause Plus When the screen shown above is open, press any of the four keys on the front or optional back handlebars to verify the machine is reading the keys as they are pressed. | 37 Gallant XL User Manual...
- Page 39 Press each key on the front or back handlebars several times. When a key is pressed, it will become selected or hightlighted on the touchscreen to indicate that key is working. Pass: Each time a key is pressed, the corresponding key icon on the diagnostic screen will toggle between selected or unselected.
-
Page 40: Updates
This screen can be used to update the touchscreen display and the machine software using a USB drive (with the updated firmware versions) inserted into the touchscreen's USB port. To complete an update, follow these steps: | 39 Gallant XL User Manual... -
Page 41: Stitch Modes
For the latest software update for your machine or display, visit babylock.com and select the machine model. 2. Insert the USB drive into the bottom of the Gallant XL touchscreen. NOTE: This USB port is used for both the Machine and Display updates. -
Page 42: Cruise Mode
When quilting in Precision mode, the needle only moves when you move the machine. Stitching Length (SPI) Needle position (blue indicates what position is selected) Precision Mode | 41 Gallant XL User Manual... -
Page 43: Manual Mode
After pressing the Start/Stop key on the handlebars, move the machine to begin quilting according to the stitches-per-inch setting. When you pause moving the machine, the needle will pause again. Press the Start/Stop key on the handlebars to fully stop quilting. Select the Precision icon and then specify the stitches per inch by pressing the Plus or Minus key on the the screen. -
Page 44: Alerts
An icon will be displayed on the screen along with a code number that appears in the upper right corner of the screen. This number will help a Baby Lock retailer diagnose the issue. The number will not mean anything to you, but make note of this and relay it to your authorized Baby Lock retailer. - Page 45 Magnetic Encoder: This icon indicates a problem with the main shaft position sensor. Please contact your authorized Baby Lock retailer for service. Service: This icon indicates that the machine should be serviced. Please contact your authorized Baby Lock retailer for service X Encoder: This icon shows the X encoder is not fully plugged in.
-
Page 46: Machine Maintenance
A change in the sound of the machine while quilting also indicates that it may need to be oiled. NOTE: Internal lubrication will be done when the machine is taken to an authorized Baby Lock retailer for routine maintenance and cleaning, every 24 months or 10 million stitches (whichever comes first). -
Page 47: Maintenance Schedule
In addition to the ongoing cleaning and oiling maintenance that you do on a regular basis when you quilt, you should have your machine serviced by an authorized Baby Lock retailer every 24 months or 10 million stitches, whichever occurs first. They will take care of oiling and greasing internal parts and ensure the machine is in optimal working order. -
Page 48: Troubleshooting
Troubleshooting You can correct many problems on your own. If you need additional help, contact your local, authorized Baby Lock retailer who supports you and your machine. You can also contact Baby Lock Product Support at 1-800-313-4110. First, check the following: 1. - Page 49 Improper threading • Ensure that the machine is threaded correctly. Refer to your Gallant XL Quick Reference Card if needed. The needle is not positioned • Position the needle properly to the needle bar. Inspect the properly position of the needle to make sure the needle is at the 6 o’clock position.
- Page 50 The bobbin winds onto the hook spindle, or should rotate clockwise when the thread is pulled. occasionally forms loops on the bottom of the quilt | 49 Gallant XL User Manual...
- Page 51 Leaders are stretched or worn • If fabric is beginning to stretch or fray, contact your authorized Baby Lock retailer to purchase replacement leaders. Thread Breaks Corrective Measure(s) Poor quality thread, may have •...
- Page 52 Stitching in one place too long will cause the thread to break. Improper needle/hook • Machine timing needs to be checked. Consult an authorized relationship Baby Lock retailer. | 51 Gallant XL User Manual...
- Page 53 Gently rub with emery cloth to remove the sharp handling part edge. Consult an authorized Baby Lock retailer to polish any hard-to-reach or delicate areas. Wrong type of needle • Use only the needles recommended by Baby Lock (needle system 134, sizes 12 through 21).
- Page 54 Fenton, Missouri, 63026 declares that the product, Product Name: Gallant XL complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
