- Page 1 SMILE Battery replacement instruction NE41 19010-02 v1.1...
- Page 2 NEAT Electronics AB is not responsible for any loss of data, income or any consequential damage whatsoever caused. For more information, details and descriptions, visit our web site: www.neat-group.com © 2019 Legrand All rights reserved. Document number: NE41 19010-02 v1.1 Revision date: 2019-12-18 NEAT Electronics AB Varuvägen 2...
-
Page 3: Table Of Contents
Content Introduction Intended use This handbook Warnings and disclaimers Hardware General Remove battery instruction Remove top shell Open bottom part Remove the battery Remove the O-ring Unit assembly with new battery Insert new battery Mount new O-ring PCB and bottom shell assembly Top shell assembly Safety and disposal Safety notes... - Page 4 Document revision history Date Version Revision details 2019-12-16 Release of v1.0 2019-12-18 Added missing pictogram to “5.3 Disposal”. NE41 19010-02 v1.1 SMILE - Battery replacement instruction...
-
Page 5: Introduction
Introduction Intended use The battery replacement kit is intended only for those Neat products that allow bat- tery replacement. Please contact your sales office for further information. This handbook Information notes and warnings intended for maintenance personnel and/or users are emphasized in these instructions by the pictograms defined here. The Information sign and corresponding text is intended for information which might be useful, but not critical for the reader and/or user. -
Page 6: Hardware
Hardware General The battery replacement kit contains a Lithium CR2430 battery, a top shell (color depending on product) and an O-ring. Other parts pictured in this manual are bottom shell and over molded PCB. Pictured in this manual is a neutral colored top shell and bottom shell, not an actual product. -
Page 7: Remove The Battery
Remove the battery Remove the battery. Dispose of the battery according to the local instructions for recycling, see section “Eliminación”. Remove the O-ring Use a thin flathead screwdriver to remove the O-ring. Be careful not to damage the O-ring groove. Discard the O-ring! SMILE - Battery replacement instruction NE41 19010-02 v1.1... -
Page 8: Unit Assembly With New Battery
Unit assembly with new battery Insert new battery Put the new battery in the battery holder. Check the battery polarity and position the battery accordingly. Make sure that the positive polarity of the battery is mounted upwards. Mount new O-ring Place the new O-ring in the groove. -
Page 9: Pcb And Bottom Shell Assembly
PCB and bottom shell assembly Place the circuit board into the bottom shell as pictured. Use position of data matrix label as reference for how to turn the circuit board. Make sure that the transmitter and circuit board are rotated as shown in the picture. Finally push downwards on both sides. -
Page 10: Top Shell Assembly
Top shell assembly Assemble the Bottom shell with the circuit board in a new Top shell by first placing one of the edges with the snaps in the top shell Press them together until they snap into position on both sides. NE41 19010-02 v1.1 SMILE - Battery replacement instruction... -
Page 11: Safety And Disposal
Safety and disposal Safety notes • Read instructions prior to use • Always test the system per instructions prior to use. • The product may not be suitable for all persons. • Check device regularly and replace when necessary. • Always check the function of the product after making adjustments. •... - Page 12 neat-group.com...
