869MHz Touch 2
Attack Pendant
_________________________________________________________________________
869MHz
Caring for People
Portable alarm trigger device
Compatible with Reach IP, Advent XT2 & Carer Response
Complies with BS EN 50134-2:2017
IP68: fully sealed against immersion in water
Red alarm transmit reassurance LED
Green alarm received reassurance LED
TPU neck cord with anti-ligature safety break
TPU wrist strap with aluminium stud
ABS belt clip
Suction cup for fixing to a hard surface
5 year Lithium battery (typical)
Low battery warning
Telecare Transceiver: 869.2125MHz Class 1.5
Digital Heartbeat
Operating Temperature: -10
Weight: 12 grams (exc. wearing option)
Dimensions: 45mm x 30mm x 14mm (HxWxD)
Product Code: ZXT801
The Touch 2 attack pendant can be worn by the user
either around the neck, on the wrist or on a belt.
An attack alarm call can be made from anywhere in or
around the home, in residential housing attack calls can
be made from anywhere on the scheme.

Attack Alarm Call

An attack alarm call is made by simply pressing the
pendant button once, no further action is required.
The button will flash red to indicate a call has been
transmitted, it will then flash green as reassurance that the
call has been received by the Reach IP or Advent XT2 – it
does not flash green when used with a Carer Response.
________________________________________________________________
Tynetec, a business unit of Legrand Electric Ltd
Cowley Road, Blyth Riverside Business Park, Blyth, Northumberland, NE24 5TF.
Tel: +44 (0) 1670 352371 www.tynetec.co.uk
o
o
C to +55
C
Trusted Technology
Caring for People

Alarm Condition

The attack pendant will initiate a silent dial attack alarm
call on the Reach IP unit with speech opened in listen
mode only. This allows the ARC operator to listen-in and
assess the situation before taking appropriate action.
It will initiate an "attack" alarm on the Advent XT2 and
Carer Response.

Low Battery Condition

A low battery condition will be reported automatically to
the Alarm Receiving Centre (ARC) or the local Manager.
The attack pendant should be replaced as soon as possible
within 30 days.

Out of Range Notification (Reach IP)

The Reach IP can monitor all radio peripheral devices to
determine whether they have been damaged or removed
from an installation. Should the Reach IP be unable to
detect a device's heartbeat it will automatically generate a
"radio out of range" notification. Firstly, investigate if
there's a genuine reason for the alert, if not, arrange for
the peripheral device to be replaced immediately.
The "Radio out of range timer" can be set from 30 hours to
99999 hours in Pulse CMP. "Radio supervision" can be
disabled by unchecking the tick box associated with each
peripheral device in Pulse CMP.

Maintenance

Test the attack pendant once every month.
Clean with a damp cloth, do not use solvents or cleaners
on the pendant or wearing accessories.

Disposal

Waste electrical products should not be disposed
of with normal household waste. The attack
pendant is ideally suited for disposal within the
waste electronic and electrical equipment (WEEE)
recycling scheme. Please recycle where facilities exist.
Check with your local authority or contact your supplier for
recycling/disposal advice.

Warning

The attack pendant contains a Lithium battery. If tampered
with the battery may be damaged and create a fire hazard.
No attempt should be made to remove or replace the
battery. Do not incinerate.

Anti-ligature Safety Break

The attack pendant includes an anti-ligature safety break in
the neck cord. Should excessive force be applied the cord
will part - it can be simply clipped back together.
Doc No. FM0884 V1.01 Page 1
