- Page 1 11.4 DT-E TECHNICAL AND OPERATIONAL DOCUMENTATION INSTALLATION MANUAL, OPERATING MANUAL AND INSTRUCTIONS FOR SAFE USE (Translated from the original manual) Awnings 11.4 Terrace awning JAMAICA...
- Page 2 THIS TECHNICAL AND OPERATIONAL DOCUMENTATION: Is valid from: 28 March 2022 Is applicable to the above listed product versions. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 2 / 28...
-
Page 3: Table Of Contents
4.5.1 JAMAICA AWNING INSTALLATION – WALL BRACKETS ................10 4.5.2 JAMAICA AWNING INSTALLATION – CEILING BRACKET ................16 4.5.3 JAMAICA AWNING INSTALLATION – ROOF RAFTER BRACKET ..............16 ELECTRIC DRIVE ..............................16 4.6.1 CONNECTION TO ELECTRICAL INSTALLATION ..................... 16 4.6.2 REMOTE OPERATION ........................... -
Page 4: Introduction
Threat to human life or health due to electric shock. Marking of electronic or electric equipment, which should be collected in the ENVIRONMENT designated points. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 4 / 28... -
Page 5: Terms And Definitions
SELT SP. Z O.O. with a head office in Opole shall hold the copyrights to this documentation. The documentation cannot be used without permission, either partially or as a whole, for any concurrent business activity nor can it be made available to third parties. -
Page 6: Product Technical Information
The optional use of weather automation additionally protects the product against changing weather conditions. PRODUCT SPECIFICATION Products manufactured by SELT have appropriate technical and operational parameters. They have the following features: They provide excellent sun protection for surfaces such as terraces and balconies. -
Page 7: Jamaica Awning Construction
JAMAICA AWNING CONSTRUCTION VOLANT FRONT BAR ROLL-UP VALANCE TYPE OF BRACKETS Wall bracket Ceiling bracket Roof rafter bracket Option with hood DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 7 / 28... -
Page 8: Transport And Storage Of The Product
COMPLETENESS AND QUALITY CONDITION OF DELIVERY SELT Sp. z o. o. makes every effort to ensure that the goods comply with the order. However, checking the completeness of the product is the responsibility of the Buyer and should take place at the time of its receipt. -
Page 9: Product Installation
This chapter contains general requirements concerning the product installation. Correct assembly is a necessary condition for smooth operation of the product. SELT Sp. o.o. recommends using only professional assembly crews, which guarantee the Purchaser that the conducted installation will be correct. -
Page 10: Preparation For Installation
4.5.1 JAMAICA AWNING INSTALLATION – WALL BRACKETS SELT recommends the use of Fischer fixing products - selected depending on the type of substrate. Suggested recommendations for selected substrates: for non-cracked concrete class C20/25 and not higher than C50/60: ... - Page 11 5) Screw the wall bracket in the position as shown in the drawing in the available variants using: the upper and lower holes. Follow the anchor manufacturer's instructions regarding required anchor spacing, preparation and installation method. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 11 / 28...
- Page 12 – wall surface should be of the same thickness at installation spots). 11) Secure square bar with M8x65 screws and put PVC cover on them DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 12 / 28...
- Page 13 18) After changing the tilt angle, remember to modify the position of the roller tube support. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN...
- Page 14 WARNING! It must be remembered that when changing the tilt angle of the awning, the position of the half-rings of the roller tube support must also be adjusted properly each time. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN...
- Page 15 In order to attach the hood to the awning, please carry out the following steps (in sequence as shown on the drawings below). DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 15 / 28...
-
Page 16: Jamaica Awning Installation - Ceiling Bracket
Must be used in swimming and shower pools, saunas, on construction sites, when powering outdoor devices, in farms and horticulture, in camping and recreational vehicles and in rooms at risk of fire. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN... -
Page 17: Remote Operation
the effectiveness of zeroing the product and the electrical system should be checked at each new installation site. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 17 / 28... -
Page 18: Manual Drive
Do not allow the fabric to be rolled in the opposite direction (from the bottom of roller tube), since it may cause its ripping off the roller tube, fabric damage or incorrect awning functioning. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN... -
Page 19: System Operation And Product Safety
- otherwise it will lead to permanent damage. It is recommended that the change of equipment configuration be consulted with SELT.. SAFETY REQUIREMENTS RELATED TO SPECIAL CONDITIONS AND PLACES OF PRPDUCT USE Specific safety requirements relate to children up to 42 months. Essential requirements for use are applicable in all locations, to which children have access or where they could be present. - Page 20 Automatically controlled products may start up on their own. Make sure that no dangerous situation arises. SELT Sp. z o. o. is not responsible for damage caused by improper use. Operating the system out of sight can cause serious injury as well as damage to the system.
-
Page 21: Control Of Safe Use Of The Product
do not use the product during maintenance work (e.g. cleaning windows). SELT Sp. z o.o. shall not be responsible for damages caused by misuse. INSTRUCTION FOR NON-PROFESSIONALS Read carefully this document before using the product. - Page 22 Possible adjustment and improvement of fastening of the mentioned components. Products manufactured by SELT Sp. z o. o. do not require any special maintenance. Using the product in accordance with the manufacturer's instructions ensures long-term and trouble-free operation for the system user. Ongoing maintenance work should be carried out on a fully developed system.
-
Page 23: Use Of Awning Fabrics
Stagnation of water on its surface may lead to overloading of fastenings and to slight deformations and waviness of the fabric surface. If the damp fabric is rolled up, unroll it immediately after the rain stops and let it dry. DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN... -
Page 24: General Warranty Terms
GENERAL WARRANTY TERMS General warranty terms are available on www.selt.com If the SELT Sp. z o.o. website is inaccessible then warranty terms and conditions can be obtained from the sales representative of SELT Sp. z o.o. WARRANTY EXCLUSIONS The warranty will not cover: ... -
Page 25: Complaint / Technical Defects
Immediately report a product defect to the Seller. Notifications can be sent to the e-mail address reklamacje@selt.com or directly to a sales representative. Reporting a technical defect / complaint should be made in writing on the "complaint notification" form, which can be found at www.selt.com or directly to the sales representative. -
Page 26: Product Disassembly / Utilisation / Disposal
2006 on batteries and accumulators and waste (Dz. U. [Journal of Laws] 2009, no 79, item 666) batteries and accumulators and repealing Directive 91/157/EEC DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 26 / 28... -
Page 27: Marking And Labelling Of The Product With Ce Mark
10.1 PRODUCT COMPLIANCE WITH THE CE STANDARD Products manufactured by SELT company meet the essential requirements of the standard introduced by the Polish Committee for Standardization as PN-EN 13561 what is confirmed by the manufacturer’s declaration of performance and marking the product with the CE mark. - Page 28 01 / DZ/2017 Awning with folding arms JAMAICA with Volant 230V/ 50 Hz Power 198 to 275 W 01 / DZ/2017 DT-E 11.4 SUN PROTECTION SYSTEM – TERRACE AWNING JAMAICA Edition 9 / March 2022 / EN page 28 / 28...
