INSTALLATION AND MAINTENANCE INSTRUCTIONS
8100 FAAST
Fire Alarm Aspiration Sensing Technology
SPECIFICATIONS
Electrical Characteristics
External Supply Voltage
Remote Reset Time
Power Reset
Average Operating Current
Alarm
Relay Contact Ratings
Environmental Ratings
Operating Temperature
Sampled Air Temperature
Humidity
IP Rating
Coverage Area
Air Movement
Mechanical characteristics
Exterior Dimensions
Height
Width
Depth
Cable Access
Wire Gauge
Pipe Network Size
Shipping Weight
TABLE OF CONTENTS
INTRODUCTION
SCOPE OF THIS MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DESCRIPTION
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
ITEMS INCLUDED WITH UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION
PIPE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PHYSICAL UNIT INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Securing the Mounting Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Mounting the Detector to the Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Connecting the Air Sampling Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Exhaust Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
WIRING
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Conduit Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CABLING REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SYSTEM POWERING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
USER INTERFACE
USER INTERFACE CARD INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PARTICULATE LEVEL DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ALARM LEVEL DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
AIR FLOW/FAULT DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
USER INTERFACE BUTTONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
MODES OF OPERATION
INITIALIZATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
STARTUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Failure of Configuration Validation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SS-400-007
18 – 30 VDC
External monitor must be pulled low for a minimum of 100 msec.
1 sec.
500 mA @ 24 VDC
650 mA – All relays active, all alarm levels displayed. Voltage @ 24 VDC
3.0 A @ 30 VDC, 0.5A @ 125 VAC
32°F (0°C) to 100°F (38°C)
-4°F (-20°C) to 140°F (60°C)
10 to 95% (non-condensing)
IP30
8,000 sq. ft. (743.2 sq. m.)
0 – 4,000 ft./min. (0-1,219.2 m/min.)
13.25 in. (33.66 cm)
13.0 in. (33 cm)
5.0 in. (12.7 cm)
4 – 1 in. (2.54 cm) cable entry holes on top and bottom of unit.
12 AWG (2.0523 mm) max. to 24 AWG (0.5105 mm) min.
Up to 8000 sq. ft. (approx 743 sq. m)
Maximum single pipe length 262 ft. (80 m)
Network outside pipe diameter 1.050 in., IPS (25 mm)
Internal pipe diameter .591 to .827 in. (15-21 mm)
11.6 lbs. (5.26 kg), includes packing material
®
Power or Network Loss during Configuration . . . . . . . . . . . . . . . . . . . . . . 6
NORMAL MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TEST MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
RESET MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ACCLIMATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setting Acclimate mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
DAY, NIGHT AND WEEKEND MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ISOLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
USER BUTTON ALTERNATE FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Passcode Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Address Blink Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
IP Address Blink Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
FAULTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
REAL–TIME CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
LOGS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Data Trend Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Message Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
EXTERNAL MONITOR/RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ETHERNET CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PIPE NETWORK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
WEB SERVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
E-MAIL NOTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CANNED SMOKE TESTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
GLOSSARY
KEY TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1
3825 Ohio Avenue, St. Charles, Illinois 60174
1.800.SENSOR2; Fax: 630.377.6495
www.systemsensor.com
I56-3620-005
Advertisement
Table of Contents
Related Manuals for System Sensor 8100 FAAST
Summary of Contents for System Sensor 8100 FAAST
- Page 1 INSTALLATION AND MAINTENANCE INSTRUCTIONS 8100 FAAST 3825 Ohio Avenue, St. Charles, Illinois 60174 Fire Alarm Aspiration Sensing Technology ® 1.800.SENSOR2; Fax: 630.377.6495 www.systemsensor.com SPECIFICATIONS Electrical Characteristics External Supply Voltage 18 – 30 VDC Remote Reset Time External monitor must be pulled low for a minimum of 100 msec.
-
Page 2: Pipe Installation
DESCRIPTION mounted to the wall using the enclosed mounting plate. Figure 1 shows the The 8100 FAAST aspirating smoke detection system is an advanced particulate wall mounting plate. For easier access to the FAAST unit, it is preferred to detection system for use in early warning and very early warning applications. - Page 3 Mounting the Detector to the Bracket Exhaust Pipe Once the mounting plate is attached, the unit is ready to be mounted onto the The device should always be exhausted into the space that it is monitoring. plate. Perform the following procedure to mount the unit. There are some circumstances when it may be necessary to connect a pipe to the exhaust port to divert the exhaust away from the location of the unit.
-
Page 4: Cabling Requirements
CABLING REQUIREMENTS TABLE 2. FACP WIRING DIAGRAM The FAAST system provides a series of Euro style pluggable terminals, located Fire Panel (FACP) typical connection FAAST 8100 for monitoring of device Fire Alarm Aspiration Sensing Technology® behind the left side door of the unit. Alarm Refer to Table 1 for the proper electrical connections to the unit. -
Page 5: Green Leds
FIGURE 4. USER INTERFACE DISPLAY These alarm levels are configured at default levels when shipped. They may be modified using the PipeIQ software tool. Each of these alarm levels controls a set of form C relay contacts. When an alarm level threshold is crossed, the cor- responding level LED illuminates and the relay activates a signal.. -
Page 6: Modes Of Operation
NOTE: Installation must be accomplished in accordance with all local codes and regulations. Product is UL certified to UL268. The 8100 FAAST is UL approved from 0.00046 %/ft obs. to 4.0%/ft obs. Evacuation via FACP (fire alarm control panel) must not be set higher than 0.743 %/ft obs. - Page 7 DAY, NIGHT AND WEEKEND MODE FIGURE 10. ADDRESS BLINK MODE If Acclimate mode is not desired, the FAAST system can operate in a simple day, night and weekend mode. This allows the device to have separate thresh- old levels for each state. Times can be configured, if desired, for entering and leaving day and night time operation.
-
Page 8: Real Time Clock
TABLE 5. FAULT DESCRIPTION NUMBER NAME DESCRIPTION ACTIVATED RELAY Low Flow Fault Device has decreased airflow of 20%. Minor Fault Device has decreased airflow of 50%. Urgent Fault Configuration Configuration of device with configuration software has failed. Minor Fault Device was interrupted with a power loss during configuration. A Reset will Minor Fault clear this fault and device will revert back to it's last good configuration. -
Page 9: Email Notification
WEB SERVER TABLE 6. CANNED SMOKE TESTING The FAAST system contains an integrated Web server which is used to ob- serve detector configuration and may be used to remotely monitor the unit. COMPANY AEROSOL LISTED The Web server features include: Home Safeguard •... -
Page 10: Required Documents
FAAST System Validation Form Customer Name: Project Name: Site Address: Installer Name/Contact information: Date: Commissioning Agent/Contact information: Date: Client Representative/Contact information: Date: Witness/Contact information: Date: Wiring Checked: Date: Yes / No Detector Settings Checked: Date: Yes / No Test Relays: Date: Yes / No REQUIRED DOCUMENTS... -
Page 11: Time Delay
FAAST System Validation Form (CONT.) Air Handling Yes / No Duct Sampling Yes / No Number of Sample points: Number of Cabinets: Temperature: Humidity: Conditions: Other: As-Built Installation Is the system installed in Yes / No Yes / No Drawings Available? accordance with the design? Is the power supply Is the pipe network installed... -
Page 12: Key Terms
Department, RA #__________, 3825 Ohio Avenue, St. Charles, IL 60174. Please include a System Sensor warrants its enclosed smoke detector to be free from defects in materials note describing the malfunction and suspected cause of failure. The Company shall not...
