Summary of Contents for EVEBASE MOVE 500
- Page 1 USER MANUAL POWER STATION MOVE 500...
-
Page 2: Table Of Contents
CONTENT SAFETY INSTRUCTIONS AC OUTPUT PARAMETER PRODUCT INTRODUCTION LCD DISPLAY OPERATION INSTRUCTION PRODUCT SPECIFICATIONS BATTERY SPECIFICATIONS PROBLEMS AND RESOLUTIONS... -
Page 3: Safety Instructions
Only official parts or accessories can be used with this product. If any accessories need to be replaced, please contact Evebase for more information. Do not charge the product with a charging device that does not meet the specified parameters and please do not use extension cords and cable taps. - Page 4 14. Avoid usage/ storage near any heat source (fire, car in direct sunlight etc.). 15. Don’t use any wires or metal objects that can result in a short circuit. 16. No items can be stacked on top of the product. 17.
-
Page 5: Ac Output Parameter
AC OUTPUT PARAMETER Type of AC port AC output US/JP 100V~120V 50/60Hz 220V 50Hz 230V 50Hz 220V~240V 50Hz 220V 60Hz... -
Page 6: Product Introduction
PRODUCT INTRODUCTION This product is a portable power station, suitable for family emergency power cuts, outdoor travel, emergency relief, field work and other scenarios. The product has a built-in lithium battery, which supports adapter, car charger, photo-voltaic panel and other charging methods. The AC output voltage corresponds to different national specifications (see previous page) and a number of USB ports supply for lighting, ventilator, electric fan, router, notebook and other equipment. -
Page 7: Lcd Display
LCD DISPLAY High/Low temperature protection Charging power Car port output indicator Fan status Discharge power Battery percentage DC Port Charging Indicator AC output indicator Battery indicator Type-C Output indicator USB output indicator LED indicator 12V DC port High/Low temperature protection Charging power Car port output indicator Fan status... -
Page 8: Operation Instruction
OPERATION INSTRUCTION 1. How to turn on the system and check the battery? Shortly press any button on the power station to turn on the system, you can check the remaining battery power and switch on the corresponding port output. During the first use after a long-term non-use situation it may happen that any button fails to turn on the system In order to solve this, please plug the power station into a charger for charging and try again. - Page 9 5. How to use USB and TYPE-C output ports? Shortly press the USB button to turn on USB-A/TYPE-C ports, which are used for digital devices such as mobile phones, cameras, tablets and so on. When the device is fully charged or plugged out, it will turn off automatically. When the output is overloaded or short-circuiting, flashes and the alarm is buzzing.
-
Page 10: Product Specifications
PRODUCT SPECIFICATIONS Product name EveBase Power Station Move 500W Product dimensions L*W*H = 269*178*205mm Product net weight 5,0 kg Rated capacity 484Wh rated voltage 21.6V Charging input 12-30V 150W Max DC port: 1. adapter output 12-30V (current above 1A can be used;... -
Page 11: Battery Specifications
3. Place the equipment in a -10°C ~ 40°C environment. Please check if the adapter is properly Unable to charge The adapter has a poor connection connected to the charging port. EveBase Tech B.V. Oostwal 2 1747 EZ Tuitjenhorn The Netherlands support@evebase.com www.evebase.com...
