- Page 1 USER MANUAL POWER STATION MOVE 1200...
-
Page 2: Table Of Contents
CONTENT SAFETY INSTRUCTIONS AC OUTPUT PARAMETER PRODUCT INTRODUCTION LCD DISPLAY UPS MODE SOLAR PANEL CHARGING CAR CHARGING PRODUCT SPECIFICATIONS BATTERY SPECIFICATIONS PROBLEMS AND RESOLUTIONS... -
Page 3: Safety Instructions
Only official parts or accessories can be used with this product. If any accessories need to be replaced, please contact Evebase for more information. Do not charge the product with a charging device that does not meet the specified parameters and please do not use extension cords and cable taps. - Page 4 14. Avoid usage/ storage near any heat source (fire, car in direct sunlight etc.). 15. Don’t use any wires or metal objects that can result in a short circuit. 16. No items can be stacked on top of the product. 17.
-
Page 5: Ac Output Parameter
AC OUTPUT PARAMETER Type of AC port AC output US/JP 100V~120V 50/60Hz 220V 50Hz 230V 50Hz 220V~240V 50Hz 220V 60Hz... -
Page 6: Product Introduction
PRODUCT INTRODUCTION This product is a high power portable power station, suitable for family emergency power cuts, outdoor travel, emergency relief, field work and other scenarios. The product has a built-in LiFePO4 battery, which supports adapter, car charger, photo-voltaic panel and other charging methods. - Page 7 4. DC button Operate method: short press to turn on/off. 5. LCD display The display shows the remaining power and different using data. 6. Cooling system When the fans are working, please do not block the channel. 7. AC button (AC output, total combined 1200W) Operate method: short press to turn on/off.
-
Page 8: Lcd Display
LCD DISPLAY Charging/ using time Total output power AC charging Fan state LED light Anderson charging High/low temperature protection 8 AC output DC output Power percentage Type-C output Car port output Total input power USB output When this icon lights up, please keep the air intake/ outlet unobstructed. When this icon lights up, please note that the operating temperature of the device is too high or too low. -
Page 9: Ups Mode
When the power grid is cut off, it will immediately switch to the internal battery capacity, in order for you to keep on working. Evebase is not responsible for any abnormal operation or data loss caused by careless use. In case the power station jumps into UPS mode in Europe or the United Kingdom and the AC output exceeds the maximum power of 1200W, the AC output icon will start to flash, indicating overload. -
Page 10: Solar Panel Charging
SOLAR PANEL CHARGING The product can be charged through solar panels. Maximum solar panel input is 500W (maximum 50V voltage). The solar panel charging power may fluctuate according to the weather conditions. Solar panel voltage exceeding 50V will damage the equipment and isn’t covered by warranty. CAR CHARGING This power station can be charged by the cigarette lighter in the car, with an ACC cable. -
Page 11: Product Specifications
PRODUCT SPECIFICATIONS Product name EveBase Power Station Move 1200W Product dimensions L*W*H = 386*225*317mm Product net weight 12,5 kg Rated capacity 960Wh AC Charging 50/60Hz 700W max MPPT input 11.5-50V 500W max 50/60Hz (frequency switch available), rated 1200W, peak 2400W, AC Output pure sine wave. -
Page 12: Problems And Resolutions
2. After checking if all components are Overload protection function normal, turn on the power button. Charging unavailable activated. 3. Press the overload protection button to connect the AC cable to recover AC input. EveBase Tech B.V. Oostwal 2 1747 EZ Tuitjenhorn The Netherlands support@evebase.com www.evebase.com...
