Fujitsu AR G45LMLA Series Design & Technical Manual page 10

INSTALLATION PLACE
„ „
MAINTENANCE HOLE
„ „
It is possible to install and remove the control
box.
Maintenance hole
300
Control box
500
WHEN USING A SQUARE DUCT
„ „
BOTTOM AIR INTAKE HOLE
„ „
300 or more
P174 X 6 = 1044
108 1015
- (01 - 07) -
150 or more
It is possible to install and remove the control
box, fan units and filter.
Maintenance hole
300
Control box
1550
46
18
Ø3.2
(Unit : mm)
Intake panel
