TROUBLESHOOTING
※ Load mode Check list
No. Part
1 R-FAN HIGHEST
2 R-FAN HIGH
3 R-FAN LOW
R compartment
4
defrost heater
Showcase Door
5
heater
High
6
Temperature
7 Low Temperature
Normal
8
Temperature
9 Demo Mode
10 Damper Open
11 IceMaker Heater
12 Full Ice
AUTO FILL
13
BOTTLE SENSOR
14 Comp.
15 F-FAN HIGHEST
16 F-FAN HIGH
17 F-FAN LOW
F compartment
18
defrost heater
19 C-FAN HIGHEST
20 C-FAN HIGH
21 C-FAN LOW
AUTO FILL FULL
22
WATER SENSOR
23 F(I-F) Valve
24 R Valve
25 I-FAN HIGHEST
26 I-FAN HIGH
27 I-FAN LOW
28 French Heater
29 Wifi Status
Display (LED)
R-10 "a","b" In the case of the R-FAN HIGHEST operation, the corresponding LED is blinked
R-1 "a" In the case of the R-FAN HIGH operation, the corresponding LED is blinked
R-1 "b" In the case of the R-FAN LOW operation, the corresponding LED is blinked
In the case of the R compartment defrost heater operation,
R-1 "c"
the corresponding LED is blinked
R-1 "d" In the case of the Showcase Door heater operation, the corresponding LED is blinked
R-1 "e" If the external air temperature is 34℃ or higher, the corresponding LED is blinked
R-1 "f" If the external air temperature is 21℃ or less, the corresponding LED is blinked
If the external air temperature is within the range of 22℃ ~ 33℃,
R-1 "e","f"
the corresponding LED is blinked
R-1 "g" In the case of the Demo mode operation, the corresponding LED is blinked
R-10 "a" In the case of the Flex-Zone damper opened, the corresponding LED is blinked
R-10 "c" In the case of the IceMaker's heater operation, the corresponding LED is blinked
R-10 "d" In the case of the Ice maker's bucket is full,, the corresponding LED is blinked
In the case of the "Auto Fill Infuser" bottle sensor detected bottle,
R-10 "g"
the corresponding LED is blinked
F-1 "a" In the case of the Comp. operation, the corresponding LED is blinked
F-1 "b","c" In the case of the F-FAN HIGHEST operation, the corresponding LED is blinked
F-1 "b" In the case of the F-FAN HIGH operation, the corresponding LED is blinked
F-1 "c" In the case of the F-FAN LOW operation, the corresponding LED is blinked
In the case of the F compartment defrost heater operation,
F-1 "d"
the corresponding LED is blinked
F-1 "e","f" In the case of the C-FAN HIGHEST operation, the corresponding LED is blinked
F-1 "e" In the case of the C-FAN HIGH operation, the corresponding LED is blinked
F-1 "f" In the case of the C-FAN LOW operation, the corresponding LED is blinked
In the case of the "Auto Fill Infuser" water sensor detected water,
F-10 "a"
the corresponding LED is blinked
F-10 "b" In the case of the F-Valve Opend, the corresponding LED is blinked
F-10 "C" In the case of the R-Valve Opend, the corresponding LED is blinked
F-10 "d", "e" In the case of the I-FAN HIGHEST operation, the corresponding LED is blinked
F-10 "d" In the case of the I-FAN HIGH operation, the corresponding LED is blinked
F-10 "e" In the case of the I-FAN LOW operation, the corresponding LED is blinked
F-10 "g" In the case of the French heater operation, the corresponding LED is blinked
Not connected to the IP sharer (AP) or the Internet: Off
WI-FI Icon Router(AP) connected: On
Internet connected: On
Description
