DISASSEMBLY AND REASSEMBLY
3-8) Vegetable & Fruit Drawers Shelf
Part Name
Vegetable & Fruit Shelf
How To Do
1. Remove the vegetable & fruit drawer by
pulling the roller part and lifting it up.
2. While pressing the button on the left of the
shelf in txhe picture, lift up the Vegetable &
Fruit Drawer Shelf.
(Refer to the picture)
3. Remove the vegetable & fruit drawer shelf by
pulling it out.
(Refer to the picture)
26
Descriptive Picture
button
