Samsung RF28R7201 AA Series Service Manual page 15

Items
Defrost Heater(FRE)
Defrost Heater(REF)
Heater-Ice Maker
DISPENSER Heater
FRENCH Heater
Heater Water Pipe
Heater Ice room
Bimetal Thermo For Preventing of Refrigerator Heater
Rated Voltage
Motor BLDC (FRE)
Motor BLDC (REF)
Motor BLDC (CIRCUIT)
Motor BLDC (ICE ROOM)
Auger Motor
Geared Motor (ICE MAKER)
Geared Motor (DISPENSER)
Motor DAMPER
Lamp LED(FRE)
Lamp LED(REF)
Lamp LED(MID)
Door Switch
Power Cord
Earth Screw
Heated at F Defrost
Heated at R Defrost
Interlock with
French Heater
-
-
-
FRE
REF
REF (ICE ROOM)
MID
15
PRODUCT SPECIFICATIONS
Specification
RF28R*
AC 120V, 230W / AC 230V, 230W
AC 120, 120W / AC 230V, 120W
F/S : AC 120V, 141W / AC 230V, 141W
C/D : AC 120V, 120W / AC 230V, 120W
AC 120, 2.5W / AC 230V, 2.5W
AC 120, 2.5W / AC 230V, 2.5W
DC12V, 2.3W
DC12V, 2W
AC 250V, 3A
Off : 140℉(60℃). On : 104℉(40℃)
AC 230V / 50HZ
DC12V, 2.1W / DREP5020LC
DC12V, 1.92W / 3612JL-04W-S49-G51
DC12V, 1.7W / DRCP8020LA
DC12V, 3.2W / DREP5020LB
AC230V, 102W / ISG-3240SSJ
DC12V / GSP-24RW-001F
AC230V, 3.5W / MVCD18AR19
DC12V / NSBY001TJ1
DC 12V / 85 ~ 130mA
DC 12V, 506~588mA
DC 12V / 85 ~ 130mA
DC 200V 0.5A / MDCG-4 (1EA)
DC 200V 0.5A / MDCG-4 (2EA)
125VAC 5A, 250VAC 2.5A
DC 200V 0.5A / MDCG-4 (1EA)
AC 120V, 15A / AC250V, 16A
BSBN (BRASS SCREW)
