  • Page 1
 DOMESTIC
INSTANTANEOUS
GAS
WATER
HEATER

 USER’S
MANUAL













 MINI
12
OF
ErP










 Read
the
technical
instruction
before
installing
the
appliance.
 Read
the
user’s
instruction
before
lighting
the
appliance.



 Cod.
6328400
–
12/2016


...

  • Page 3: Table Of Contents


 This
gas
water
heater
is
ISO9001
certified.
 Thank you for purchasing our large capacity automatic gas water heater. Read this manual before installing and operating and keep for future reference.

 Contents  Special Advice ………………………………………….………………...…………….2  Features & Benefits …………………………………….……………………………….2  Specifications…………………………………………………………………………….3  Parts Name………………………………………………...……………………………..4 ...

  • Page 4: Special Advice



 Special
Advice
 Since
the
combustion
of
the
gas
will
consume
a
large
amount
of
air
and
produce
Carbon
 Monoxide
while
the
heater
is
working.
However,
if
human
inbreathe
too
much
Carbon
Monoxide,
 it
will
cause
danger
or
even
death
.Therefore,
the
users
are
requested
to
install
and
use
this
 heater
strictly
according
to
this
manual
to
avoid
Carbon
Monoxide
toxicosis.
The
manufacturer
or
 any
danger
resulted
from
installation
and
operations
not
bear
responsibility
for
any
danger
 resulted
from
installation
and
operations
not
in
accordance
to
this
manual.




 Features
&
Benefits

 1.

 Automatic
operation
 Simply
turn
on
the
hot
water
tap
or
shower,
and
hot
water
will
arrive.
When
the
tap
is
  turned
off,
the
flame
will
automatically
go
out.
 Independent
 control
 of
 water
 flow
 and
 gas
 flow
 makes
 it
 easy
 to
 adjust
 the
 water
  temperature.

 2.

 Innovative
design
 Sleek
shape
and
convenient
to
install.
...

  • Page 5: Specifications

    Specifications
 Gas‐fired
instantaneous
Water
Heater
 Name MINI
12
OF
ErP
 Model Heat
Input(Hi)

Q 24
kW
 20.4kW
 Heat
Output



P Max
Flow
Rate(rise
 12kg/min
 25℃) Appliance
Type
 11BS Type
of
Gas 2H‐G20‐20mbar/3B‐G30‐30mbar/3P‐G31‐37mbar Gas
category
 II2H3P/II2H3B/P
 Max
water
pressure
 Pw=10bar
 Min
water
pressure
 Pw=0.3bar
 Power
supply
 3v
 Degree
of
electrical
 IPX0
 protection
 Water
Controlled
Automatic
Ignition
 Ignition
method
 Gas
Inlet
 G
1
/
2
or
G
3
/
4
 Cold
Water
 Pipe
 G
1
/
2
 Inlet
 joint
 Hot
Water
 G
1
/
2
 Outlet
 Flue
Duct
...

  • Page 6: Parts Name

    Parts
Name
 Fig.
1
 MINI 12 OF ErP Ø130
 4

...
  • Page 7 Installation
 ●Before
installation
,contact
the
qualified

 technicians
in
local
gas
dealer
or
gas

 management
department
to
do
the
installation
.
 Any
random
or
improper
installation
will

 affect
the
safety
use
of
the
machine
or
even

 damage
users
life.
 ●If
the
flue
type
gas
water
heater
install
a
flue
,

 it
is
strictly
prohibited
to
open
the
mechanical

 ventilation
equipment
like
the
cooker
hood

 and
ventilation
fan
in
rooms
that
are
installed

 or
connected
through
when
it
is
in
operation.

 Installation
requirements
 ●Do
not
install
the
water
heater
in
bedroom
,
 basement
,bathroom
,or
rooms
under
bad
ventilation

 condition
.The
room
for
installation
shall
be
well

 ventilated
and
above
6m² in area .A ventilation hole as well as an exhaust hole must be drilled in the wall ,for venting hole shall be at the level lower than the water heater.(Fig.3)
...

  • Page 8: Installation Method

    Installation
Method

 1. Installation

 Drill
holes
in
the
wall
according
to
Fig.6,
put
an
expansion
bolt
into
the
upper
hole
and
plastic
 gasket
into
the
lower
hole,
mount
the
water
heater
vertically
on
the
upper
bolt
without
 inclination
and
tighten
the
lower
holes
with
expansion
bolts.

 A
 B
 MINI 530.5
 283.5
 12 OF ErP


 Fig.
6
(Unit:mm)
 2.

 Piping
 ●
 L.P.G
users
are
recommended
to
use
2m³/h
pressure
–reducer.
 ●
 Gas
inlet
Faucets
 ⑴
 For
L.P.G
users,
connect
the
gas
inlet
faucet
and
the
gas
pressure‐reducer
of
the
gas
cylinder
 with
special
 Ф9.5mm
rubber
tube,
fasten
the
joints
with
clips.
 ⑵
 For
Natural
Gas
users,
contact
the
gas
dealer
to
connect
with
fit
pipe.
 ⑶
 After
connecting
the
pipes,
check
the
connections
with
soapsuds
for
gas
leak.
 ● Water
Inlet
Faucet
 Remove
the
drain
valve
firstly
to
avoid
breaking
the
anti‐frost
pipe.
It’s
use
the
tube
provided,
 or
you
may
use
rigid
pipe
as
cold‐water
connection.
A
water
controller
shall
be
installed
 before
the
water
inlet
faucet
(Fig.7).
(Note:
There
is
a
filter
inside
the
water
inlet
faucet,
do
 not
remove
it
while
installing).
...
  • Page 9 ● Hot
Water
Outlet
 If
connect
the
hot
water
outlet
directly
to
the
shower,
you
can
use
tube
or
rigid
pipe.
When
 install
control
valve
or
tap
to
the
hot
water
outlet,
or
install
the
shower
with
control
tap,
do
 not
use
pipes
made
of
materials
pressure‐unendurable
or
temperature‐unendurable,
such
as
 plastic
pipes,
aluminum
pipes.
 3.

 Battery
Installation



 Do
not
confuse
the
positive
and
negative
ends
of
the
batteries
(See
Fig.8).

 4.

 Flue
Duct
Installation
 As
This
type
B appliances
shall
only
be
installed
in
the
open
air
or
in
a
room
which
is
 11BS
 separated
from
inhabited
rooms
and
supplied
with
appropriate
ventilation
directly
to
the
 outside.(
The
waste
air
exhaust
pipe
must
be
installed.)
 ●
 The
main
body
of
the
flue
duct
shall
be
n=made
or
rustproof
material.
 ●
 The
horizontal
part
of
the
flue
duct
shall
has
an
1:100
down
inclination,
and
there
shall
be
a
 ф10mm
hole
at
the
bottom
of
the
vertical
part
of
the
duct
outside
the
room,
for
the
purpose
 of
draining
water
drops
 ●
 The
outlet
of
the
flue
duct
shall
have
a
windproof
cap,

 which
should
not
be
clogged.




 Installation
method:
 ●
 Drill
proper
holes
on
the
wall
according
to
the
right

 dimensions
of
the
heater
(See
Fig.9).
...

  • Page 10: Operation Method

    Operation
Method
 1. preparation
Before
Ignition
 ●
 Make
sure
the
type
of
gas
used
complies
with
that
stipulated
in
the
label.
 ●
 Open
the
ventilation
holes.
 ●
 Turn
on
the
gas
inlet
valve.
 2.

 How
To
Ignite
 ●
 Turn
on
the
water
valve
(make
sure
there
is
water
flowing
out
of
the
shower),
the
water
 heater
with
“clicking”
ignition
sound.
The
burner
is
ignited
and
hot
water
flows
out
instantly.
 If
the
water
pressure
is
low,
or
the
power
is
not
connected,
the
water
heater
will
not
operate
 normally.
 ●
 After
initial
installation
or
a
change
of
gas
cylinder
air
may
remain
in
the
gas
pipe
and
it
 requires
several
ignition
attempts
to
push
the
air
out
of
the
pipe
before
the
gas
can
be
ignited.
 If
a
problem
comes
up
after
normal
operation,
turn
off
the
water
immediately.
Try
to
 re‐ignite
10‐20
seconds
later
to
avoid
“pop”
burning.
 ●
 Water
Temperature
Control

 ⑴
 Turn
the
water
flow
control
knob
(rod)
on
the
cover
of
(under)
the
machine
to
control
the
 water
flow
and
its
temperature.
Turn
the
gas
regulator
knob
(rod)
on
the
cover
(bottom)to
 control
the
flame
of
the
burner
thus
controlling
the
hot
water
temperature.
 (2)
turn
the
water
inlet
tap
to
control
water
temperature:
decreasing
the
water
flow
to
make
the
 water
temperature
high
(do
it
slowly,
if
the
flame
extinguishes
then
re‐ignite
by
increasing
the
 water
flow),
and
increasing
the
water
flow
to
make
the
water
temperature
low.
 ●
 Test
water
temperature
with
your
hand
before
using
to
avoid
scalding.(Fig.10)
 ●
 Turn
off
the
gas
valve
after
each
shower.(Fig.11)
 ●
 When
the
outdoor
temperature
is
below
0℃,
the
water
heater
must
be
drained
after
each
 shower
as
follows:
 ⑴
...

  • Page 11: Cautions For Safety






 Cautions
For
Safety
 ■

 Gas
Leakage
Prevention
 ●

 It’s
better
to
install
a
gas
leakage‐warning
device.
 ●

 Check
whether
the
flame
is
extinguished
after
each
shower
and
do
not
forget
to
turn
off
the
 gas
valve(Fig.11)
 ●

 Always
check
all
the
gas
pipe
connections
with
soapsuds
to
see
whether
it
has
gas
leakage.
In
 case
of
gas
leakage,
shut
off
the
gas
supply
and
open
the
windows
immediately.
Under
such
 condition,
ignition,
switching
on/off
the
electric
power
supply
are
strictly
prohibited
to
avoid
 explosion
and
firing.(Fig.12)
 9

...
  • Page 12
 ●

 Keep
on
using
one
type
of
gas
(L.P.G
or
NG),
never
mixing
using
them.
 ●

 Check
the
gas
tube
regularly
as
it
may
age
and
crack
after
long
period
of
usage.
Replace
it
if
 cracked
tubes
are
found.
Under
normal
operation,
the
gas
tube
should
be
replaced
yearly.
 ●

 For
L.P.G
user,
if
the
flame
of
the
heater
is
not
stable,
it
may
be
caused
by
the
breakdown
of
 the
pressure
reduction
valve
connected
to
the
outlet
of
the
gas
tank.
In
that
case,
stop
using
 the
heater
immediately
and
contact
a
service
technician
 ●

 For
NG
users,
if
the
flame
of
the
heater
is
not
stable,
it
may
be
caused
by
the
instability
of
 the
gas
pressure.
In
that
case,
stop
using
the
heater,
otherwise
it
may
be
damaged
or
even
 cause
accident.

 ■

 Fire
Accident
Prevention
 ●

 Make
sure
that
the
flame
of
the
heater
has
extinguished
before
leaving
the
room
or
go
to
 sleep.
 ● Turn
off
the
main
gas
valve
and
the
water
inlet
valve
in
case
of
water
shortage.
 ● Do
 not
 place
 inflammables
 like
 towel
 or
 cloth
 onto
 the
 water
 air
 drain
 outlet
 or
 the
 air
 inlet.(Fig.13)
...
  • Page 13 ● Do
not
pile
inflammables,
explosives
or
volatile
materials
near
the
heater.
(Fig.14)
 ● For
 L.P.G
 users,
 do
 not
 place
 the
 tank
 titled
 or
 inverted,
 otherwise
 the
 liquid
 in
 the
 gas
 cylinder
may
flow
into
the
heater,
and
cause
fired
accident.
 Carbon
Monoxide
Intoxication
Prevention
  The
burning
of
gas
consumes
large
amount
of
air
and
produces
some
amount
of
poisonous
  gas
 like
 carbon
 monoxide.
 Thus,
 the
 heater
 must
 be
 fixed
 in
 a
 ventilated
 location.
 Keep
 exhaust
fan
running
and
the
ventilation
hole
opened.
...

  • Page 14: Maintenance

    knobs,
especially
the
parts
around
the
flame
check
window.
 The
Following
Things
Are
Normal
  When
the
water
pressure
is
lower
than
0.3bar,
the
heater
cannot
be
ignited.
  The
drain
valve
is
dripping.
When
the
water
pressure
is
too
high,
the
drain
valve
will
release
  the
water
so
as
to
reduce
the
pressure
to
protect
the
heater.
 When
the
heater
is
supplying
hot
water
to
too
much
points
at
the
same
time,
the
hot
water
  flow
would
be
reduced,
and
at
times
no
hot
will
issue
at
all.
 During
 shower,
 if
 the
 heater
 is
 operated
 for
 more
 than
 20
 minutes,
 the
 flame
 will
  automatically
turns
off
due
to
the
20‐minute
timer
safety
protection
function
of
the
heater.

 Maintenance


 Check
the
gas
tube/pipe
regularly
for
any
defect.
Contact
service
center
for
any
doubt.
  Clean
the
water
filter
regularly.
  Check
the
water
leakage
regularly.
  When
 the
 flame
 turns
 from
 blue
 to
 yellow
 with
 black
 smoke,
 contact
 the
 service
 center
 ...

  • Page 15: Trouble Shooting

    Trouble
Shooting

 Symptom
 Remedies














 Reasons



 Gas
valve
not
open












 Turn
on
main
valve
or
  replace
the
gas
 Gas
valve
half
open

...
