Motherboard Components
11
12
13
19
14
15
16
24
1
Super P4DP6 motherboard
2
JA4: Ultra SCSI CH B
3
JBT1: CMOS clear
4
JWOR: wake-on-ring Header
5
WOL: wake-on-LAN header
6,7,8,9,10
JP10-JP21: PCI-X bus speed setting
11
USB2, USB3
12
JP32: ACPI/sleep button header
13
JD1: PWR LED/speaker/NMI header
14
JPA1: SCSI termination
15
JA1: Ultra III LVD SCSI CH A
16
J2A/J3A: IDE#1/IDE#2 drive conn.
17
JP7: floppy drive conn.
*
18

IPMI port

19
Adaptec 7899W SCSI chip
20
ICH3
Note: Interleaved ECC registered memory requires DDR DIMMs to be installed in pair.
Front Panel Functions
1
1. 6 SCA Ultra160 hot-swap drive bays
2. 1 slim CD-ROM drive
3. Floppy Drive
4. 1 x 5.25" drive bay
5.
Overheat: Indicates an overheat condition in the system
6.
NIC2: Indicates network activity on LAN2 when flashing
7
NIC1: Indicates network activity on LAN1 when flashing
8.
HDD: Indicates IDE channel activity
9.
Power: Indicates power is being supplied to the system's
power supply units
1
2
3
4
5
56
55
54
6
21
8
7
10
22
18
9
20
33
17
23
25
26
27
28
29
30
21,22
P64H2
23
CPU2 fan
24
JL1: chassis intrusion header
25
CPU2/chassis fan
26
USB 4
27
JP33: CPU1/chassis fan
28
JP9: third power fail header
29
JP36: alarm reset switch
30
JF2: front control panel conn.
31
Secondary ATX power conn.
32, 33
CPU1, CPU2
34, 35, 36, 37
38
ATX power conn.
39
Keyboard & mouse
40
USB 0 & USB1
41, 42
COM1, VGA, parallel port
2
3
4
5 6 7 8
9
58
57
50
53
52
48
51
44
49
46
47
45
34
35
36
37
38
32
31
43
44
45
46
47
48
49
50
51
52
53
Bank1, 2, 3, 4
54
55
56
57
58
Rear Panel Functions
1. AC power connector
2. PS/2 mouse and keyboard ports
3. 2 USB ports
4. COM 1 port
5. VGA port
6. Parallel port
7. 2 x Intel 82550 LAN ports
8. 7 I/O expansion slots
41
40
42
39
Battery
LAN1, LAN2 ports
ATI rage XL graphic chip
Overheat fan
MCH
JP4: VGA enable/disbale
JP38: thermal fan enable/disbale
JP3 /JP27: LAN1/LAN2 enable/disable
JP17/Bus 1B (PCI-X 133MHz, slot #6)
JP18/Bus 1A (PCI-X 133MHz, slot #5)
JP19/Bus 2A (PCI-X 100MHz, slot #4)
JP20/Bus 2B (PCI-X 66MHz, slot #3)
JP21/Bus 2B (PCI-X 66MHz, slot #2)
JP23/Bus 2B (PCI-X 66MHz, slot #1)
JP35: keylock switch conn.
