mySmart MWS3A-PRM-VFC & MWS3A-PRM-VFC-NC Product Manual

MWS3A-PRM-VFC & MWS3A
-PRM-VFC-NC Product Guide
Ceiling Microwave presence/absence detector
Front features
Mounting Bezel
Back features
Retaining Spring
Switched
Output Connector
Retaining Spring
The MWS3A -PRM -VFC Microwave presence detector
provides automatic control of lighting loads with optional
manual control.
The MWS3A -PRM detects movement using a highly
sensitive microwave detector. This works by emitting low
power microwave signals and measuring the re ections as
the signals bounce o moving objects.
The output channel comprises a mains voltage relay
capable of simple on/o switching. This unit provides an
isolated voltage free contact output.
Functioning as a presence detector, the unit can turn lights
on when a room is occupied and o when the room is
empty. Optional settings allow lights to be turned o in
response to ambient daylight.
The MWS3A -PRM has a unique adjustable sensor head
that allows the area of detection to be optimised for the
application.
All functionality is fully programmable using an IR handset.
Two variants are available.
MWS3A -PRM -VFC
MWS3A -PRM -VFC -NC
Microwave Sensor
Detects movement within the unit's detection range,
allowing load control in response to changes in occupancy.
IR Receiver
Receives control and programming commands from an
IR (infrared) handset.
Light Level Sensor
Measures the overall light level in the detection area
Status LEDs
Sensor Lens
which covers...
The LED ashes
Microwave Sensor
Walk Test LED active
IR Receiver
Light Level Sensor
Valid setting received
Status LEDs
Power Input & Switch Input Connector
Used to connect mains power to the unit and to connect a
switch to manually override the lights on or o .
Output Connector
Connection to a switched load.
Power Input &
Switch Input
Ceiling Microwave detector volt free
contact
Ceiling Microwave detector volt free
contact, normally closed fail safe
operation
R ed to indicate the following:
when movement is detected

Overview

Features
