Bond 52661 Owner's Manual

Platinum patio pellet heater
Hide thumbs

Advertisement

Table of Contents

Item # 52661
If you have any questions or concerns, please contact manufacturer at the below resources:
Email: customerservice@ghpgroupinc.com | Website: www.ghpgroupinc.com
Platinum Patio Pellet Heater
DANGER
Toll free phone: 1-877-447-4768 | Monday - Friday, 8:00 am - 4: 30 pm CST
Owner's Manual
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other firepit.
WARNING
For outdoor use only.
WARNING
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Read
the owner's manual thoroughly before
installing or servicing this equipment.
If the information in this manual is not
followed exactly, a fire or explosion
may result causing property damage, or
personal injury.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: retain this manual for
future reference.
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor. Using it
in an enclosed space can kill you. Never
use this appliance in an enclosed space
such as a camper, tent, car or home.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 52661 and is the answer not in the manual?

Questions and answers

Related Manuals for Bond 52661

Summary of Contents for Bond 52661

  • Page 1 Platinum Patio Pellet Heater Item # 52661 WARNING Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other firepit. WARNING For outdoor use only. WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.

  • Page 2: Safety Information

    SAFETY INFORMATION Before you assemble or operate this unit, please carefully read this entire guide. Failure to do so may result in a fire, explosion, injury or death. • FOR OUTDOOR USE ONLY! This pellet heater shall be used only outdoors in a well-ventilated space and shall not be used in a building, garage, or any other enclosed area.
  • Page 3 SAFETY INFORMATION • Children should never operate this unit. • Children and adults should be aware of the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition. • Unit may tip over in high winds. •...
  • Page 4 CONTENTS Item Description Reflector Upper Chimney Middle Chimney Lower Chimney Heater Body Assembly Grate Firepot Heater Base Ash Tray Wheel Assembly Bottom Base Feet Fire Poker Protective Cover Door Handle Assembly...
  • Page 5 ASSEMBLY INSTRUCTIONS 1. Unscrew the lock nut and the latch from the door handle assembly (O). Insert the door handle to the hole on the door, then attach the latch and tighten with lock nut. 2. Attach the heater body assembly (E) to heater base (H) using 7 pcs M6x12 screws (AA).
  • Page 6 ASSEMBLY INSTRUCTIONS 3. Screw in 4 pcs feet (L) to bottom base (K), then attach wheel assembly (J) to bottom base (K) using 2pcs M6x 20 screws (CC) and 2 pcs M6 nuts (DD). 4. Attach bottom base (K) to heater base (H) using 4 pcs M6x 40 screws (EE).
  • Page 7 ASSEMBLY INSTRUCTIONS 6. Insert ash tray (I) into heater base (H). 7. Attach the reflector (A) to upper chimney (B) using 3 wing screws (FF). 8. Attach upper chimney (B) and middle chimney (C) and lower chimney (D) together using 2pcs M6x12 screws (BB) and 2pcs M6x12 screws (AA).
  • Page 8 ASSEMBLY INSTRUCTIONS 9. Attach chimney assembly to heater body assembly (E) using 4pcs M6x12 screws (AA). 10. Your pellet patio heater is now ready for use.

  • Page 9: Operation

    OPERATION 1. Make sure your heater has been assembled properly. 2. Push in the shut-off gate. 3. Fill hopper with pellets. The pellets will not fall into the firepot at this point since the shut-off gate is closed. 4. Open the door, pull out the shut-off gate completely. This will allow pellets to fall into firepot. 5.

  • Page 10: Maintenance

    MAINTENANCE • This outdoor pellet patio heater should be inspected on a regular basis to ensure product safety and long product life. • Check components for any signs of damage. • Wipe exterior surfaces and unit windows with a mild soap and water. Ash tray and ash tray area should be regularly cleaned, once ashes have completely cooled.

  • Page 11: Replacement Parts List

    REPLACEMENT PARTS LIST Item Description Part # Item Description Part # Reflector 30-01-885 Protective Cover 30-01-898 Upper Chimney 30-01-886 Door Handle Assembly 30-01-899 Middle Chimney 30-01-887 Heater Body Cover 30-01-875 Lower Chimney 30-01-888 Small Glass 30-01-876 Heater Body Assembly 30-01-889 Middle Glass 30-01-877 Grate...
