- Page 1 M U LT I B E A M M O V I N G H E A D TYPHOON-120 USER GUIDE 10177 - 1 April 2014 version...
-
Page 2: Important Safety Information
In order to avoid any electrical malfunction, please do not use any multi-socket, power cord extension or connecting system without Any maintenance procedure must be performed by a CONTEST making sure they are perfectly isolated and present no defect. authorised technical service. Basic cleaning operations must tho- roughly follow our safety instructions. -
Page 3: Technical Specifications
Typhoon-120 - Multibeam moving head English 2 - Technical specifications Light sources Movements › 12x10W RGBW LEDs - 50 000 hours (expected) › PAN and TILT movements + lens independent rotation effect › Rotating diffractive lens › Movement range: Pan 540°, Tilt 270° - Non-stop 360° head ›... - Page 4 Typhoon-120 - Multibeam moving head English 3 - Description Microphone Indicator LEDs These 4 LEDs indicate the device status. The microphone is used for the music-sensitive modes. Indication Fuse Is ON when the DMX mode is activated If need to replace the fuse, please make sure the new fuse has MASTER is ON when the Master mode is activated exactly the same characteristics as the original one.
-
Page 5: Internal Menu
Typhoon-120 - Multibeam moving head English 4 - Internal menu 4.1 - Menus and functions Once turned on, the moving head will start a position initialisation for each motor. At this stage, the display indicates . Once the initilisation is over, the display will indicate , you will then be able to access the menu using the MENU or ENTER buttons. - Page 6 Typhoon-120 - Multibeam moving head English Configures the microphone sensitivity. Saves When 000 is selected the microphone is deactivated. changes Activates the PAN movement reversion when the Slave and Show modes are activated, or in Saves DMX mode. changes Press ENTER and select Yes or No with UP and DOWN. Activates the TILT movement reversion when the Slave mode is activated, or in DMX mode.
- Page 7 Typhoon-120 - Multibeam moving head English Channel Mode : 10 Slave Mode : Slave 1 Black-out : No Allows you to reset the following parameters Sound State : Yes Saves and switch to professional mode. Sound Sense : 90 changes Pan Inverse : No Tilt Inverse...
- Page 8 Typhoon-120 - Multibeam moving head English 5 - The various DMX modes As soon as a DMX signal is detected via the DMX IN input, the DMX mode is automatically activated. 5.1 - 1-channel mode Channel Values Action 000 - 007 Black-out 008 - 069 Show 1...
- Page 9 Typhoon-120 - Multibeam moving head English 5.3 - 15-channel mode Channel Values Action 000 - 255 PAN movement 000 - 255 Precise PAN movement 000 - 255 TILT movement 000 - 255 Precise TILT movement 000 - 255 PAN and TILT movement speed 000 - 255 Main Dimmer Strobe...
- Page 10 Typhoon-120 - Multibeam moving head English 5.3 - 15-channel mode (continuation and end) PAN and TILT macros 000 - 007 No function 008 - 015 Macro 1 016 - 023 Macro 2 024 - 031 Macro 3 032 - 039 Macro 4 040 - 047 Macro 5...
- Page 11 Typhoon-120 - Multibeam moving head English 5.4 - 17-channel mode Channel Values Action 000 - 255 PAN movement 000 - 255 Precise PAN movement 000 - 255 TILT movement 000 - 255 Precise TILT movement 000 - 255 PAN and TILT movement speed 000 - 255 Main Dimmer Strobe...
- Page 12 Typhoon-120 - Multibeam moving head English 5.4 - 17-channel mode (continuation and end) Channel Values Action PAN and TILT macros 000 - 007 No function 008 - 015 Macro 1 016 - 023 Macro 2 024 - 031 Macro 3 032 - 039 Macro 4 040 - 047...
- Page 13 Typhoon-120 - Multibeam moving head English 5.5 - 29-channel mode Channel Values Action 000 - 255 PAN movement 000 - 255 Precise PAN movement 000 - 255 TILT movement 000 - 255 Precise TILT movement 000 - 255 PAN and TILT movement speed 000 - 255 Main Dimmer Strobe...
- Page 14 Typhoon-120 - Multibeam moving head English 5.5 - 29-channel mode (continuation and end) Channel Values Action Colour macros (continuation) 140 - 149 Colour macro 13 150 - 159 Colour macro 14 160 - 169 Colour macro 15 170 - 179 Colour macro 16 180 - 189 Colour macro 17...
- Page 15 Typhoon-120 - Multibeam moving head English 6 - DMX cabling and addressing for each mode Unit 1 Unit 2 Unit 3 Unit 4 DMX console DMX mode Unit 1 address Unit 2 address Unit 3 address Unit 4 address 1 channel 10 channels 15 channels 17 channels...
- Page 16 That is why technical specifications and the products physical configuration might differ from the illustrations. Make sure you get the latest news and updates about the CONTEST ® products on www.contest-lighting.com ®...
