SERVICE MANUAL
Ver. 1.2 2006.05
Sony Corporation
9-879-942-03
Personal Audio Division
2006E02-1
Published by Sony Techno Create Corporation
© 2006.05
• The following parts are an available for service parts of this model.
PARTS LIST
Ref. No.
Part No.
Description
3-235-711-01 ATTACHMENT (EAR PAD) (BLACK)...(BLACK)
3-235-711-41 ATTACHMENT (EAR PAD) (GRAY)
...(WHITE, GRAY, BLUE, PINK, GREEN, VIOLET)
501
X-2103-008-1 DIVERGE (LOWER) ASSY (BLACK)...(BLACK)
501
X-2108-547-1 DIVERGE (LOWER) ASSY (WHITE)
...(WHITE, GRAY, BLUE, PINK, GREEN, VIOLET)
501
MDR-NE2
Chinese Model
Remark
• Color Indication of Appearance Parts Example:
KNOB, BALANCE (WHITE) . . . . (RED)
X
Parts color Cabinets color
STEREO EARPHONES
US Model
AEP Model
E Model
X
Advertisement
Table of Contents
Related Manuals for Sony MDR-NE2
Summary of Contents for Sony MDR-NE2
- Page 1 • The following parts are an available for service parts of this model. PARTS LIST Ref. No. Sony Corporation 9-879-942-03 Personal Audio Division 2006E02-1 Published by Sony Techno Create Corporation © 2006.05 MDR-NE2 Part No. Description 3-235-711-01 ATTACHMENT (EAR PAD) (BLACK)…(BLACK) 3-235-711-41 ATTACHMENT (EAR PAD) (GRAY) …(WHITE, GRAY, BLUE, PINK, GREEN, VIOLET)
- Page 2 MDR-NE2 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date 2005.10 2006.02 2006.05 Description of Revision Addition of US, AEP and E model.
