  • ENGLISH, page 11

Quick Links

Quick Start
Thank you for purchasing the MSI
Z370 TOMAHAWK
motherboard.
®
This Quick Start section provides demonstration diagrams about
how to install your computer. Some of the installations also provide
video demonstrations. Please link to the URL to watch it with the web
browser on your phone or tablet. You may have even link to the URL
by scanning the QR code.
Kurzanleitung
Danke, dass Sie das MSI
Z370 TOMAHAWK
Motherboard gewählt
®
haben. Dieser Abschnitt der Kurzanleitung bietet eine Demo zur
Installation Ihres Computers. Manche Installationen bieten auch
die Videodemonstrationen. Klicken Sie auf die URL, um diese
Videoanleitung mit Ihrem Browser auf Ihrem Handy oder Table
anzusehen. Oder scannen Sie auch den QR Code mit Ihrem Handy,
um die URL zu öffnen.
Présentation rapide
Merci d' avoir choisi la carte mère MSI
Z370
TOMAHAWK. Ce
®
manuel fournit une rapide présentation avec des illustrations
explicatives qui vous aideront à assembler votre ordinateur. Des
tutoriels vidéo sont disponibles pour certaines étapes. Cliquez sur
le lien fourni pour regarder la vidéo sur votre téléphone ou votre
tablette. Vous pouvez également accéder au lien en scannant le QR
code qui lui est associé.
Быстрый старт
Благодарим вас за покупку материнской платы MSI
Z370
®
TOMAHAWK. В этом разделе представлена информация,
которая поможет вам при сборке комьютера. Для некоторых
этапов сборки имеются видеоинструкции. Для просмотра
видео, необходимо открыть соответствующую ссылку в
веб-браузере на вашем телефоне или планшете. Вы также
можете выполнить переход по ссылке, путем сканирования
QR-кода.
I
Quick Start

Advertisement

Table of Contents
loading

Summary of Contents for MSI Z370 TOMAHAWK

  • Page 1 Videoanleitung mit Ihrem Browser auf Ihrem Handy oder Table anzusehen. Oder scannen Sie auch den QR Code mit Ihrem Handy, um die URL zu öffnen. Présentation rapide Merci d’ avoir choisi la carte mère MSI Z370 TOMAHAWK. Ce ® manuel fournit une rapide présentation avec des illustrations explicatives qui vous aideront à...
  • Page 2 Installing a Processor/ Installation des Prozessors/ Installer un processeur/ Установка процессора https://youtu.be/4ce91YC3Oww Quick Start...
  • Page 3 Installing DDR4 memory/ Installation des DDR4-Speichers/ Installer une mémoire DDR4/ Установка памяти DDR4 http://youtu.be/T03aDrJPyQs DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Quick Start...
  • Page 4 Connecting the Front Panel Header/ Anschließen der Frontpanel-Stiftleiste/ Connecter un connecteur du panneau avant/ Подключение разъемов передней панели http://youtu.be/DPELIdVNZUI HDD LED + Power LED + HDD LED - Power LED - Reset Switch Power Switch Reset Switch Power Switch JFP1 Reserved No Pin JFP1...
  • Page 5 Installing the Motherboard/ Installation des Motherboards/ Installer la carte mère/ Установка материнской платы Quick Start...
  • Page 6 Installing SATA Drives/ Installation der SATA-Laufwerke/ Installer le disque dur SATA/ Установка дисков SATA http://youtu.be/RZsMpqxythc Quick Start...
  • Page 7 Installing a Graphics Card/ Einbau der Grafikkarte/ Installer une carte graphique/ Установка дискретной видеокарты http://youtu.be/mG0GZpr9w_A Quick Start...
  • Page 8 Connecting Peripheral Devices/ Peripheriegeräte/ Connecter un périphérique anschliessen/ Подключение периферийных устройств VIII Quick Start...
  • Page 9 Connecting the Power Connectors/ Stromanschlüsse anschliessen/ Connecter les câbles du module d’ alimentation/ Подключение разъемов питания http://youtu.be/gkDYyR_83I4 ATX_PWR1 CPU_PWR1 Quick Start...
  • Page 10 Power On/ Einschalten/ Mettre sous-tension/ Включение питания Quick Start...
  • Page 11: Table Of Contents

    Contents Safety Information ....................2 Specifications ......................3 Rear I/O Panel ....................... 8 LAN Port LED Status Table..................8 Audio Ports Configuration ..................8 Realtek HD Audio Manager ..................9 Overview of Components ..................11 CPU Socket ......................12 DIMM Slots ......................13 PCI_E1~6: PCIe Expansion Slots ................
  • Page 12: Safety Information

    Safety Information y The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. y Ensure that all components are securely connected. Loose connections may cause the computer to not recognize a component or fail to start.
  • Page 13: Specifications

    Supports non-ECC, un-buffered memory y Supports Intel Extreme Memory Profile (XMP) ® * Please refer www.msi.com for more information on compatible memory. y 3x PCIe 3.0 x16 slots (support x16/x4/x1 modes)* y 3x PCIe 3.0 x1 slots** Expansion Slots * The PCI_E4 slot will be unavailable when an M.2 PCIe SSD module has been...
  • Page 14 Continued from previous page Intel Z370 Chipset ® y Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices RAID y Supports RAID 0 and RAID1 for M.2 PCIe storage devices* * M.2 PCIe RAID volume can be created with M.2/Optane Genie. y ASMedia ASM3142 Chipset ®...
  • Page 15 Continued from previous page y 1x 24-pin ATX main power connector y 1x 8-pin ATX 12V power connector y 6x SATA 6Gb/s connectors y 2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports) y 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) y 1x 4-pin CPU fan connector y 1x 4-pin water pump fan connector...
  • Page 16 Continued from previous page y Drivers y APP MANAGER y SUPER CHARGER y COMMAND CENTER y LIVE UPDATE 6 y MSI SMART TOOL y RAMDISK y DPC LATENCY TUNER y FAST BOOT y X-BOOST y DRAGON EYE y GAMING APP...
  • Page 17 Continued from previous page y Audio ƒ Audio Boost y Network ƒ GAMING LAN with Gaming LAN Manager y Storage ƒ Twin Turbo M.2 y Fan ƒ Pump Fan ƒ Smart Fan Control y LED ƒ Mystic Light ƒ Mystic Light Extension (RGB) ƒ...
  • Page 18: Rear I/O Panel

    Rear I/O Panel Audio Ports USB 3.1 Gen1 PS/2 USB 3.1 Gen2 DVI-D Optical S/PDIF-Out USB 2.0 USB 3.1 Gen1 USB 3.1 Gen2 Type-C LAN Port LED Status Table Link/ Activity LED Speed LED Status Description Status Description No link 10 Mbps connection Yellow Linked...
  • Page 19: Realtek Hd Audio Manager

    Realtek HD Audio Manager After installing the Realtek HD Audio driver, the Realtek HD Audio Manager icon will appear in the system tray. Double click on the icon to launch. Device Selection Advanced Settings Jack Status Application Enhancement Connector Main Volume Settings Profiles y Device Selection - allows you to select a audio output source to change the related...
  • Page 20 Audio jacks to headphone and microphone diagram Audio jacks to stereo speakers diagram AUDIO INPUT Audio jacks to 7.1-channel speakers diagram AUDIO INPUT Rear Front Side Center/ Subwoofer Rear I/O Panel...
  • Page 21: Overview Of Components

    Overview of Components DIMMA1 SYS_FAN1 DIMMA2 CPU_FAN1 CPU_PWR1 DIMMB1 DIMMB2 CPU Socket PUMP_FAN1 SYS_FAN4 EZ Debug LED ATX_PWR1 JUSB3 M2_1 JBAT1 PCI_E1 JUSB4 PCI_E2 SATA▼1▲2 PCI_E3 SATA▼3▲4 PCI_E4 M2_2 SATA▼5▲6 PCI_E5 JCI1 PCI_E6 JAUD1 SYS_FAN3 JCOM1 JFP1 SYS_FAN2 JFP2 JRGB1 JUSB2 JPWRLED1 JUSB1...
  • Page 22: Cpu Socket

    Always unplug the power cord from the power outlet before installing or removing the CPU. Please retain the CPU protective cap after installing the processor. MSI will deal with Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket.
  • Page 23: Dimm Slots

    DIMM Slots DIMMA1 DIMMB1 Channel A Channel B DIMMA2 DIMMB2 Memory module installation recommendation DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Important Always insert memory modules in the DIMMA2 slot first. Due to chipset resource usage, the available capacity of memory will be a little less than the amount of installed.
  • Page 24: Pci_E1~6: Pcie Expansion Slots

    The PCI_E2 slot will be unavailable when an expansion card has been installed in the PCI_E3 slot. If you install a large and heavy graphics card, you need to use a tool such as MSI Gaming Series Graphics Card Bolster to support its weight to prevent deformation of the slot.
  • Page 25: M2_1~2: M.2 Slots (Key M)

    M2_1~2: M.2 Slots (Key M) Important Intel RST only supports PCIe M.2 SSD with UEFI ROM, ® does not support Legacy ROM. Intel Optane™ Memory Ready for all M.2 slots. ® Video Demonstration M2_1 Watch the video to learn how to Install M.2 module.
  • Page 26: Sata1~6: Sata 6Gb/S Connectors

    SATA1~6: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 Important The SATA1/ SATA5 port will be unavailable when an M.2 SATA SSD module has been installed in the M2_1/ M2_2 slot.
  • Page 27: Jfp1, Jfp2: Front Panel Connectors

    M.2 slots with examples of various combination possibilities 2xM.2 PCIe SSDs + 6xSATA HDDs 2xM.2 SATA SSDs + 4xSATA HDDs PCIe SATA SATA PCIe 1xM.2 SATA SSD + 1xM.2 PCIe SSD + 5xSATA HDDs 1xM.2 PCIe SSD + 6xSATA HDDs SATA PCIe PCIe...
  • Page 28: Cpu_Pwr1, Atx_Pwr1: Power Connectors

    CPU_PWR1, ATX_PWR1: Power Connectors These connectors allow you to connect an ATX power supply. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground...
  • Page 29: Jusb1~2: Usb 2.0 Connectors

    JUSB1~2: USB 2.0 Connectors These connectors allow you to connect USB 2.0 ports on the front panel. USB0- USB1- USB0+ USB1+ Ground Ground No Pin Important Note that the VCC and Ground pins must be connected correctly to avoid possible damage.
  • Page 30: Cpu_Fan1, Pump_Fan1, Sys_Fan1~4: Fan Connectors

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~4: Fan Connectors Fan connectors can be classified as PWM (Pulse Width Modulation) Mode or DC Mode. PWM Mode fan connectors provide constant 12V output and adjust fan speed with speed control signal. DC Mode fan connectors control fan speed by changing voltage. When you plug a 3-pin (Non-PWM) fan to a fan connector in PWM mode, the fan speed will always maintain at 100%, which might create a lot of noise.
  • Page 31: Jaud1: Front Audio Connector

    JAUD1: Front Audio Connector This connector allows you to connect audio jacks on the front panel. MIC L Ground MIC R Head Phone R MIC Detection SENSE_SEND No Pin Head Phone L Head Phone Detection JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis intrusion event...
  • Page 32: Jtpm1: Tpm Module Connector

    JTPM1: TPM Module Connector This connector is for TPM (Trusted Platform Module). Please refer to the TPM security platform manual for more details and usages. LPC Clock 3V Standby power LPC Reset 3.3V Power LPC address & data pin0 Serial IRQ LPC address &...
  • Page 33: Jrgb1: Rgb Led Connector

    Always turn off the power supply and unplug the power cord from the power outlet before installing or removing the RGB LED strip. Please use MSI’ s software to control the extended LED strip. JCOM1: Serial Port Connector This connector allows you to connect the optional serial port with bracket.
  • Page 34: Ez Debug Led

    EZ Debug LED These LEDs indicate the debug status of the motherboard. CPU - indicates CPU is not detected or fail. DRAM - indicates DRAM is not detected or fail. VGA - indicates GPU is not detected or fail. BOOT - indicates the booting device is not detected or fail.
  • Page 35: Bios Setup

    Press Delete key, when the Press DEL key to enter Setup Menu, F11 to enter Boot Menu message appears on the screen during the boot process. y Use MSI FAST BOOT application. Click on GO2BIOS button and choose OK. The system will reboot and enter BIOS setup directly.
  • Page 36: Resetting Bios

    Updating BIOS Updating BIOS with M-FLASH Before updating: Please download the latest BIOS file that matches your motherboard model from MSI website. And then save the BIOS file into the USB flash drive. Updating BIOS: 1. Press Del key to enter the BIOS Setup during POST.
  • Page 37: Ez Mode

    EZ Mode At EZ mode, it provides the basic system information and allows you to configure the basic setting. To configure the advanced BIOS settings, please enter the Advanced Mode by pressing the Setup Mode switch or F7 function key. XMP switch Setup Mode switch Screenshot...
  • Page 38 y Information display - click on the CPU, Memory, Storage, Fan Info and Help buttons on left side to display related information. y Function buttons - enable or disable the LAN Option ROM, M.2/Optane Genie, Hardcore Mode, AHCI, RAID, CPU Fan Fail Warning Control and BIOS Log Review by clicking on their respective button.
  • Page 39: Advanced Mode

    Advanced Mode Press Setup Mode switch or F7 function key can switch between EZ Mode and Advanced Mode in BIOS setup. XMP switch Setup Mode switch Screenshot Search Language System information GAME BOOST switch Boot device priority bar BIOS menu BIOS menu selection selection...
  • Page 40: Oc Menu

    OC Menu This menu is for advanced users who want to overclock the motherboard. Important Overclocking your PC manually is only recommended for advanced users. Overclocking is not guaranteed, and if done improperly, it could void your warranty or severely damage your hardware. If you are unfamiliar with overclocking, we advise you to use GAME BOOST function for easy overclocking.
  • Page 41 f CPU Ratio Mode [Dynamic Mode]* Selects the CPU Ratio operating mode. This item will appear when you set the CPU ratio manually. [Fixed Mode] Fixes the CPU ratio. [Dynamic Mode] CPU ratio will be changed dynamically according to the CPU loading.
  • Page 42 f CPU Base Clock (MHz) [Default] Sets the CPU Base clock. You may overclock the CPU by adjusting this value. Please note that overclocking behavior and stability is not guaranteed. This item appears when a CPU that support this function is installed. f CPU Base Clock Apply Mode [Auto]* Sets the applying mode for adjusted CPU base clock.
  • Page 43 f DigitALL Power Press Enter to enter the sub-menu. Controls the digital powers related to CPU PWM. fCPU Loadline Calibration Control [Auto] The CPU voltage will decrease proportionally according to CPU loading. Higher load-line calibration could get higher voltage and good overclocking performance, but increase the temperature of the CPU and VRM.
  • Page 44 f DRAM Voltages control [Auto] These options allow you to set the voltages related to memory. If set to Auto, BIOS will set these voltages automatically or you can set it manually. f PCH Voltages control [Auto] These options allow you to set the voltages related to PCH. If set to Auto, BIOS will set these voltages automatically or you can set it manually.
  • Page 45 fLimit CPUID Maximum [Disabled] Enables or disables the extended CPUID value. [Enabled] BIOS limits the maximum CPUID input value to circumvent boot problems with older operating system that do not support the processor with extended CPUID value. [Disabled] Use the actual maximum CPUID input value. fIntel Virtualization Tech [Enabled] Enables or disables Intel Virtualization technology.
  • Page 46 fC1E Support [Disabled] Enables or disables the C1E function for power-saving in halt state. This item appears when Intel C-State is enabled. [Enabled] Enables C1E function to reduce the CPU frequency and voltage for power-saving in halt state. [Disabled] Disables this function. fPackage C State limit [Auto] This item allows you to select a CPU C-state level for power-saving when system is idle.
  • Page 47 fSW Guard Extensions (SGX) [Software Control] Enables or disables Intel SGX. BIOS Setup...
  • Page 48: Software Description

    7. Follow the instructions on the screen to install Windows ® Installing Drivers 1. Start up your computer in Windows ® 2. Insert MSI Driver Disc into your optical drive. ® 3. The installer will automatically appear and it will find and list all necessary drivers.
  • Page 49 Table des matières Informations de sécurité ..................2 Spécifications ......................3 Panneau arrière Entrée/ Sortie ................8 Tableau explicatif de l’ état de la LED du port LAN ..........8 Configuration des ports audio ................8 Realtek HD Audio Manager ..................9 Vue d’...
  • Page 50: Informations De Sécurité

    Informations de sécurité y Les composants dans l’ emballage peuvent être endommagés par des décharges électrostatiques (ESD). Pour vous assurer de correctement monter votre ordinateur, veuillez vous référer aux instructions ci-dessous. y Assurez-vous de bien connecter tous les composants. En cas de mauvaise connexion, il se peut que l’...
  • Page 51: Spécifications

    Support Intel Extreme Memory Profile (XMP) ® * Veuillez vous référer au site www.msi.com pour plus d’ informations sur la mémoire compatible. y 3 x slots PCIe 3.0 x16 (support mode x16/x4/x1)* y 3 x slots PCIe 3.0 x1 ** Slots d’...
  • Page 52 ** La carte hôte U.2 n’ est pas fournie. *** Référez-vous au manuel de configuration de la mémoire Intel Optane™ sur ® le site officiel MSI. Chipset Intel Z370 ® y Support des architectures RAID 0, RAID 1, RAID 5 et RAID 10 pour les périphériques de stockage SATA...
  • Page 53 Suite du tableau de la page précédente 1 x contrôleur Intel I219-V Gigabit LAN y 1 x port clavier/ souris PS/2 y 2 x ports USB 2.0 Type-A y 1 x port DVI-D y 1 x port USB 3.1 Gen2 Type-A y 1 x port USB 3.1 Gen2 Type-C Connecteurs sur le panneau arrière...
  • Page 54 Google Chrome™, Google Toolbar et Google Drive y Norton™ Internet Security Solution * Cette fonctionnalité dépend d’ une offre limitée dans le temps. Veuillez vous référer au site www.msi.com pour plus d’ informations. Suite du tableau sur la page suivante Spécifications...
  • Page 55 Suite du tableau de la page précédente y Audio ƒ Audio Boost y Network ƒ GAMING LAN avec Gaming LAN Manager y Stockage ƒ Twin Turbo M.2 y Ventilateur ƒ Ventilateurs pour la pompe ƒ Contrôle des ventilateurs y LED ƒ...
  • Page 56: Panneau Arrière Entrée/ Sortie

    Panneau arrière Entrée/ Sortie Ports Audio USB 3.1 Gen1 PS/2 USB 3.1 Gen2 DVI-D Sortie S/PDIF optique USB 2.0 USB 3.1 Gen1 USB 3.1 Gen2 Type-C Tableau explicatif de l’ état de la LED du port LAN LED indiquant la connexion LED indiquant la vitesse et l’...
  • Page 57: Realtek Hd Audio Manager

    Realtek HD Audio Manager Après l’ installation du pilote Realtek HD Audio, l’ icône Realtek HD Audio Manager apparaît dans la barre des tâches du système. Double-cliquez sur l’ icône pour lancer le programme. Sélection du périphérique Paramètres avancés Etat des prises Jack Amélioration d’...
  • Page 58 Ilustration de l’ utilisation des ports audio dédiés au casque et au microphone Ilustration de l’ utilisation du port audio dédié aux haut-parleurs AUDIO INPUT Ilustration de l’ utilisation des ports audio dédiés aux haut-parleurs 7.1 AUDIO INPUT Rear Front Side Center/ Subwoofer...
  • Page 59 Vue d’ ensemble des composants DIMMA1 SYS_FAN1 DIMMA2 CPU_FAN1 CPU_PWR1 DIMMB1 Socket DIMMB2 processeur PUMP_FAN1 SYS_FAN4 EZ Debug LED ATX_PWR1 JUSB3 M2_1 JBAT1 PCI_E1 JUSB4 PCI_E2 SATA▼1▲2 PCI_E3 SATA▼3▲4 PCI_E4 M2_2 SATA▼5▲6 PCI_E5 JCI1 PCI_E6 JAUD1 SYS_FAN3 JCOM1 JFP1 SYS_FAN2 JFP2 JRGB1 JUSB2...
  • Page 60: Vue D' Ensemble Des Composants

    électrique. Veuillez garder le capot de protection du processeur après l’ installation du processeur. Selon les exigences de RMA (Return Merchandise Authorization), MSI n’ acceptera pas les cartes mère dont le capot de protection aura été retiré.
  • Page 61: Slots Dimm

    Slots DIMM DIMMA1 DIMMB1 Canal A Canal B DIMMA2 DIMMB2 Installation recommandée de module mémoire DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Important Veillez à toujours insérer un module de mémoire dans l’ emplacement DIMMA2 en premier. Du fait des ressources utilisées par le chipset, la capacité de mémoire disponible est un peu moins élevée que celle installée.
  • Page 62: Pci_E1~6: Slots D' Extension Pcie

    PCI_E3. Si vous installez une carte graphique lourde, il vous faut utiliser un outil comme la barre de support MSI Gaming Series pour supporter son poids et pour éviter la déformation du slot. Si vous choisissez d’ installer une seule carte d’ extension PCIe x16, nous vous recommandons d’...
  • Page 63: M2_1~2: Slots M.2 (Touche M)

    M2_1~2: Slots M.2 (Touche M) Important La technologie Intel RST supporte seulement un SSD ® M.2 PCIe avec une mémoire ROM UEFI et non avec une mémoire ROM Legacy. Intel Optane™ Memory Ready pour tous les slots M.2. ® M2_1 Vidéo de démonstration Référez-vous à...
  • Page 64: Sata1~6: Connecteurs Sata 6 Gb/S

    SATA1~6: Connecteurs SATA 6 Gb/s Ces connecteurs utilisent une interface SATA 6 Gb/s. Chaque connecteur peut être relié à un appareil SATA. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 Important Le port SATA1/ SATA5 est indisponible lorsqu’ un SSD M.2 SATA est installé dans le slot M2_1/ M2_2.
  • Page 65: Jfp1, Jfp2: Connecteurs De Panneau Avant

    Combinaison des slots M.2 2 x SSDs M.2 PCIe + 6 x disques 2 x SSDs M.2 SATA + 4 x disques durs SATA durs SATA PCIe SATA SATA PCIe 1 x SSD M.2 SATA + 1 x SSD M.2 PCIe + 1 x SSD M.2 PCIe + 6 x disques durs 5 x disques durs SATA SATA...
  • Page 66: Cpu_Pwr1, Atx_Pwr1: Connecteurs D' Alimentation

    CPU_PWR1, ATX_PWR1: Connecteurs d’ alimentation Ces connecteurs vous permettent de relier une alimentation ATX. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground...
  • Page 67: Jusb1~2: Connecteurs Usb 2.0

    Notez que les broches VCC et Terre doivent être branchées correctement afin d’ éviter tout dommage sur la carte mère. Pour recharger votre iPad, iPhone et iPod par l’ intermédiaire d’ un port USB, veuillez installer l’ utilitaire MSI SUPER CHARGER. ®...
  • Page 68: Cpu_Fan1, Pump_Fan1, Sys_Fan1~4: Connecteurs Pour Ventilateurs

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~4: Connecteurs pour ventilateurs Les connecteurs pour ventilateurs peuvent être utilisés en mode PWM (Pulse Width Modulation) et en mode DC. En mode PWM, les connecteurs fournissent une sortie de 12V constante et ajustent la vitesse des ventilateurs avec un signal de contrôle de vitesse.
  • Page 69: Jaud1: Connecteur Audio Avant

    JAUD1: Connecteur audio avant Ce connecteur se lie aux jacks audio du panneau avant. MIC L Ground MIC R Head Phone R MIC Detection SENSE_SEND No Pin Head Phone L Head Phone Detection JCI1: Connecteur intrusion châssis Ce connecteur est relié à un câble d’ interrupteur intrusion châssis. Normal Commencer l’...
  • Page 70: Jtpm1: Connecteur De Module Tpm

    JTPM1: Connecteur de module TPM Ce connecteur est relié à un module TPM (Trusted Platform Module). Veuillez vous référer au manuel du module TPM pour plus d’ informations. LPC Clock 3V Standby power LPC Reset 3.3V Power LPC address & data pin0 Serial IRQ LPC address &...
  • Page 71: Jrgb1: Connecteur Led Rgb

    Avant d’ installer ou de retirer le ruban LED, veillez à toujours éteindre l’ alimentation et à débrancher le câble d’ alimentation de la prise électrique. Veuillez utiliser un logiciel MSI dédié pour contrôler le ruban d’ extension LED. JCOM1: Connecteur de port série Ce connecteur vous permet de relier un port série en option.
  • Page 72: Ez Debug Led

    EZ Debug LED Ces LED indiquent l’ état de débogage de la carte mère. CPU - indique que le CPU n’ est pas détecté ou que son initialisation a échoué. DRAM -indique que la mémoire DRAM n’ est pas détectée ou que son initialisation a échoué. VGA - indique que le GPU n’...
  • Page 73: Configuration Du Bios

    Menu, F11 to enter Boot Menu” sur l’ écran, veuillez appuyer sur la touche Suppr. y Quand l’ ordinateur est déjà en marche, vous pouvez utiliser l’ application MSI FAST BOOT. Cliquez sur le bouton GO2BIOS puis sur OK. Le système redémarre et entre dans l’...
  • Page 74: Réinitialiser Le Bios

    Avant la mise à jour : Veuillez télécharger la dernière version de BIOS compatible à votre carte mère sur le site MSI. Ensuite, veuillez sauvegarder le nouveau BIOS sur le lecteur flash USB. Mettre le BIOS à jour : 1. Appuyez sur la touche Suppr pour entrer dans l’ interface Setup du BIOS pendant le processus de POST.
  • Page 75: Ez Mode (Mode Simplifié)

    EZ Mode (mode simplifié) Le mode EZ vous fournit les informations basiques du système et vous permet de configurer les réglages de base. Si vous souhaitez configurer les réglages du BIOS, veuillez utiliser le mode Advanced en appuyant sur le switch Setup Mode (Interrupteur de modes de réglages) ou la touche de fonction F7.
  • Page 76 y Informations du système - montre la vitesse et la tension du processeur et de la mémoire, la température du processeur et de la carte mère, le type de carte mère et de processeur, la capacité mémoire, la version du BIOS et la date d’ installation. y Barre priorité...
  • Page 77: Advanced Mode (Mode Avancé)

    Advanced Mode (mode avancé) Appuyez sur le Setup Mode switch (interrupteur de modes de réglages) ou sur la touche de fonction F7 pour commuter entre le mode simplifié et le mode avancé. Interrupteur de Capture modes de réglages Interrupteur XMP Recherche d’...
  • Page 78: Oc Menu (Menu Overclocking)

    OC Menu (menu overclocking) Ce menu est destiné aux utilisateurs avancés souhaitant overclocker leur carte mère. Important L’ overclocking manuel du PC n’ est recommandé que pour les utilisateurs avancés. L’ overclocking n’ est pas garanti et une mauvaise manipulation peut rendre nulle votre garantie et sévèrement endommager votre matériel.
  • Page 79 f Adjusted CPU Frequency Montre la fréquence ajustée du processeur. Fonctionne en lecture seule. f CPU Ratio Mode [Dynamic Mode]* Choisit le mode d'opération du ratio du processeur. Ce menu apparaît lorsque vous réglez le ratio manuellement. [Fixed Mode] Fixe le ratio. [Dynamic Mode] Le ratio sera modifié...
  • Page 80 fEnhanced Turbo [Auto]* Active ou désactive la fonction Enhanced Turbo pour tous les coeurs du processeur afin d’ augmenter les performances du processeur. Ce menu apparaît lorsque le processeur installé prend cette fonction en charge. [Auto] Ce réglage est configuré automatiquement par le BIOS. [Enabled] Le ratio de tous les coeurs du processeur sont augmentés au maximum.
  • Page 81 f Advanced DRAM Configuration Appuyez sur la touche Entrée pour entrer dans le sous-menu. L’ utilisateur peut régler la synchronisation de mémoire de chaque barrette de mémoire. Le système peut être instable ou peut ne plus redémarrer après le changement de la synchronisation de la mémoire.
  • Page 82 fCPU VRM Over Temperature Protection [Enabled] Active ou désactive le CPU VRM pour la protection sur-température. f CPU Core/ GT Voltage Mode [Auto]* Définit le mode pour la tension du cœur du processeur et la tension GT. [Auto] Ce réglage est configuré automatiquement par le BIOS. [Adaptive Mode] Définit la tension adaptative automatiquement pour l’...
  • Page 83 f MEMORY-Z Appuyez sur la touche Entrée pour accéder au sous-menu. Ce sous-menu affiche tous les réglages et timings de la mémoire installée. Vous pouvez également accéder à ce sous-menu à tout moment en appuyant sur la touche [F5]. fDIMMx Memory SPD Appuyez sur la touche Entrée pour accéder au sous-menu.
  • Page 84 fAdjacent Cache Line Prefetch [Enabled] Active ou désactive le prefetcher matériel du processeur (MLC Spatial prefetcher). [Enabled] Active le prefetcher de la ligne de cache adjacente pour réduire le temps de latence et ajuster les performances dans l’ application spécifique. [Disabled] Active seulement la ligne de cache exigée.
  • Page 85 fIntel Turbo Boost [Enabled] Active ou désactive la technologie Intel Turbo Boost. Cette fonction est pensée ® pour le mode Normal et apparaît lorsque le processeur installé prend cette fonction en charge. [Enabled] Active la fonction d’ augmentation automatique des performances du processeur afin de dépasser limite définie lorsque le système exige un niveau de performances plus élevée.
  • Page 86: Informations Sur Les Logiciels

    ® Installer les pilotes 1. Allumez l’ ordinateur sous Windows ® 2. Insérez le disque MSI Driver Disc dans le lecteur optique. ® 3. L’ outil d’ installation apparaît automatiquement. Il trouvera et listera tous les pilotes dont vous avez besoin.
  • Page 87 Inhalt Sicherheitshinweis ....................2 Spezifikationen ...................... 3 Rückseite E/A ......................8 LAN Port LED Zustandstabelle ................8 Konfiguration der Audioanschlüsse ............... 8 Realtek HD Audio Manager ..................9 Übersicht der Komponenten ................11 CPU Sockel ......................12 DIMM-Steckplätze ....................13 PCI_E1~6: PCIe Erweiterungssteckplätze ............
  • Page 88: Sicherheitshinweis

    Sicherheitshinweis y Die im Paket enthaltene Komponenten sind der Beschädigung durch elektrostatischen Entladung (ESD). Beachten Sie bitte die folgenden Hinweise, um die erfolgreichen Computermontage sicherzustellen. y Stellen Sie sicher, dass alle Komponenten fest angeschlossen sind. Lockere Steckverbindungen können Probleme verursachen, zum Beispiel: Der Computer erkennt eine Komponente nicht oder startet nicht.
  • Page 89: Spezifikationen

    Unterstützt Intel Extreme Memory Profile (XMP) ® * Weitere Informationen zu kompatiblen Speicher finden Sie unter: http://www.msi.com. y 3x PCIe 3.0 x16-Steckplätze (unterstützt x16/x4/x1 Modi)* y 3x PCIe 3.0 x1-Steckplätze** Erweiterung- * Der PCI_E4-Steckplatz wird nicht zur Verfügung, wenn Sie ein M.2 PCIe SSD anschlüsse...
  • Page 90 ** Die Turbo U.2 Hostkarte ist im Lieferumfang nicht enthalten, bitte separat kaufen. ***Weitere Informationen finden Sie die Konfigurationsanleitung des Intel ® Optane Speicher auf der MSI Wesite. ™ Intel Z370 Chipsatz ® y Unterstützt RAID 0, RAID1, RAID 5 und RAID 10 für SATA Speichergeräte...
  • Page 91 Fortsetzung der vorherigen Seite y Realtek ALC892 Codec ® Audio y 7.1-Kanal-HD-Audio y Unterstützt S/PDIF-Ausgang 1x Intel I219-V Gigabit LAN Controller y 1x PS/2 Tastatur/ Maus-Combo-Anschluss y 2x USB 2.0 Typ-A Anschlüsse y 1x DVI-D Anschluss y 1x USB 3.1 Gen2 Typ-A Anschluss y 1x USB 3.1 Gen2 Typ-C Anschluss Hintere Ein-/ und Ausgänge...
  • Page 92 Extreme Tuning Utility ® y Google Chrome , Google Toolbar, Google Drive ™ y Norton Internet Security Solution ™ * Dieses Angebot steht nur für begrenzte Zeit zur Verfügung, weitere Informationen finden Sie unter www.msi.com Fortsetzung auf der nächsten Seite Spezifikationen...
  • Page 93 Fortsetzung der vorherigen Seite y Audio ƒ Audio Boost y Netzwerk ƒ GAMING LAN mit Gaming LAN Manager y Speicherung ƒ Twin Turbo M.2 y Lüfter ƒ Pump-Lüfter ƒ Smart-Lüftersteuerung y LED ƒ Mystic Light ƒ Mystic Light Extension (RGB) ƒ...
  • Page 94: Rückseite E/A

    Rückseite E/A Audioanschlüsse USB 3.1 Gen1 PS/2 USB 3.1 Gen2 DVI-D Optischer S/PDIF- USB 2.0 Ausgang USB 3.1 Gen1 USB 3.1 Gen2 Typ-C LAN Port LED Zustandstabelle Verbindung/ Aktivität LED Geschwindigkeit LED Zustand Bezeichnung Zustand Bezeichnung Keine Verbindung 10 Mbps-Verbindung Gelb Verbindung Grün...
  • Page 95: Realtek Hd Audio Manager

    Realtek HD Audio Manager Nach der Installation des Realtek HD Audio-Treibers, wird das Symbol Realtek HD Audio Manager in der Taskleiste angezeigt. Klicken Sie doppelt auf dieses Symbol, um das Programm zu starten. Geräteauswahl Erweiterte Einstellungen Verbindungs- status Optimierungen Lautstärke Anschlüsse Profil y Geräteauswahl - Ermöglicht die Auswahl der Audio-Ausgangs Quelle.
  • Page 96 Audiobuchsen für den Anschluss von einem Kopfhörer und Mikrofon Audiobuchsen für Stereo-Lautsprecher AUDIO INPUT Audiobuchsen für 7,1 Kanal Anlage AUDIO INPUT Rear Front Side Center/ Subwoofer Rückseite E/A...
  • Page 97: Übersicht Der Komponenten

    Übersicht der Komponenten DIMMA1 SYS_FAN1 DIMMA2 CPU_FAN1 CPU_PWR1 DIMMB1 DIMMB2 CPU Sockel PUMP_FAN1 SYS_FAN4 EZ Debug LED ATX_PWR1 JUSB3 M2_1 JBAT1 PCI_E1 JUSB4 PCI_E2 SATA▼1▲2 PCI_E3 SATA▼3▲4 PCI_E4 M2_2 SATA▼5▲6 PCI_E5 JCI1 PCI_E6 JAUD1 SYS_FAN3 JCOM1 JFP1 SYS_FAN2 JFP2 JRGB1 JUSB2 JPWRLED1 JUSB1...
  • Page 98: Cpu Sockel

    Sie jedoch bitte sicher, dass die betroffenen Komponenten mit den abweichenden Einstellungen während des Übertaktens zurecht kommen. Von jedem Versuch des Betriebes außerhalb der Produktspezifikationen kann nur abgeraten werden. MSI übernehmt keinerlei Garantie für die Schäden und Risiken, die aus einem unzulässigem Betrieb oder einem Betrieb außerhalb der Produktspezifikation resultieren.
  • Page 99: Dimm-Steckplätze

    DIMM-Steckplätze DIMMA1 DIMMB1 Kanal A Kanal B DIMMA2 DIMMB2 Speichermodul-Installationsempfehlung DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Wichtig Um einen sicheren Systemstart zu gewährleisten, bestücken Sie immer DIMMA2 zuerst. Aufgrund der Chipsatzressourcennutzung wird die verfügbare Kapazität des Speichers kleiner sein als die Größe der installierten Speicherkapazität. Basierend auf der Intel CPU Spezifikation wird eine Speicherspannung unter 1,35 Volt vorgeschlagen, um die CPU zu schützen.
  • Page 100: Pci_E1~6: Pcie Erweiterungssteckplätze

    PCI_E1~6: PCIe Erweiterungssteckplätze PCI_E1: PCIe 3.0 x16 (CPU Lanes) PCI_E2: PCIe 3.0 x1 (PCH Lanes) PCI_E3: PCIe 3.0 x1 (PCH Lanes) PCI_E4: PCIe 3.0 x4 (PCH Lanes) PCI_E5: PCIe 3.0 x1 (PCH Lanes) PCI_E6: PCIe 3.0 x1 (PCH Lanes) Mehrere Grafikkarten Einbauempfehlung Wichtig Der PCI_E4-Steckplatz wird nicht zur Verfügung, wenn Sie ein M.2 PCIe SSD Modul im M2_2-Steckplatz installieren.
  • Page 101: M2_1~2: M.2 Slots (Key M)

    M2_1~2: M.2 Slots (Key M) Wichtig Intel RST unterstützt nur PCIe M.2 SSD mit UEFI ROM, ® Legacy-ROM wird NICHT unterstützt. Intel Optane Technik unterstützt alle M.2 Steckplätze. ® ™ Video-Demonstration M2_1 Eine anschauliche Darstellung zur Installation eines M.2 Moduls finden Sie im Video.
  • Page 102: Sata1~6: Sata 6 Gb/S Anschlüsse

    SATA1~6: SATA 6 Gb/s Anschlüsse Dieser Anschluss basiert auf der Hochgeschwindigkeitsschnittstelle SATA 6 Gb/s. Pro Anschluss kann ein SATA Gerät angeschlossen werden. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 Wichtig Der SATA1/ SATA5 Anschluss ist nicht verfügbar, wenn Sie ein M.2 SATA SSD Modul im the M2_1-/ M2_2-Steckplatz installieren.
  • Page 103: Jfp1, Jfp2: Frontpanel-Anschlüsse

    M.2 Steckplätze mit Beispielen zu den verschiedenen Kombinationsmöglichkeiten 2xM.2 PCIe SSDs + 6xSATA HDDs 2xM.2 SATA SSDs + 4xSATA HDDs PCIe SATA SATA PCIe 1xM.2 SATA SSD + 1xM.2 PCIe SSD + 5xSATA HDDs 1xM.2 PCIe SSD + 6xSATA HDDs SATA PCIe PCIe...
  • Page 104: Cpu_Pwr1, Atx_Pwr1: Stromanschlüsse

    CPU_PWR1, ATX_PWR1: Stromanschlüsse Mit diesen Anschlüssen verbinden Sie die ATX Stromstecker. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground Wichtig Stellen Sie sicher, dass alle Anschlüsse mit den richtigen Anschlüssen des Netzteils verbunden sind, um einen stabilen Betrieb der Hauptplatine sicherzustellen.
  • Page 105: Jusb1~2: Usb 2.0 Anschlüsse

    Bitte beachten Sie, dass Sie die mit VCC (Stromführende Leitung) und Ground (Erdung) bezeichneten Pins korrekt verbinden müssen, ansonsten kann es zu Schäden kommen. Um ein iPad, iPhone und einen iPod über USB-Anschlüsse aufzuladen, installieren Sie bitte die MSI SUPER CHARGER Software. ® JUSB3~4: USB 3.1 Gen1 Anschlüsse Mit diesen Anschlüssen können Sie die USB 3.1 Gen1 Anschlüsse auf dem Frontpanel...
  • Page 106: Cpu_Fan1, Pump_Fan1, Sys_Fan1~4: Stromanschlüsse Für Lüfter

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~4: Stromanschlüsse für Lüfter Diese Anschlüsse können im PWM (Pulse Width Modulation) Modus oder Spannungsmodus betrieben werden. Im PWM-Modus bieten die Lüfteranschlüsse konstante 12V Ausgang und regeln die Lüftergeschwindigkeit per Drehzahlsteuersignal. Im DC-Modus bestimmen die Lüfteranschlüsse die Lüftergeschwindigkeit durch Ändern der Spannung. Wenn Sie ein 3-Pin (Non-PWM) Lüfter an einen PWM-Modus Lüfteranschluss anschließen, läuft der Lüfter mit höchster Drehzahl und kann unangenehm laut werden.
  • Page 107: Jaud1: Audioanschluss Des Frontpanels

    JAUD1: Audioanschluss des Frontpanels Dieser Anschluss ermöglicht den Anschluss von Audiobuchsen eines Frontpanels. MIC L Ground MIC R Head Phone R MIC Detection SENSE_SEND No Pin Head Phone L Head Phone Detection JCI1: Gehäusekontaktanschluss Dieser Anschluss wird mit einem Kontaktschalter verbunden. Normal Löse den Gehäuseeingriff aus...
  • Page 108: Jtpm1: Tpm Anschluss

    JTPM1: TPM Anschluss Dieser Anschluss wird für das TPM Modul (Trusted Platform Module) verwendet. Weitere Informationen über den Einsatz des optionalen TPM Modules entnehmen Sie bitte dem TPM Plattform Handbuch. LPC Clock 3V Standby power LPC Reset 3.3V Power LPC address & data pin0 Serial IRQ LPC address &...
  • Page 109: Jrgb1: Rgb Led Anschluss

    Schalten Sie die Stromversorgung aus und ziehen Sie das Netzkabel ab, bevor Sie die RGB-LED-Streifen ein- und ausbauen. Bitte verwenden Sie die MSI-Software zur Steuerung des LED-Leuchtstreifens. JCOM1: Serieller Anschluss Mit diesem Anschluss können Sie das optionale serielle Schnittstelle mit dem Einbausatze verbinden.
  • Page 110: Ez Debug Led

    EZ Debug LED Diese LEDs zeigen den Debug-Status des Motherboards an. CPU - CPU wird nicht erkannt oder ist fehlerhaft. DRAM - DRAM wird nicht erkannt oder ist fehlerhaft. VGA - GPU wird nicht erkannt oder ist fehlerhaft. BOOT - Boot-Gerät wird nicht erkannt oder ist fehlerhaft.
  • Page 111: Bios-Setup

    Während des BOOT-Vorgangs drücken Sie die Taste ENTF, wenn die Meldung Press DEL key to enter Setup Menu, F11 to enter Boot Menu erscheint. y Verwenden Sie die MSI FAST BOOT Anwendung. Klicken Sie die GO2BIOS-Taste und drücken Sie OK. Das System startet neu und geht direkt ins BIOS.
  • Page 112: Reset Des Bios

    Before updating: Vorbereitung: Laden Sie bitte die neueste BIOS Version, die dem Motherboard-Modell entspricht, von der offiziellen MSI Website herunter und speichern Sie die BIOS-Datei auf USB-Flash- Laufwerk. BIOS-Aktualisierungsschritte: 1. Drücken Sie während des POST-Vorgangs die Taste (Entf), um das BIOS zu öffnen.
  • Page 113: Ez Modus

    EZ Modus Im EZ-Modus können Sie die Grundinformationen des Systems einsehen und grundlegende Einstellungen konfigurieren. Um sich die erweiterten BIOS- Einstellungen anzeigen zu lassen, aktivieren Sie bitte den Erweiterten Modus durch Drücken des Setup Modus Schalter oder der Funktionstaste F7. XMP Schalter Setup Modus Schalter Screenshot...
  • Page 114 y Boot-Geräte Prioritätsleiste - Sie können die Gerätesymbole verschieben, um die Startreihenfolge zu ändern. Die Bootreihenfolge sind mit “hoch” (links) bis “niedrig” (rechts) bezeichnet. y Informationsanzeige - Klicken Sie auf die Schaltfläche CPU, Memory, Storage, Fan Info und Help auf der linken Seite, um die jeweiligen Informationen anzuzeigen. y Funktionstasten - Aktivieren oder deaktivieren Sie LAN Option ROM, M.2/Optane Genie, Hardcore-Modus, AHCI, RAID, CPU Fan Fail Warning Control und BIOS Log Review durch Anklicken der zugehörigen Schaltfläche.
  • Page 115: Erweiterter Modus

    Erweiterter Modus Drücken Sie den Setup Modus Schalter oder die Funkionstaste F7, um zwischen dem EZ-Modus und Erweiterten-Modus im BIOS-Setup zu wechseln. XMP Schalter Setup Modus Schalter Screenshot Suchen Sprache System- information GAME BOOST Schalter Bootgeräte- Prioritätsleiste BIOS-Menü BIOS-Menü -Auswahl -Auswahl Menüanzeige y GAME BOOST Schalter/ XMP Schalter/ Setup Modus Schalter/ Screenshot/...
  • Page 116: Oc Menü

    OC Menü In diesem Menü können Benutzer das BIOS anpassen und das Mainboard übertakten. Bitte führen Sie nur Änderungen durch, wenn Sie sich über das Ergebnis im Klaren sind. Sie sollten Erfahrung beim Übertakten haben, da Sie sonst das Motherboard oder Komponenten des Systems beschädigen können.
  • Page 117 f 1/2/3/4-Core Ratio Limit [Auto]* Hier können Sie den CPU Multiplikator für die verschiedenen aktiven Kerne einstellen. Diese Option erscheint nur, wenn eine CPU installiert ist, die diese Funktion unterstützt. f Adjusted CPU Frequency Zeigt die eingestellte Frequenz der CPU an. Es handelt sich um eine Anzeige – Änderungen sind nicht möglich.
  • Page 118 fIntel Turbo Boost [Enabled]* Aktivieren oder deaktivieren Sie Intel Turbo Boost. Diese Option wird angezeigt, ® wenn die installierte CPU diese Einstellungen unterstützt. [Enabled] Aktivieren Sie diese Funktion, um die CPU-Leistung automatisch zu erhöhen, wenn das System mehr Leistung benötigt. [Disabled] Deaktivieren Sie diese Funktion.
  • Page 119 f DRAM Timing Mode [Link] Wählt den Speicher-Timing-Modus aus. [Link] Ermöglicht die manuelle Konfigurieren des DRAM-Timing für alle Speicherkanäle. [UnLink] Ermöglicht die manuelle Konfigurieren des DRAM-Timing für die einzelnen Speicherkanäle. f Advanced DRAM Configuration Drücken Sie die Eingabetaste <Enter>, um das Untermenü aufzurufen. Der Anwender kann die Speicher-Timing für jeden Kanal des Speichers einstellen.
  • Page 120 fCPU Over Current Protection [Auto] Legen Sie den aktuellen Grenzwert für den CPU-Überstromschutz fest. Wenn die Einstellung auf Auto gesetzt ist, wird das BIOS diese Einstellungen automatisch konfigurieren. fCPU Switching Frequency [Auto] Stellen Sie die PWM Arbeitsgeschwindigkeit ein, um die CPU Core-Spannung und den Ripple Bereich zu stabilisieren.
  • Page 121 f OC Quick View Timer [3 Sec]* Legt die Dauer der Anzeigezeit von Übertaktung-Einstellungswerten fest. Wenn die Einstellung auf Deaktiviert gesetzt ist, wird das BIOS die unterschiedlichen OC- Einstellungen nicht anzeigen. f CPU Specifications Drücken Sie die Eingabetaste <Enter>, um das Untermenü aufzurufen. Das Untermenü...
  • Page 122 fIntel VT-D Tech [Disabled] Aktiviert oder deaktiviert die Intel VT-D (Intel Virtualization for Directed I/O) Technologie. fHardware Prefetcher [Enabled] Aktivieren oder deaktivieren Sie das Hardware Prefetcher (MLC Streamer prefetcher). [Enabled] Der CPU Hardware Prefetcher kann frühzeitig Daten und Anweisungen aus dem Speicher in den L2-Cache aden um die Cache-Latency Zeiten zu reduzieren.
  • Page 123 fCFG Lock [Enabled] Sperren oder Entsperren des MSR 0xE2[15]s, des CFG Lock-Bits. [Enabled] Sperrt das CFG Lock-Bit. [Disabled] Entsperrt das CFG Lock-Bit. fEIST [Enabled] Aktivieren oder deaktivieren Sie die Enhanced Intel SpeedStep Technologie. Diese ® Option wird angezeigt, wenn OC Explore Mode auf Normal eingestellt. [Enabled] Aktiviert EIST, um die CPU-Spannung und Taktfrequenz dynamisch anzupassen.
  • Page 124: Softwarebeschreibung

    ® Installation von Treibern 1. Starten Sie Ihren Computer mit Windows ® 2. Legen Sie die MSI Treiber Disk in das optisches Laufwerk. ® 3. Der Installer wird automatisch erscheint und findet und finden Sie die benötigten Treiber in die Liste.
  • Page 125 Содержание Безопасное использование продукции ............2 Технические характеристики ................ 3 Задняя панель портов ввода/ вывода ............8 Таблица состояний индикатора порта LAN ........... 8 Конфигурация портов Аудио ................8 Менеджер Realtek HD Audio ................9 Компоненты материнской платы ............... 11 Процессорный...
  • Page 126: Безопасное Использование Продукции

    Безопасное использование продукции y Компоненты, входящие в комплект поставки могут быть повреждены статическим электричеством. Для успешной сборки компьютера, пожалуйста, следуйте указаниям ниже. y Убедитесь, что все компоненты компьютера подключены должным образом. Ослабленные соединения компонентов могут привести как к сбоям в работе, так и полной неработоспособности компьютера. y Чтобы...
  • Page 127: Технические Характеристики

    Поддержка non-ECC, небуферизованной памяти y Поддержка Intel Extreme Memory Profile (XMP) ® * Пожалуйста, обратитесь www.msi.com для получения дополнительной информации о совместимых памяти. y 3x слота PCIe 3.0 x16 (поддержка режима x16/x4/x1)* y 3x слота PCIe 3.0 x1** Слоты...
  • Page 128 SATA HDD. Пожалуйста, обратитесь к странице 16 для по получения информации о использовании комбинаций портов M.2. ** Turbo U.2 адаптер не входит в комплект поставки и приобретается отдельно. *** Пожалуйста, обратитесь к руководству по конфигурации памяти Optane™ на веб-сайте MSI. Intel ® Чипсет Intel Z370 ®...
  • Page 129 Продолжение с предыдущей страницы 1x Гигабитный сетевой контроллер Intel I219-V y 1x комбинированный порт PS/2 клавиатуры/ мыши y 2x порта USB 2.0 Type-A y 1x порт DVI-D y 1x порт USB 3.1 Gen2 Type-A y 1x порт USB 3.1 Gen2 Type-C Разъемы...
  • Page 130 Extreme Tuning Utility ® y Google Chrome , Google Toolbar, Google Drive ™ y Norton Internet Security Solution ™ * Это предложение годно в течение ограниченного периода времени, для получения дополнительной информации посетите сайт www.msi.com Продолжение на следующей странице Технические характеристики...
  • Page 131 Продолжение с предыдущей страницы y Аудио ƒ Audio Boost y Сеть ƒ GAMING LAN с контроллером Gaming LAN Manager y Накопитель ƒ Twin Turbo M.2 y Вентикатор ƒ Pump Fan ƒ Интеллектуальное управление скоростью вращения вентиляторов y Индикатор ƒ Mystic Light ƒ...
  • Page 132: Задняя Панель Портов Ввода/ Вывода

    Задняя панель портов ввода/ вывода Порты Аудио USB 3.1 Gen1 PS/2 USB 3.1 Gen2 DVI-D Оптический S/PDIF-Out USB 2.0 USB 3.1 Gen1 USB 3.1 Gen2 Type-C Таблица состояний индикатора порта LAN Подключение/ Работа Скорость передачи данных индикатора Состояние Описание Состояние Описание...
  • Page 133: Менеджер Realtek Hd Audio

    Менеджер Realtek HD Audio После установки драйвера Realtek HD Audio, в системном трее появится значок Realtek HD Audio Manager. Дважды щелкните по значку для запуска приложения. Выбор устройства Расширенные настройки Состояние Дополнительные разъемов эффекты Мастер- Настройки громкость подключений Профили y Выбор устройства - позволяет выбрать источник аудио выхода и изменить соответствующие...
  • Page 134 Подключение наушников и микрофона Подключение внешнего стерео усилителя (колонок) AUDIO INPUT Подключение звуковой системы 7.1 AUDIO INPUT Rear Front Side Center/ Subwoofer Задняя панель портов ввода/ вывода...
  • Page 135: Компоненты Материнской Платы

    Компоненты материнской платы DIMMA1 SYS_FAN1 DIMMA2 CPU_FAN1 Процессорный CPU_PWR1 DIMMB1 сокет DIMMB2 PUMP_FAN1 SYS_FAN4 EZ Debug LED ATX_PWR1 JUSB3 M2_1 JBAT1 PCI_E1 JUSB4 PCI_E2 SATA▼1▲2 PCI_E3 SATA▼3▲4 PCI_E4 M2_2 SATA▼5▲6 PCI_E5 JCI1 PCI_E6 JAUD1 SYS_FAN3 JCOM1 JFP1 SYS_FAN2 JFP2 JRGB1 JUSB2 JPWRLED1 JUSB1...
  • Page 136: Процессорный Сокет

    питания. Пожалуйста, сохраните защитную крышку процессорного сокета после установки процессора. Любые возможные гарантийные случаи, связанные с работой материнской платы, MSI будет рассматривать только, при наличии защитной крышки на процессорном сокете. При установке процессора обязательно установите процессорный кулер. Кулер, представляющий собой систему охлаждения процессора, предотвращает...
  • Page 137: Слоты Dimm

    Слоты DIMM DIMMA1 DIMMB1 Канал A Канал B DIMMA2 DIMMB2 Рекомендации по установке модулей памяти DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Внимание! Всегда устанавливайте модуль памяти сначала в слот DIMMA2. В связи со спецификой использования ресурсов чипсета, доступный объем памяти...
  • Page 138: Pci_E1~6: Слоты Расширения Pcie

    Порт PCI_E2 будет недоступен при установке карты расширения в слоте PCI_E3. При установке массивной видеокарты, необходимо использовать такой инструмент, как MSI Gaming Series Graphics Card Bolster для поддержки веса графической карты и во избежание деформации слота. Для установки одной карты расширения PCIe x16 с оптимальной...
  • Page 139: M2_1~2: Разъемы M.2 (Ключ M)

    M2_1~2: Разъемы M.2 (Ключ M) Внимание! RST поддерживает только PCIe M.2 SSD с Intel ® UEFI ROM и не поддерживает устройства с Legacy ROM. Технология Intel Optane™ совместима с любым ® разъемом M.2. M2_1 Видео Инструкция Смотрите видео, чтобы узнать как M2_2 установить...
  • Page 140: Sata1~6: Разъемы Sata 6 Гб/С

    SATA1~6: Разъемы SATA 6 Гб/с Эти разъемы представляют собой интерфейсные порты SATA 6 Гб/с. К каждому порту можно подключить одно устройство SATA. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 Внимание! Порт SATA1/ SATA5 будет недоступен при установке модуля M.2 SATA SSD в разъеме...
  • Page 141: Jfp1, Jfp2: Разъемы Передней Панели

    Разъемы М.2 и различные возможные примеры использования 2xM.2 PCIe SSDs + 6xSATA HDDs 2xM.2 SATA SSDs + 4xSATA HDDs PCIe SATA SATA PCIe 1xM.2 SATA SSD + 1xM.2 PCIe SSD + 5xSATA HDDs 1xM.2 PCIe SSD + 6xSATA HDDs SATA PCIe PCIe JFP1, JFP2: Разъемы...
  • Page 142: Cpu_Pwr1, Atx_Pwr1: Разъемы Питания

    CPU_PWR1, ATX_PWR1: Разъемы питания Данные разъемы предназначены для подключения блока питания ATX. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground Внимание! Для...
  • Page 143: Jusb1~2: Разъемы Usb 2.0

    Внимание! Помните, что во избежание повреждений, необходимо правильно подключать контакты VCC и земли. Для того, чтобы зарядить ваш iPad, iPhone и iPod через порты USB, пожалуйста, установите утилиту MSI SUPER CHARGER. ® JUSB3~4: Разъемы USB 3.1 Gen1 Данные разъемы предназначены для подключения портов USB 3.1 Gen1 на...
  • Page 144: Cpu_Fan1, Pump_Fan1, Sys_Fan1~4: Разъемы Вентиляторов

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~4: Разъемы вентиляторов Разъемы вентиляторов можно разделить на два типа: с PWM (PulseWidth Modulation) управлением и управлением постоянным током. Разъемы вентиляторов с PWM управлением имеют контакт с постоянным напряжением 12В, а также контакт с сигналом управления скоростью вращения. Управление скоростью...
  • Page 145: Jaud1: Разъем Аудио Передней Панели

    JAUD1: Разъем аудио передней панели Данный разъем предназначен для подключения аудиоразъемов передней панели. MIC L Ground MIC R Head Phone R MIC Detection SENSE_SEND No Pin Head Phone L Head Phone Detection JCI1: Разъем датчика открытия корпуса К этому разъему подключается кабель от датчика открытия корпуса. Нормально...
  • Page 146: Jtpm1: Разъем Модуля Tpm

    JTPM1: Разъем модуля TPM Данный разъем используется для подключения модуля ТРМ (Trusted Platform Module). Дополнительные сведения см. в описании модуля ТРМ. LPC Clock 3V Standby power LPC Reset 3.3V Power LPC address & data pin0 Serial IRQ LPC address & data pin1 5V Power LPC address &...
  • Page 147: Jrgb1: Разъем Rgb Led

    Обратите внимание, что длина лент должна быть не более 2 метров, иначе яркость свечения будет падать. Перед установкой или заменой светодиодных лент RGB, необходимо полностью обесточить систему и отключить кабель питания. Используйте утилиту MSI для управления удлинительными ® светодиодными лентами.
  • Page 148: Индикаторы Отладки Ez

    Индикаторы отладки EZ Данные индикаторы указывают состояние отладки материнской платы. CPU - процессор не обнаружен или поврежден. DRAM - память DRAM не обнаружена или повреждена. VGA - видеокарта не обнаружена или повреждена. BOOT - устройство загрузки не обнаружено или повреждено. JPWRLED1: Индикатор...
  • Page 149: Настройка Bios

    Нажмите клавишу Delete, когда появляется сообщение на экране Press DEL key to enter Setup Menu, F11 to enter Boot Menu во время загрузки. y При помощи приложения MSI FAST BOOT. Нажмите на кнопку GO2BIOS и выберите ОК. Система перезагрузится и автоматически войдет в настройки...
  • Page 150: Сброс Bios

    обратитесь к разделу “Джампер очистки данных CMOS” . Обновление BIOS Обновление BIOS при помощи M-FLASH Подготовительные операции: Пожалуйста, скачайте последнюю версию файла BIOS с сайта MSI, который соответствует вашей модели материнской платы. Сохраните файл BIOS на флэш-диске USB. Обновление BIOS: 1.
  • Page 151: Режим Ez

    Режим EZ Режим EZ предоставляет основную информацию о системе и позволяет выполнить основные операции по настройке. Для настройки расширенных функций BIOS, пожалуйста, войдите в Расширенный режим, путем нажатия Переключатель режимов установки или при помощи функциональной клавиши F7. Переключатель режимов установки Переключатель...
  • Page 152 y Язык - позволяет выбрать язык интерфейса для настройки BIOS y Информация о системе - показывает частоту процессора/ памяти, температуру процессора/ материнской платы, информацию о материнской плате/процессоре, размер памяти, напряжение на процессоре/ памяти, версию BIOS и дату создания. y Приоритет загрузочных устройств - вы можете переместить инонку устройства...
  • Page 153: Режим Разгона

    Режим разгона Нажмите переключатель режимов установки или функциональную клавишу F7 для переключения между режимами EZ и разгона в настройках BIOS. Переключатель Переключатель XMP Скриншот Поиск режимов установки Язык Информация о системе Переключатель Приоритет GAME BOOST загрузочных устройств Выбор меню Выбор меню...
  • Page 154: Меню Oc

    Меню OC Данное меню предназначено для опытных пользователей и предоставляет возможности для «разгона» системы. Внимание! Разгонять ПК вручную рекомендуется только опытным пользователям. Производитель не гарантирует успешность разгона. Неправильное выполнение разгона может привести к аннулированию гарантии и серьезному повреждению оборудования. Неопытным пользователям рекомендуется использовать функцию GAME BOOST.
  • Page 155 f 1/2/3/4-Core Ratio Limit [Auto]* Данные опции позволяют настроить множители процессора для различных ядер. Данные пункты доступны, только если процессор поддерживает данную функцию. f Adjusted CPU Frequency Показывает текущую частоту процессора. Это значение нельзя изменять. f CPU Ratio Mode [Dynamic Mode]* Выбор...
  • Page 156 fIntel Turbo Boost [Enabled]* Включение или выключение Intel Turbo Boost. Этот пункт появляется, ® когда установленный процессор поддерживает данную функцию. Включение этой функции приводит к автоматическому [Enabled] увеличению производительности процессора. Функция выключена. [Disabled] fEnhanced Turbo [Auto]* Функция Enhanced Turbo позволяет увеличивать частоту на всех ядрах процессора.
  • Page 157 f Memory Try It ! [Disabled] Позволяет улучшить совместимость памяти и производительность, путем выбора наиболее оптимального пресета. f DRAM Timing Mode [Link] Режимы таймингов памяти. Позволяет пользователю настроить тайминги DRAM вручную [Link] для всех каналов памяти. Позволяет пользователю настроить тайминги DRAM вручную [UnLink] для...
  • Page 158 fCPU Under Voltage Protection [Auto] Устанавливает нижнюю границу напряжения для защиты процессора от пониженного напряжения. Если установлено Auto, BIOS автоматически настроит этот параметр. Чем выше значение, тем ниже степень защиты и выше вероятность выхода системы из строя. fCPU Lite Load [Auto] Уменьшает...
  • Page 159 f PCH Voltages control [Auto] Эти параметры позволяют вам задать напряжения, связанные с памятью. При установке в Auto, BIOS установит напряжения автоматически. Вы также можете настроить напряжения вручную. f CPU Memory Changed Detect [Enabled]* Включение или выключение предупреждающих сообщений при загрузке системы, когда...
  • Page 160 fLimit CPUID Maximum [Disabled] Включение или выключение расширенных значений CPUID. BIOS будет ограничивать максимальное входное значение [Enabled] CPUID для обхода проблемы загрузки в устаревших операционных системах, не поддерживающих процессор с расширенными значениями CPUID. Используйте фактическое максимальное входное значение [Disabled] CPUID. fIntel Virtualization Tech [Enabled] Включение...
  • Page 161 fIntel C-State [Auto] Включение или выключение Intel C-state. C-state - это технология управления питанием процессора, определяемая ACPI. Параметр будет настроен автоматически с помощью BIOS. [Auto] Определяет состояние простоя системы и значительно [Enabled] сокращает энергопотребление процессором. Выключение функции. [Disabled] fC1E Support [Disabled] Включение...
  • Page 162 fLong Duration Maintained (s) [Auto] Настроит максимальное время работы процессора с ограничением мощности при Long Duration Power Limit. fShort Duration Power Limit (W) [Auto] Настроить предельную мощность TDP процессора при кратковременных нагрузках в режиме Turbo Boost. fCPU Current Limit (A) [Auto] Устанавливает...
  • Page 163: Описание Программного Обеспечения

    7. Следуйте инструкциям на экране, чтобы установить Windows ® Установка драйверов 1. Загрузите компьютер в Windows ® 2. Вставьте диск с драйверами MSI Driver Disc в привод для оптических ® дисков. 3. Автоматически отобразится окно установщика, который найдет и перечислит все необходимые драйверы.
  • Page 164 Примечание Описание программного обеспечения...
  • Page 165 The point of contact for regulatory matters is MSI, recycling and disposing of their end-of-life products. MSI-NL Eindhoven 5706 5692 ER Son. y Visit the MSI website and locate a nearby distributor B급 기기 (가정용 방송통신기자재) for further recycling information.
  • Page 166 MSI will comply with the product take entregar a una empresa autorizada para la recogida de back requirements at the end of life of MSI-branded estos residuos.
  • Page 167 MSI si adeguerà a tale Direttiva ritirando tutti i prodotti marchiati MSI che sono stati venduti all’interno dell’Unione Europea alla fine del loro ciclo di vita.
  • Page 168 Alternatively, please try the following help resources for further guidance. y Visit the MSI website for technical guide, BIOS updates, driver updates, and other information: http://www.msi.com y Register your product at: http://register.msi.com...

Table of Contents
