MikroTik CRS106-1C-5S Quick Start Manual

CRS106-1C-5S
CRS106-1C-5S
The CRS106-1C-5S is a network switch with five SFP ports and one Ethernet/SFP combo port. It is already configured, with all ports switched together.
We recommend you set up a password to secure your device.
Safety Warnings
Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.
Powering
The power consumption of this device under maximum load is up to 11 W. The device accepts powering in the following ways:
Direct-input power jack (5.5mm outside and 2mm inside, female, pin positive plug) accepts 8-30 V DC.
The combo ethernet port accepts passive Power over Ethernet 8-30 V DC, PoE injector is not included.
Setup
The device has five SFP ports and one SFP/Ethernet combo port. This unit is compatible with 100Mbit and 1.25G SFP modules. The ETH/SFP combo
interface has two connectors on the back of the unit, of which only one can be used at the same time, the used port will be automatically recognized as
Combo1. It is possible to select which physical port will be used in the software ethernet menu. If left to default "auto", first to initialize will be used.
First use
Connect your WAN cable to port 1, and the other devices to ports 2-5.
Set client device IP configuration to automatic (DHCP).
The default IP address from ports 2-5 (LAN) is 192.168.88.1.
Username is admin, there is no password
Secure the device by setting up a password.
Configuration
(or, for some models, check user and wireless passwords on the sticker) .
