- Page 1 IS161 Rev.03 02/09/2019 BIONIK4 Barriera automatica Brushless Automatic barrier Brushless Automatisierung für Schranke Brushless Barrière automatique Brushless Barrera automática Brushless Barreira automática Brushless IT - Istruzioni ed avvertenze per l'installatore EN - Instruction and warnings for the installer DE - Anleitungen und Hinweise für den Installateur...
- Page 2 Avvertenze generali Consignes générales de sécurité Dichiarazione di conformità Déclaration de conformité Destinazione d’uso Destination d’utilisation Limiti di impiego Limites d’emploi Descrizione del prodotto Description du produit Dimensioni Dimensions Contenuto dell’imballo Contenu de l’emballage Caratteristiche tecniche Caractéristiques techniques Installazione tipo Installation type Riferimenti e accessori References et accessoires...
-
Page 3: General Safety Precautions
INTENDED USE The BIONIK4 automated barrier is specifically conceived for installations in private or public car parks, in residential, commercial or industrial areas or in high traffic zones. This product may only be used for its expressly intended purpose. Any other usage is prohibited. -
Page 4: Description Of The Product
BIONIK4 barriers are suitable for CONTINUOUS operation and may be used with booms up to 4 metres in length. DESCRIPTION OF THE PRODUCT 36V DC BIONIK4 BRUSHLESS barrier for booms up to 3 or 4 metre, with control unit and on-board native encoder, complete with a fastening base BI/004 with tie rods and screws and boom fastening flanges. -
Page 5: Technical Characteristics
RELEASE SYSTEM KEY WITH A STANDARD CYLINDER KEY WITH A STANDARD CYLINDER TYPICAL INSTALLATION 1 10 Automatic Barrier BIONIK4 serie Reflective sticker Integrated control unit Internal Photocell Flashing lights Fixed end rest for boom complete with a shock-resistant rubber mechanical stop... - Page 6 REFERENCES AND ACCESSORIES 17 19 Code Description Code Description BI/004 Red Ø72 spring (for booms and accessories, see chap. Barrier unit cabinet, in carbon steel with anti-corrosion 17 SP/72/01 treatment and painted. BI/004/115 18 KT231 Fixed end rest fastening plate. Key release with a standard lock 19 BAFS/01 Fixed end rest, non-adjustable, with rubber buffer.
-
Page 7: Installation
INSTALLATION 11.1 Preliminary checks • Check that the material received is in good condition and suitable for the application. • Check that the operating limits of the product are not exceeded. KT240 • Check that the site chosen for installation meets the overall space requirements of the product and that there are no obstacles hindering open or close manoeuvres. - Page 8 90° 22 22...
- Page 9 OPENING Selecting direction of aperture ON THE LEFT OPENING BIONIK4 barriers are configured by default for installation on the right hand side (seen from the ON THE RIGHT inspection hatch side). Whenever corrective actions are carried out, pay the utmost attention when releasing, locking or moving the internal mechanical parts. These operations could be hazardous for the installer.
- Page 10 11.5 Support and boom installation 1. Unlock the barrier (see chapter 21). 2. Based on the opening direction of the barrier (fig. 7), turn the linkage lever until reaching the stop on the mechanical limit switch (fig. 7), in the position in which it is possible to install the boom horizontally.
- Page 11 INSTALLING AND ADJUSTING THE SPRING • Select the desired opening direction as indicated in paragraph 11.4. • Unlock the barrier (see chapter 21) and move the boom into the completely open vertical position. • Select the most suitable spring (see tables in paragraph 12.1). •...
- Page 12 12.1 Spring selection The booms are understood as complete with shock-resistant rubber and LED strips. BA/68/3 BA/68/3 BA/68/4 (with boom from 2,2 to 2,80 m) (boom up to 3 m) (boom up to 4 m) NOT AVAILABLE NOT AVAILABLE NOT AVAILABLE NOT AVAILABLE NOT AVAILABLE NOT AVAILABLE...
-
Page 13: Adjusting The Mechanical Stop
ADJUSTING THE MECHANICAL STOP The figure shows the mechanical stop on a barrier installed on the LEFT hand side. For barriers installed on the RIGHT, perform the mirror images of the procedures illustrated. • Unlock the barrier (see chapter 21). •... -
Page 14: Electrical Connections
ELECTRICAL CONNECTIONS All electrical connections must be made with the unit disconnected from mains power and, if applicable, battery power. See controller manual for instructions on making connections and programming. Before connecting to electrical power, ensure that the mains power specifications on the identification plate match the mains power supply used. - Page 15 INSTALLING THE BI/BLED LED FLASHING LIGHT The BI/BLED flashing lamp unit is factory supplied already pre-installed in the head [A], packaged separately inside the BIONIK4 package. 1. Insert the connector [B] in the LIGHT terminal of the control unit. 2. Refer to the control unit manual for the flashing lamp unit settings.
-
Page 16: Maintenance
• Check that there are now plants within the radius of action of the boom which ROGER TECHNOLOGY is the exclusive proprietor holder of all rights regarding this could interfere with the photocells or with the movements of the boom itself.
