- Page 1 IS194 Rev.01 05/11/2019 BIONIK8 Barriera automatica Brushless Automatic barrier Brushless Automatisierung für Schranke Brushless Barrière automatique Brushless Barrera automática Brushless Barreira automática Brushless IT - Manuale di installazione EN - Instruction and warnings for the installer DE - Anleitungen und Hinweise für den Installateur FR - Instructions et avertissements pour l'installateur ES -...
-
Page 2: General Safety Precautions
This installation manual is intended for qualified personnel only. ROGER TECHNOLOGY cannot be held responsible for any damage or injury due to improper use or any use other the intended usage indicated in this manual. Installation, electrical connections and adjustments must be performed by qualified personnel, in accordance with best practices and in compliance with applicable regulations. -
Page 3: Description Of The Product
5 DESCRIPTION OF THE PRODUCT BIONIK BRUSHLESS 36V DC Barrier for bars up to 8 metres, with on-board control unit, digital absolute encoder, complete with fixing base with BI/008 tie rods and screws, and boom fixing flange. BIONIK BRUSHLESS 36V DC Barrier for bars up to 8 metres, with on-board control unit, digital absolute encoder, complete with fixing base with BI/008/115 tie rods and screws, and boom fixing flange. -
Page 4: Technical Characteristics
8 TECHNICAL CHARACTERISTICS BI/008 BI/008/115 POWER SUPPLY 230 Vac - 50 Hz ±10% 115 Vac 60 Hz ±10% MOTOR POWER SUPPLY 0 ÷ 36 Vdc 0 ÷ 36 Vdc POWER CONSUMPTION 0 ÷ 18 A 0 ÷ 18 A POWER MOTOR... - Page 5 10 REFERENCES AND ACCESSORIES 15 16 17 18 Code Description Code Description Carbon steel barrier assembly cabinet with anti-corrosion Fixed support with rubber, NOT-adjustable, with provision BAFS/03 treatment, painted. of a bolt. Aluminium boom support base, die-cast, with anti-corrosion BAFS/02 Fixed support with rubber, adjustable, telescopic.
-
Page 6: Installation
11 INSTALLATION 11.1 Preliminary checks • Check that the material received is in good condition and suitable for the application. • Check that the operating limits of the product are not exceeded. • Check that the site chosen for installation meets the overall space requirements of the product and that there are no obstacles hindering open or close manoeuvres. •... - Page 7 11.3 Installing the barrier NOTE: the barrier is configured by default for installation on the right hand side (viewed from inspection hatch side). • Undo and remove the washers and nuts from the anchors on the base plate (fig. 3). •...
- Page 8 11.4 Selecting direction of aperture BIONIK barriers are configured by default for installation on the INSTALLATION ON right hand side (seen from the inspection hatch side). THE RIGHT INSTALLATION OF THE LEFT Whenever corrective actions are carried out, pay the utmost attention when releasing, locking or moving the internal mechanical parts.
-
Page 9: Installing The Boom
12 INSTALLING THE BOOM IMPORTANT: The BIONIK8 barrier is supplied with two 4.1 m booms (D1 and D2). WARNING!: to avoid damaging the surface of the components, it is recommended to place them on a stable and soft surface. • Unlock the barrier (see chapter 23). •... -
Page 10: Installation Procedure
12.3 Installation procedure 1. Insert the connector M1 on the boom D1 by half of its length (375 mm), fig. 11. 2. Fasten the boom to the connector using the 10 self-drilling screws [L] included, 5 above and 5 under, along the boom axis, at a distance of 60 mm apart, fig. 11. 3. - Page 11 13 INSTALLING AND ADJUSTING THE SPRING For choosing the most suitable configuration, the booms are understood as complete with shock-resistant rubber and LED strips. BI/008 with boom up to 8 m The adjustable fixed end rest with integrated magnet BAFS/05 must be used.
- Page 12 13.1 Installation and adjustment of the balancing unit • The balancing unit is composed of a linkage lever, a slider [CU] and a spring unit. • The linkage lever has two 4 mm pitch toothed windows, on which the [CU] slide will be fit. •...
- Page 13 13.3 Spring unit installation 1. Unlock the barrier (see chapter 23) and move the boom into the completely open vertical position. 2. Fasten the spring unit SP/85/AS/02 to the linkage lever using the screws included (fig. 17), according to the opening direction and in the position that allows the correct movement of the barrier.
-
Page 14: Spring Adjustment
13.4 Spring adjustment 1. Adjust the spring tensioning by loosening the nuts [A] as indicated in fig. 19. 2. By moving upward the fastening cross bar [B], the spring tensioning increases; vice versa, by moving it downward, the tensioning decreases. 3. - Page 15 14 ADJUSTING MECHANICAL STOP Figure 21 shows the mechanical stop on a barrier installed on the RIGHT hand side. For barriers installed on the LEFT, perform the mirror images of the procedures illustrated. • Unlock the barrier (see chapter 23). •...
- Page 16 16 CONNECTING PHOTOCELLS G90/F4ES photocells may be installed on both sides of the barrier at two different heights: (50 cm or 100 cm). • Disconnect from mains electricity and from battery power (if applicable). • Open the inspection hatch, turning the key clockwise by 90°. •...
-
Page 17: Electrical Connections
17 ELECTRICAL CONNECTIONS All electrical connections must be made with the unit disconnected from mains power and, if applicable, battery power. See the CTRL controller manual for instructions on making connections and programming. Before connecting to electrical power, ensure that the mains power specifications on the identification plate match the mains power supply used. - Page 18 19 INSTALLING THE BI/BLED/8 LED FLASHING LIGHT (fig. 26-27) The BI/BLED/8 flashing lamp unit is factory supplied already pre-installed in the head [A], packaged separately inside the BIONIK package. 1. Insert the connector [B] in the LIGHT terminal of the control unit. 2.
-
Page 19: Maintenance
• Check the electrical connections. • Check that the manual lock release system works. ROGER TECHNOLOGY is the exclusive proprietor holder of all rights regarding this • Check that the boom is balanced correctly as indicated in chapter 13. publication.
