- Page 1 USB-3300 Series Multifunctional Data Acquisition Devices User Manual Rev. C Smacq Beijing Smacq Technology Co., Ltd. Smacq.com Smacq.cn...
- Page 2 StatementL Copyright ©2018 Beijing Smacq Technology Co., Ltd. All rights reserved No content of this manual may be reproduced, modified or abridged without prior consent and written permission. Trademark Information Smacq is a registered trademark of Beijing Smacq Technology Co., Ltd. The names of the other products and companies mentioned in this document are trademarks or trade names of their respective companies.
-
Page 3: Security Requirements
Security Requirements Warning Only the voltage within the specified range can be connected. Voltage exceeding the specified range may cause damage to the device, and even present a negative impact on personal safety. Check the product specification for detailed reference to the range of voltages that can be connected by each port. -
Page 4: Measurement Category
Measurement Category Warning For use in measurement category I (CAT I) only. Do not use in measurement category II/III/IV. Use this device to connect signals or make measurements. Measurement categories Note Measurement categories I (CAT I) means that measurements are made on a circuit that is not directly connected to the main power supply. - Page 5 Pollution level explanation Pollution degree 1: No pollution, or only dry non-conductive pollution. This pollution level has no effect. For example: a clean room or an air-conditioned office environment. Pollution degree 2: Generally, only dry non-conductive pollution occurs. Temporary conduction can sometimes occur due to condensation.
-
Page 6: Table Of Contents
CONTENT Security Requirements ......................3 Measurement Category ......................4 Environment ..........................4 1. Getting Started ........................9 1.1. Product Introduction ··········································································· 9 1.2. Function Diagram ·············································································· 9 1.3. Product Specifications ······································································· 10 1.4. Product unpacking ··········································································· 15 Precautions ......................15 Check the packing list ..................... - Page 7 4. Analog Output (AO) ......................30 4.1. Circuit diagram ··············································································· 30 4.2. Signal Output Mode ········································································· 30 DC immediate output ....................30 Hardware Timing ..................... 31 Finite number output mode ..................31 Infinite loop output mode ..................31 Infinite non-loop output mode ................. 31 Proportional and offset operation ................
- Page 8 6.4. Trigger ························································································· 41 Clear trigger ......................42 7. Counter (CT) ........................43 7.1. Counting edge and PWM output ··························································· 43 software controls single point reading..............44 Sampling Clock Timing Continuous acquisition ............. 44 Control counting enable ..................45 Control the counting direction .................
-
Page 9: Getting Started
1. Getting Started This chapter describes the basic functions of USB-3300 Series Data Acquisition Device, as well as product specifications and precautions in the process of product unpacking. 1.1. Product Introduction USB-3300 Series data acquisition device is the multifunctional data acquisition device based on high-speed USB2.0 interface. -
Page 10: Product Specifications
FIFO cache Digital I/O Figure 1.1 functional Block Diagram of USB-3300 series data acquisition device 1.3. Product Specifications The following product specification parameters, unless otherwise stated, are acquired at the temperature of 25°C and the humidity of 40%, while the device is turned on for 20 minutes. - Page 11 Input coupling mode Input impedance 500MΩ Small signal bandwidth 450kHz (-3dB) Input bias current 0.7nA Analog input max The voltage to ground of each input side does not exceed ±12 V voltage Software FIFO 2 MPts/Ch Pre-trigger FIFO 4096 Pts AI capture mode Continuous acquisition mode and limited number of acquisitions Analog input accuracy (...
- Page 12 Output drive current 10mA Power on state Within ±50mV Hardware FIFO 2048Pts/Ch DC direct output, Onboard FIFO waveform periodic output, onboard AO output mode FIFO waveform trigger N loop, non-repetitive loop signals to computer caches Output voltage establishment time Edge slope 9.2 V/ us Analog output accuracy Range (V)
- Page 13 Timing resolution 10ns Channel synchronization DIN software FIFO 2MPts/Ch DIN pre-trigger FIFO 2048Pts/Ch DOUT Hardware FIFO 2048Pts/Ch Continuous acquisition mode and OneShot mode When the sampling rate exceeds 4MS/s/Ch, only OneShot mode is DIN acquisition mode supported, and the number of collected points does not exceed 15,000 points.
- Page 14 Hardware FIFO 256 Pts / Ch Acquisition mode Single point measurement, sampling clock timing acquisition, implicit buffer acquisition External trigger Number of channels 1 input, 1 output High level: 1.95V~5V Input voltage Low level: 0V~1.2V High level: 3.3V Output voltage Low level: 0V~0.003V Output power-on state Low level...
-
Page 15: Product Unpacking
USB 2.0 high-speed interface Power supply requirements USB interface power 4.5V~5.5V supply Typical current without 400 mA load Maximum load 600 mA Physical properties Connectors not included:150*96*28 Size (mm) Connectors included:150*112*28 Connectors not included: about 185 grams Weight (g) Connectors included: about 230 grams I/O connector Bolt terminal Bolt terminal... -
Page 16: Installation
2. Installation This chapter describes signal connection and drive installation of USB-3300 series data acquisition device. 2.1. Connector signal pins distribution Figure 2.1 USB-3300 signal pin distribution diagram Table 2.1 Signal pin allocation Signal name Single-ended input Differential input AI 0... - Page 17 AI 4 Analog input 4 Analog input 4 Cathode AI 5 Analog input 5 Analog input 4 Negative AI 6 Analog input 6 Analog input 6 Cathode AI 7 Analog input 7 Analog input 6 Negative AI 8 Analog input 8 Analog input 8 Cathode AI 9 Analog input 9...
-
Page 18: Usb Cable Reinforcement Design
2.2. USB Cable Reinforcement Design USB cable connectors are prone to be pulled off during operation. USB-3300 series data acquisition devices provide a cable reinforcement design, with which a strap can be used to fix the USB cable to the device to prevent the accidents. Check Figure 2.2 for details. - Page 19 Click Browse in the pop-up dialog box, then enter the \USB-3000SeriesDAQ\driver folder in the CD-ROM, then enter the "win7" folder, then the 32-bit operating system enters the "x86" folder, the 64-bit operating system enters the "x64" folder, select the "susb.inf" file, and then click "Open". (The drivers of Windows8/8.1 and Windows10 are the same as those of Windows7, using the same file.
-
Page 20: Analog Input (Ai)
3.1. Circuit diagram Figure 3.1 analog input circuit 3.2. Signal Connection methods USB-3300 series data acquisition devices support analog input acquisition connection methods of non-grounding reference single-ended input (NRSE) and differential input (DIFF). Table 3.1 lists the recommended connection methods for floating-ground signal sources and... -
Page 21: Floating Grounded Signal Source
USB-3300 USB-3300 Signal source Signal source Differential input (DIFF) USB-3300 USB-3300 Non- Signal source Signal source grounded reference SENSE SENSE Single- ended input （NRSE） AGND AGND 3.3. Floating grounded signal source A floating grounded signal source is not connected in any way to the building ground system but, it has an isolated ground-reference point. - Page 22 Differential connection mode can reduce noise interference and improve the common-mode suppression ability of acquisition device. For a floating signal source with less than 100ΩF internal resistance, you can directly connect the negative end of the signal to AI- and AI-GND ports and connect the positive end of the signal to AI+ ports, as shown below in figure 3.2.
- Page 23 For a floating signal source with a large internal resistance, you can use the differential input mode with two bias resistors, as shown in Figure 3.4. The fully balanced bias resistor connection in this way can provide a slightly better noise suppression, but it can reduce the load on the signal source and result in gain errors.
-
Page 24: Non-Grounded Reference Single-Ended Mode (Nrse) Connection
Non-grounded reference single-ended mode (NRSE) connection When both the following conditions are true, you can connect the float signal using a non- grounded reference single-end mode: The input signal voltage is higher than 1V The length of the cable connecting signals to the acquisition device is lower ... -
Page 25: Use Ungrounded Reference Single-Ended Mode (Nrse) Connection
Analog input AI+ and AI- are all valid signals. Low input signal voltage while high accuracy demanded The cable connecting the signal to the acquisition device exceeds 3 meters The input signal requires a separate reference location or return signal ... -
Page 26: Signal Acquisition Mode
Figure 3.8 grounded signal source NRSE input 3.5. Signal Acquisition Mode When the USB-3300 series data acquisition device performs analog input measurement, it supports continuous acquisition mode or limited number acquisition mode. The sampling rates of both modes are hardware-timed. The limited number acquisition mode is called OneShot mode. -
Page 27: Limited Number Acquisition Mode
3.6. Comprehensive Sampling Rate and Single Channel Sampling Rate When the USB-3300 series data acquisition device is used for single channel acquisition, the channel can achieve the maximum sampling rate. If two channels are enabled for one acquisition, the sampling rate of each channel is half the set sample rate;... -
Page 28: Trigger
Conv_OUT pin via software for simultaneous synchronization of multiple devices. See the "Synchronization System" chapter for details on the external clock. 3.8. Trigger The USB-3300 series data acquisition device provides rich trigger options, and the Block Diagram of trigger options for AI acquisition is shown in Figure 3.10. DoSoftTrig software trigger... -
Page 29: Clear Trigger
Clear trigger The AI trigger status can be reset to an untriggered state by software settings. Pre-trigger The pre-trigger function is used to record the pre-trigger signal. The pre-trigger function relies on the hardware FIFO to store the data of the pre-trigger signal, so the number of pre- triggered points is limited and cannot exceed 4kPts. -
Page 30: Analog Output (Ao)
AO is the abbreviation of Analog Output here. 4.1. Circuit diagram Figure 4.1 shows the schematic diagram of the AO output circuit of the USB-3300 series data acquisition device, which supports the ground reference single-ended output. Figure 4.1 analog output circuit diagram 4.2. -
Page 31: Hardware Timing
Hardware Timing The three output modes mentioned below refer to the mode of outputting analog waveforms, so the sampling rate of the output waveform is an important parameter. When the acquisition device is in AO mode, the AO sampling clock is generated by hardware timing. The sampling clock signal can be generated internally or externally. -
Page 32: Proportional And Offset Operation
10, and the default is 1; The setting range of b is -10 to 10, and the default is 0. 4.3. Output Update Rate USB-3300 series data acquisition device can reach an AO output update rate up to 100 kSa/s/ Ch, which is also the DAC output sampling rate. This is the independent sampling rate for each channel. -
Page 33: Trigger
The external sampling clock source input from Conv_IN cannot be set to divide or multiply. It can only be used directly as the sampling clock. The AO_n timer output signal can be set to the Conv_OUT pin via software for simultaneous synchronization of multiple devices. See the "Synchronization System"... -
Page 34: Clear Trigger
Clear trigger The AO trigger status can be reset to an untriggered state via software settings. -
Page 35: Digital Input (Di)
5. Digital Input (DI) This chapter introduces the digital input signal acquisition on USB-3300 series data acquisition devices. DI is the abbreviation of Digital Input here. Figure 4.1 is a schematic diagram of the digital input circuit. Figure 5.1 Block Diagram of digital input circuit 5.1. -
Page 36: Limited Number Acquisition Mode
Attention The number of set collection points cannot exceed 2MPts. 5.2. Sampling Rate For USB-3300 series of data acquisition devices, the DI sampling rate is up to10 Msa/s/ch. This is parallel simultaneous sampling of all channels, with each channel able to achieve this highest sampling rate. -
Page 37: Trigger
See the "Synchronization System" chapter for details on the external clock. 5.4. Trigger The USB-3300 series data acquisition device provides rich trigger options. The DI acquisition trigger options are shown in Figure 5.3. DiSoftTrig software trigger... -
Page 38: Clear Trigger
Clear trigger The DI trigger status can be reset to an untriggered state via software settings. Pre-trigger The pre-trigger function is used to record the pre-trigger signal. The pre-trigger function relies on the hardware FIFO to store the data of the pre-trigger signal, so the number of pre- triggered points is limited and cannot exceed 4kPts. -
Page 39: Digital Output (Do)
Figure 5.1 is a schematic diagram of the digital output circuit. Figure 6.1 Digital output circuit 6.1. Signal Output Mode When the USB-3300 series data acquisition device is utilized for digital output, the following four output modes are supported: Immediate output ... -
Page 40: Infinite Loop Output Mode
6.2. Output Update Rate USB-3300 series data acquisition device DO output update rate can reach up to 10MSa/s/ Ch. This means parallel simultaneous sampling of all channels, while each channel can achieve this highest sampling rate. -
Page 41: Trigger
See the "Synchronization System" chapter for details on the external clock. 6.4. Trigger The USB-3300 series of data acquisition devices provide a rich set of trigger options, as shown in Figure 6.3, which describes trigger options for the DO output. -
Page 42: Clear Trigger
The DO output uses the channel exclusive software trigger signal DoSoftTrig as the trigger source by default. You can set DO output to use other trigger sources to achieve the synchronization of each function via software settings. The DoSoftTrig software trigger and the GlobalSoftTrig global software trigger are both software triggers, which means the computer sends a command to the data acquisition device to achieve device triggering. -
Page 43: Counter (Ct)
Figure 7.1 Block Diagram of counter circuit The counter of USB-3300 series is a 32-bit counter, in which the frequency of the internal Source signal can be set by software, and its period is set in steps of 10ns, with a minimum setting of 20ns. -
Page 44: Software Controls Single Point Reading
edges. You can also control the direction of counting, and the counting value increases or decreases. There are two ways to output the measured value of the counter: Software controlled single point reading Sampling clock timing continuous acquisition software controls single point reading. -
Page 45: Control Counting Enable
Tigger Source Counter value Sampling clock FIFO Figure 7.3 Sample of Sampling Clock Timing Continuous Acquisition Control counting enable The enable of the control counter can be realized by inputting the high and low levels of the Gate port. Gate port input high level, the counter counts normally. ... -
Page 46: Pulse Width Measurementment
the reset value is set to 0. When the count value reaches 5, the counter overflows and the count value is reset to 0. At this time, the positive pulse width duty ratio of the PWM waveform Output from the out port is 60%. Tigger Source Counter value... -
Page 47: Sampling Clock Timing Continuous Acquisition
first pulse after triggering is latched. Figure 7.5 is an example of software-controlled single point measurement. Trigger Transmit Gate Source Counter valur Latched value Figure 7.5 Examples of software controlling single-point measurement Sampling clock timing continuous acquisition Sampling clock timing continuous acquisition means that after the counter triggers to start counting edge of the Source signal, the counter value is stored in the FIFO according to the set sampling rate, and the data in the FIFO is continuously uploaded to the computer memory buffer, so that the user program can realize continuous and uninterrupted data acquisition only by... -
Page 48: Pulse Measurement
measurementment is completed, and the data in the FIFO will be continuously uploaded to the computer memory buffer. The sequence of all pulse width data read by the user program. Figure 7.7 shows the working mode of implicit buffer pulse width acquisition. Trigger Gate Source... -
Page 49: Software Controlled Single Point Measurement
Software controlled single point measurement Software-controlled single-point measurement means that after the counter triggers and starts counting edge of the Source signal, the counter value is not directly uploaded to the computer, but the latched counter value is sent back to the computer when the computer reads the request. In this process, no new pulse measurement is carried out, and only the first pulse after triggering is latched. -
Page 50: Implicit Buffered Pulse Acquisition
buffered Implicit pulse acquisition Implicit buffer pulse acquisition means that when counting values measurement pulses, the measured values are automatically stored in FIFO every time the pulse measurement is completed, and the data in FIFO are continuously uploaded to the computer memory buffer. The sequence of all pulse data read by the user program. -
Page 51: Software Controlled Single Point Measurement
Period of measurenent Gate …… Source The period of fx = N / fk The frequency of fx= fk / N Figure 7 11 Principle of frequency (period) measurement There are three ways to output the frequency measurement: Software controlled single point measurement ... -
Page 52: Implicit Buffer Frequency Measurement And Acquisition
If the data processing speed of user program is not fast enough, the data will gradually fill the memory space of 2M points in the computer memory buffer, and after filling, the new data cannot be written correctly, resulting in data discontinuity. Figure 7.13 shows the working mode of sampling clock timing continuous acquisition. -
Page 53: Use Quadrature Encoder For Measurement
There are two ways to output the position measurement: Software controlled single point measurement Sampling clock timing continuous acquisition Use quadrature encoder for measurement. When quadrature encoder is used, X1, X2 or X4 encoding modes can be supported by software settings. -
Page 54: Z Channel Characteristic
…… …… Counter value 7 8 9 10 10 9 8 7 4 3 2 Figure 7.17 Quadrature encoder X4 coding counting mode Z channel characteristic Some quadrature encoders have a third channel Z, which is usually used as an index channel. Setting channel Z to high level can reset the counter, and the value of the counter is reset to the specified value. -
Page 55: Software Controlled Single Point Measurement
Counter value 2 Figure 7.19 Measurement example of two pulse encoder Software controlled single point measurement Software-controlled single-point measurement means that after the counter is triggered, the encoder is measured, and the measured value is not directly uploaded to the computer, but the latched measured value is sent back to the computer after receiving the computer reading request. -
Page 56: Synchronization System
8. Synchronization System This chapter introduces the multi- card synchronization system of the USB-3300 series data acquisition device . The synchronization system has four ports, sampling clock input, sampling clock output, external trigger input and external trigger output. 8.1. Sampling Clock... -
Page 57: External Trigger
AI sampling clock DI sampling clock DO sampling clock AO_0 sampling clock Conv_Out AO_1 sampling clock AO_2 sampling clock AO_3 sampling clock CT_0 sampling clock CT_1 sampling clock CT_2 sampling clock Figure 8.2 Block Diagram of sampling clock output circuit 8.2. - Page 58 AO_2 output trigger AO_3 output trigger CT_0 trigger CT_1 trigger CT_2 trigger AI acquisition trigger DI acquisition trigger DO acquisition trigger AO_0 output trigger Ext_Trig_Out AO_1 output trigger AO_2 output trigger AO_3 output trigger CT_0 trigger CT_1 trigger CT_2 trigger Figure 8.4 External trigger output circuit...
-
Page 59: Service And Warranty
9. Service and Warranty Beijing Smacq Technology Co., Ltd. is committed to its products during the warranty period, if the product fails under normal use in warranty, we will repair or replace defected parts for free. Please refer to the warranty explanation in the box for detailed instructions. In addition to the warranties mentioned in this manual and the warranty note, we do not provide any other warranties, express or implied, including, but not limited to, any implied warranties as to the tradable nature of the product and the suitability of the special purpose. -
Page 60: Ordering Information
10. Ordering Information Host Model Notes 16-AI(1 MSa/s)、4-AO、4-DI、4-DO、3-CT USB-3323 16-AI(500 kSa/s)、4-AO、4-DI、4-DO、3-CT USB-3322 USB-3321 16-AI(250 kSa/s)、4-AO、4-DI、4-DO、3-CT USB-3320 16-AI(125 kSa/s)、4-AO、4-DI、4-DO、3-CT 8-AI(1 MSa/s)、4-AO、4-DI、4-DO、3-CT USB-3313 8-AI(500 kSa/s)、4-AO、4-DI、4-DO、3-CT USB-3312 8-AI(250 kSa/s)、4-AO、4-DI、4-DO、3-CT USB-3311 USB-3310 8-AI(125 kSa/s)、4-AO、4-DI、4-DO、3-CT Standard accessories Model Notes USB connection cable, 1.5 meters, USB-A type to USB-B type USB-A-B 10-bit, 3.81mm pitch terminal block TB10-3.81...
