- Page 1 PCI-1232 Digital Output Control Device User Manual Rev. C Beijing Smacq Technology Co., Ltd. Smacq.com Smacq.cn...
- Page 2 Statement Copyright ©2020 Beijing Smacq Technology Co., Ltd. All rights reserved No content of this manual may be reproduced, modified or abridged without prior consent and written permission. Trademark information is a registered trademark of Beijing Smacq Technology Co., Ltd. Smacq The names of the other products and companies mentioned in this document are trademarks or trade names of their respective companies.
-
Page 3: Safety Requirements
Safety Requirements Only the voltage within the specified range can be connected. Voltage Warning exceeding the specified range may cause damage to the device, and even present a negative impact on personal safety. Check the product specification for detailed reference to the range of voltages that can be connected by each port. -
Page 4: Measurement Categories
Measurement Categories For use in measurement category I (CAT I) only. Do not use in Warning measurement category II/III/IV. Use this device to connect signals or make measurements. Measurement categories Note Measurement categories I (CAT I) means that measurements are made on a circuit that is not directly connected to the main power supply. -
Page 5: Environment
Environment Temperature Operating 0℃ ~ 55℃ Storage -40℃ ~ 85℃ Humidity Operating 5%RH ~ 95%RH，no condensation Storage 5%RH ~ 95%RH，no condensation Pollution degree Highest elevation 2000 m Pollution degree description Pollution degree 1: No pollution, or only dry non-conductive pollution. This pollution degree has no effect. -
Page 6: Table Of Contents
CONTENT Safety Requirements ..................2 Measurement Categories ................3 Environment ....................4 1. Getting Started ................... 6 1.1. Product introduction ................6 1.2. Function Diagram ................7 1.3. Product specifications ................. 7 1.4. Product unpacking ................8 2. Installation ....................9 2.1. -
Page 7: Getting Started
1. Getting Started This chapter describes the basic functions of PCI-1232 Data Acquisition Decice, as well as product specifications and precautions in the process of product unpacking. 1.1. Product introduction PCI-1232 digital output control card is a digital I/O acquisition device based on PCI bus, which can be used to control the output of digital switch signals when it is loaded into a computer.All digital inputs of are isolated from the computer system by optocouplers. -
Page 8: Function Diagram
1.2. Function Diagram Figure 1.1 shows the schematic diagram of PCI-1232 data acquisition device. Digital system Trigger source: Software trigger PCI bus Sampling clock source: Internal module sampling clock source Digital Output FIFO cache Figure 1.1 PCI-1232 data acquisition device functions 1.3. -
Page 9: Product Unpacking
Highest sampling rate 50kS/s Timing resolution 20 ns Bus power requirements compatible with 5V and 3.3V PCI bus PCI bus power supply Power supply Typical current without 160mA@+5V, typical load Maximum Load 400mA@+5V 1.4. Product unpacking Precautions To prevent electrostatic discharge (ESD) from damaging the device, please note the following: Please wear a grounding wristband or touch a grounded object first to ensure being ... -
Page 10: Installation
2. Installation This chapter describes signal connection and drive installation of PCI-1232 data acquisition device. 2.1. Connector signal pins distribution Signal connector DB37 Figure 2.1 Schematic diagram of PCI-1232 digital output control card... -
Page 11: Drive Installation
COM 1 2.2. Drive installation PCI-1232 data acquisition device can be used in Windows 7 and Windows 10, including 32-bit and 64-bit. Here, taking the driver installation in Windows 10 environment as an example, we will introduce how to install the driver of PCI-1232 data acquisition device step by step. - Page 12 1) Open the device manager of Windows operating system, and when the driver is not installed, it is displayed as "PCI Data Capture and Signal Processing Controller", as shown in Figure 2.3 below. Figure 2.3 Before the driver is installed 11 |...
- Page 13 2) Select "PCI Data Capture and Signal Processing Controller", right-click and select "Update Driver". Select "Browse my computer to find driver software" in the pop- up dialog box, as shown in Figure 2.4 below. Figure 2.4 Browse my computer for driver software. 12 |...
- Page 14 3) Then in the pop-up dialog box, click "Browse" button, locate the operating system version folder corresponding to the driver, and then click "Next", as shown in Figure 2.5. Figure 2.5 Locate the folder where the driver is located. 13 |...
- Page 15 4) The computer starts to enter the driver installation process. After the installation is successful, the dialog box shown in Figure 2.6 below pops up, and the driver installation is completed. Figure 2.6 Driver installation is complete. 14 |...
- Page 16 Figure 2.7 Device Manager after successful driver installation 15 |...
-
Page 17: Digital Output（Do
3. Digital Output（DO） This chapter introduces the digital signal output for the PCI-1232 data acquisition device. The digital input is referred to as DO here, the abbreviation of Digital Output. 3.1 Schematic diagram of digital output circuit The circuit diagram of digital output is shown in Figure 3.1. -
Page 18: Trigger
Please refer to the response routine for details. 3.3. Trigger PCI-1232 data acquisition device provides two trigger options, and the schematic diagram of DO acquisition trigger options is shown in figure 4.2. DoSoftTrig software trigger... -
Page 19: Register Address Mapping
4. Register address mapping Address mapping should be applied to lower-level programming development. Before that, developers should be familiar with the principles of computer system and PCI interface. Therefore, in the Windows system environment, we recommend developers to use the drivers and dll provided by us to develop the devices. -
Page 20: Do Digital Output Register
4.2. DO digital output register Offset Name Explain Address D0 function configuration completion flag, 1 means 0x1300 to start waiting for triggering, and 0 means that the DoReady configuration has not been completed. 0: Direct output. Do output 0x1304 1: waveform output ncycle. mode 2: Infinite non-cyclic waveform output. -
Page 21: Service And Warranty
5. Service and Warranty Beijing Smacq Technology Co., Ltd. is committed to its products during the warranty period, if the product fails under normal use in warranty, we will repair or replace defected parts for free. Please refer to the warranty explanation in the box for detailed instructions. In addition to the warranties mentioned in this manual and the warranty note, we do not provide any other warranties, express or implied, including, but not limited to, any implied warranties as to the tradable nature of the product and the suitability of the special purpose. -
Page 22: Ordering Information
6. Ordering Information Host Model Notes PCI-1232 32-Do Optional accessories Model Notes DB37 connecting line, double male, 1.5m. DB37CB-1.5M End board, DiN guide rail installation DB37TB 21 |...
