PCI-3000 Series Multifunctional Data
Acquisition Devices
User Manual
Rev. A
Beijing Smacq Technology Co., Ltd.
Smacq.com
Smacq.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCI-3000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Smacq Technologies PCI-3000 Series

Summary of Contents for Smacq Technologies PCI-3000 Series

  • Page 1 PCI-3000 Series Multifunctional Data Acquisition Devices User Manual Rev. A Beijing Smacq Technology Co., Ltd. Smacq.com Smacq.cn...

  • Page 2: Statement

    Statement Copyright ©2021 Beijing Smacq Technology Co., Ltd. All rights reserved No content of this manual may be reproduced, modified or abridged without prior consent and written permission. Trademark information is a registered trademark of Beijing Smacq Technology Co., Ltd. Smacq The names of the other products and companies mentioned in this document are trademarks or trade names of their respective companies.

  • Page 3: Safety Requirements

    Safety Requirements Warning Only the voltage within the specified range can be connected. Voltage exceeding the specified range may cause damage to the device, and even present a negative impact on personal safety. Check the product specification for detailed reference to the range of voltages that can be connected by each port.

  • Page 4: Measurement Categories

    Measurement Categories For use in measurement category I (CAT I) only. Do not use in Warning measurement category II/III/IV. Use this device to connect signals or make measurements. Measurement categories Note Measurement categories I (CAT I) means that measurements are made on a circuit that is not directly connected to the main power supply.

  • Page 5: Environment

    Environment Temperature Operating 0℃ ~ 55℃ Storage -40℃ ~ 85℃ Humidity Operating 5%RH ~ 95%RH, no condensation Storage 5%RH ~ 95%RH, no condensation Pollution degree Highest elevation 2000 m Pollution degree description Pollution degree 1: No pollution, or only dry non-conductive pollution. This pollution degree has no effect.

  • Page 6: Table Of Contents

    CONTENT Statement ....................... 1 Safety Requirements ..................2 Measurement Categories ................3 Environment ....................4 1. Getting Started..................7 1.1. Product introduction ................7 1.2. Function Diagram ................10 1.3. Product specifications ...............10 1.4. Product unpacking ................15 Precautions .....................15 Check the packing list................15 2.
  • Page 7 Finite number output mode ..............33 Infinite loop output mode ...............34 Infinite non-loop output mode ...............34 4.2. Output update rate ................34 4.3. Trigger ....................34 Clear trigger ....................35 5. Digital Input（DI） .................36 5.1. Signal acquisition mode ..............36 Continuous acquisition mode ..............36 Limited number acquisition mode ............36 Single read ....................36 5.2.

  • Page 8: Getting Started

    1. Getting Started This chapter describes the basic functions of PCI-3000 Series Data Acquisition Device, as well as product specifications and precautions in the process of product unpacking. 1.1. Product introduction PCI-3000 series data acquisition device is a multi-functional data acquisition device based on PCI bus, which can be used for continuous high-speed signal acquisition and control signal output when installed in a computer.
  • Page 9 PCI-3000 series data acquisition device contains several models, and the main differences of each model are as follows: PCI-3210 PCI-3211 PCI-3212 PCI-3213 Analog input 8 Single-Ended 8 Single-Ended / 8 Single-Ended / 8 Single-Ended / 4 Difference 4 Difference 4 Difference...
  • Page 10 PCI-3120 PCI-3121 PCI-3122 PCI-3123 Analog input 16 Single-Ended 16 Single-Ended 16 Single-Ended 16 Single-Ended / 8 Difference / 8 Difference / 8 Difference / 8 Difference channel quantity Analog input 16-bit 16-bit 16-bit 16-bit resolution Analog input 125kS/s 250kS/s 500kS/s 1MS/s Sampling rate Analog output...

  • Page 11: Function Diagram

    1.2. Function Diagram Figure 1.1 shows the schematic diagram of PCI-3000 series data acquisition device. Digital system Trigger source: Software trigger External trigger Din trigger PCI bus Sampling clock source: Internal module sampling clock source External sampling clock source Digital I/O FIFO cache Figure 1.1 PCI-3000 series data acquisition device functions...
  • Page 12 (If multi-channel is used, the sampling rate refers to the sum of multi-channel sampling rates. ) PCI-3213/3223/3113/3123: 1MS/s max., continuous Highest sampling rate PCI-3212/3222/3112/3122: 500kS/s max, continuous PCI-3211/3221/3111/3121: 250kS/s max, continuous PCI-3210/3220/3110/3120: 125kS/s max, continuous Timing resolution 10ns Channel synchronization Range ±10.24V/±5.12V/±2.56V/±1.28V/±0.64V/ Input coupling mode...
  • Page 13 Analog input accuracy (with temperature coefficient of 5 ppm/℃) Full range absolute Gain error Offset error Random noise accuracy Range (ppm of reading) (ppm of range) (μVrms) (μV) ±10.24V ±5.12V ±2.56V ±1.28V ±0.64V Analog output Number of channels Resolution 16-bit ±1 LSB Output voltage establishment time...
  • Page 14 Digital I/O Number of channels Ground reference DGND Direction I/O can be set, and the power-on default value can be set. High level：1.95 V ~ 5 V Digital input voltage Low level:0 V ~ 1.2 V High level:3.3 V Digital output voltage Low level: 0 V ~ 0.003 V Highest sampling rate 10MS/s...
  • Page 15 Calibration Recommended warm- No less than 20Minutes up time Recommended 1 year calibration interval 14 |...

  • Page 16: Product Unpacking

    1.4. Product unpacking Precautions To prevent electrostatic discharge (ESD) from damaging the device, please note the following: Please wear a grounding wristband or touch a grounded object first to ensure being  grounded. Before removing the equipment from the packaging, please first connect the anti-static ...

  • Page 17: Installation

    2. Installation This chapter describes signal connection and drive installation of PCI-3000 series data acquisition device. 2.1. Connector signal pins distribution Signal connector DB37 Clock synchronization interface Figure 2.1 PCI-3000 signal pins distribution 16 |...
  • Page 18 19：AI 8 37：AI 7 18：AI 9 36：AI 6 17：AI 10 35：AI 5 16：AI 11 34：AI 4 15：AI 12 33：AI 3 14：AI 13 32：AI 2 13：AI 14 31：AI 1 12：AI 15 30：AI 0 11：AI SENSE 1 29：AI SENSE 0 10：GND 28：GND 9：AO 0 27：AO 1 8：GND...
  • Page 19 Signal name Single-ended input Differential input AI 5 Analog input 5 Analog input 4 Negative AI 6 Analog input 6 Analog input 6 Cathode AI 7 Analog input 7 Analog input 6 Negative Signal negative pole of AI 0~ 7 AI SENSE 0 single-ended input AI 8...

  • Page 20: Drive Installation

    TRIG IN External trigger signal input System synchronous clock SYNC_CLK input/output Not connected Not connected 2.2. Drive installation PCI-3xxx data acquisition device can be used in Windows 7 and Windows 10, including 32- bit and 64-bit. Here, taking the driver installation in Windows 10 environment as an example, we will introduce how to install the driver of PCI-3000 data acquisition device step by step.
  • Page 21 2) Select "PCI Data Capture and Signal Processing Controller", right-click and select "Update Driver". Select "Browse my computer to find driver software" in the pop- up dialog box, as shown in Figure 2.5 below. Figure 2.5 Browse my computer for driver software. 20 |...
  • Page 22 3) Then in the pop-up dialog box, click "Browse" button, locate the operating system version folder corresponding to the driver, and then click "Next", as shown in Figure 2.6. Figure 2.6 Locate the folder where the driver is located. 21 |...
  • Page 23 4) The computer starts to enter the driver installation process. After the installation is successful, the dialog box shown in Figure 2.7 below pops up, and the driver installation is completed. Figure 2.7 Driver installation is complete. 22 |...
  • Page 24 Figure 2.8 Device Manager after successful driver installation 23 |...

  • Page 25: Analog Input（Ai

    3. Analog Input（AI） This chapter describes measuring the relevant content of analog input signals on PCI-3000 series data acquisition devices. AI here is short for Analog Input. 3.1. Signal connection methods PCI-3000 series data acquisition devices support analog input acquisition connection methods of non-grounding reference single-ended input (NRSE) and differential input (DIFF).

  • Page 26: Floating Grounded Signal Source

    3.2. Floating grounded signal source A floating grounded signal source is not connected in any way to the building ground system but, it has an isolated ground-reference point. Common floating grounded signal sources are transformers, thermocouples, battery equipment, optical isolators, and isolation amplifier output. An instrument or device with isolated output is a floating-ground signal source.
  • Page 27 However, for a floating signal source with large internal resistance, the above connection will lead to the imbalance of differential signal, and the common-mode noise will be coupled to the signal of AI+ while not to AI-, so that the common-mode noise will appear in the measured results. Therefore, for such a signal source, you can use a bias resistor approximately 100 times the internal resistance of the signal source to connect to AI- and AI-GND ports, as shown in Figure 3.2.

  • Page 28: Non-Grounded Reference Single-Ended Mode (Nrse) Connection

    For AC-coupled floating signal sources, a resistor is required to provide DC loops for the positive input of instrument amplifier, AI+, as shown in Figure 3.4. If the AC coupled float signal source has a smaller internal resistance, the AI+ and AI-GND connection resistance values should be generally set as 100kΩ...

  • Page 29: Grounded Signal Source

    PCI-3000 AI-SENSE AI-GND Figure 3.5 floating-grounded signal source NRSE input 3.3. Grounded Signal Source The grounded signal source is a signal source connected to the building ground. If the computer is connected to the same power supply as the signal source, the source is already connected to a common ground point relative to the device.

  • Page 30: Use A Non-Grounded Reference Single-Ended Mode (Nrse) Connection

    Figure 3.6 shows how to use differential mode to connect the grounded signal source PCI-3000 Figure 3.6 grounded signal source DIFF input Use a non-grounded reference single-ended mode (NRSE) connection When all of the following conditions are true, you can connect the float signal using a non-grounded reference single-ended mode: The input signal voltage is higher than 1V ...

  • Page 31: Signal Acquisition Mode

    PCI-3000 AI-SENSE Figure 3.7 grounded signal source NRSE input 3.4. Signal acquisition mode When the PCI-3000 series data acquisition device performs analog input measurement ,it supports the following three acquisition modes: Continuous acquisition mode  Limited collection mode ...

  • Page 32: Limited Number Acquisition Mode

    3.5. Comprehensive sampling rate and single channel sampling rate When the PCI-3000 series data acquisition device is used for single channel acquisition, the channel can achieve the maximum sampling rate. If two channels are enabled for one acquisition, the sample rate for each channel is half the set sample rate;...

  • Page 33: Clear Trigger

    The AI acquisition uses the AiSoftTrig software trigger as the trigger source by default. The AI acquisition can use other trigger sources via software settings to achieve the synchronization of each function. Software triggering means that the computer sends a command to the acquisition device to achieve the effect of device triggering.

  • Page 34: Analog Output (Ao)

    4. Analog Output (AO) This chapter introduces the analog signal output on PCI-3000 series data acquisition devices. AO is the abbreviation of Analog Output here. Only the data acquisition device with PCI-31xx product model has the AO function. 4.1. Signal output mode...

  • Page 35: Infinite Loop Output Mode

    4.2. Output update rate PCI-3000 series data acquisition device can reach an AO output update rate up to 1MS/s/, which is also the DAC output sampling rate.

  • Page 36: Clear Trigger

    AiSoftTrig software trigger DiSoftTrig software trigger AoSoftTrig_0 software trigger AO trigger signal AoSoftTrig_1 software trigger DoSoftTrig software trigger Global sofrware trigger Trig_IN external trigger input Figure 4.1 AI trigger options The AO output uses the channel exclusive software trigger signal AoSoftTrig as the trigger source by default.

  • Page 37: Digital Input（Di

    5. Digital Input（DI） This chapter introduces the digital input signal acquisition on PCI-3000 series data acquisition devices. DI is the abbreviation of Digital Input here. 5.1. Signal acquisition mode When the PCI-3000 series data acquisition device performs DI acquisition, it supports the...

  • Page 38: Trigger

    5.2. Trigger The PCI-3000 series data acquisition device provides rich trigger options. The DI acquisition trigger options are shown in Figure 5.1. AiSoftTrig software trigger DiSoftTrig software trigger AoSoftTrig_0 software trigger DI trigger signal AoSoftTrig_1 software trigger DoSoftTrig software trigger...

  • Page 39: Digital Output（Do

    6. Digital Output（DO） This chapter introduces the digital signal output for the PCI-3000 series data acquisition device. The digital input is referred to as DO here, the abbreviation of Digital Output. 6.1. Signal output mode When the PCI-3000 series data acquisition device is utilized for digital output, the following four...

  • Page 40: Infinite Non-Loop Output Mode

    PCI-3000 series data acquisition device DO output update rate can reach up to 10MSa/s 6.3. Trigger The PCI-3000 series of data acquisition devices provide a rich set of trigger options, as shown in Figure 6.3, which describes trigger options for the DO output.

  • Page 41: Synchronization System

    7. Synchronization System This chapter introduces the multi-card synchronization system of PCI-3000 series data acquisition device. The synchronization system has three ports, synchronization clock, external trigger input and trigger output. 7.1. Synchronous clock Synchronization clock is the key signal to ensure the synchronization of multiple devices, which is used to eliminate clock errors among multiple devices.
  • Page 42 AiSoftTrig software trigger DiSoftTrig software trigger AoSoftTrig_0 software trigger DO trigger signal AoSoftTrig_1 software trigger DoSoftTrig software trigger Globa software trigger Trig_IN external trigger Figure 7.2 Schematic diagram of trigger output circuit 41 |...

  • Page 43: Service And Warranty

    8. Service and Warranty Beijing Smacq Technology Co., Ltd. is committed to its products during the warranty period, if the product fails under normal use in warranty, we will repair or replace defected parts for free. Please refer to the warranty explanation in the box for detailed instructions. In addition to the warranties mentioned in this manual and the warranty note, we do not provide any other warranties, express or implied, including, but not limited to, any implied warranties as to the tradable nature of the product and the suitability of the special purpose.

  • Page 44: Ordering Information

    9. Ordering Information Host Model Notes PCI-3210 8-AI(125kS/s), 8-DIO PCI-3211 8-AI(250kS/s), 8-DIO PCI-3212 8-AI(500kS/s), 8-DIO PCI-3213 8-AI(1MS/s), 8-DIO PCI-3220 16-AI(125kS/s), 8-DIO PCI-3221 16-AI(250kS/s), 8-DIO PCI-3222 16-AI(500kS/s), 8-DIO PCI-3223 16-AI(1MS/s), 8-DIO PCI-3110 8-AI(125kS/s), 2-AO, 8-DIO PCI-3111 8-AI(250kS/s), 2-AO, 8-DIO PCI-3112 8-AI(500kS/s), 2-AO, 8-DIO PCI-3113 8-AI(1MS/s), 2-AO, 8-DIO PCI-3120...
