English CONTENTS GENERAL POWER TOOL SAFETY WARNINGS ........35 CORDLESS IMPACT WRENCH SAFETY WARNINGS ....... 38 CAUTION ON LITHIUM-ION BATTERY ............41 REGARDING LITHIUM-ION BATTERY TRANSPORTATION ...... 43 USB DEVICE CONNECTION PRECAUTIONS (UC18YSL3) ....... 43 PRECAUTIONS REGARDING THE DUST-RESISTANCE AND WATER- PROOFING FUNCTIONS................
Page 36
English Electrical safety a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
Page 37
English h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second. Power tool use and care a) Do not force the power tool.
English d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. e) Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
Page 39
English Make sure to securely hold the tool during operation. Failure to do so can result in accidents or injuries. (Fig. 1) Fig. 1 Check that the socket is not cracked or broken. Broken or cracked sockets are dangerous. Check the socket before using it. Secure the socket with the socket pin and the ring.
Page 40
Request an inspection and repair from the dealer where you purchased the unit or a HiKOKI Authorized Service Center. Continuing to use while operating abnormally might cause injuries.
English 26. Always use the tool and battery at temperatures between -5°C and 40°C. CAUTION ON LITHIUM-ION BATTERY To extend the lifetime, the lithium-ion battery equips with the protection function to stop the output. In the cases of 1 to 3 described below, when using this product, even if you are pulling the switch, the motor may stop.
Page 42
English 10. Do not immerse the battery or allow any fluids to flow inside. Conductive liquid ingress, such as water, can cause damage resulting in fire or explosion. Store your battery in a cool, dry place, away from combustible and flammable items. Corrosive gas atmospheres must be avoided.
English REGARDING LITHIUM-ION BATTERY TRANSPORTATION When transporting a lithium-ion battery, please observe the following precautions. WARNING Notify the transporting company that a package contains a lithium-ion battery, inform the company of its power output and follow the instructions of the transportation company when arranging transport.
English [Descriptions of IP Codes] IP56 Protection rating for water penetration Must be no adverse effects on the equipment when sprayed with powerful jets of water from all directions (water-proofed). (100 L of water per minute sprayed for approximately three minutes from a distance of approximately three meters with the use of a spray nozzle with a diameter of 12.5 mm.) Protection rating for external assault by solid objects...
English NAME OF PARTS 1. POWER TOOL Protector Anvil Housing Friction ring LED-Light Trigger switch Pushing button Auto stop mode selector switch High / Low mode Handle Switch panel selector switch Hook Auto stop mode indicator lamp WR36DH High / Low mode Battery indicator lamp WR18DH...
English CHARGER Model UC18YSL3 Charging voltage 14.4–18 V Weight 0.6 kg Model UC18YFSL Charging voltage 14.4–18 V Weight 0.5 kg STANDARD ACCESSORIES In addition to the main unit (1 unit), the package contains the accessories listed in the below. Table 1 WR18DH WR36DH (2JAP)
English APPLICATIONS ○ Tightening and loosening of all types of bolts and nuts, used for securing structural items. BATTERY REMOVAL / INSTALLATION Battery removal Hold the handle tightly and push the battery latches to remove the battery (see Fig. 7). CAUTION Never short-circuit the battery.
Page 49
English Insert the battery into the charger. Firmly insert the battery into the charger as shown in Fig. 8. Battery Charge indicator lamp Guide rail Fig. 8 Charging When inserting a battery in the charger, charging will commence and the charge indicator lamp will blink in blue.
Page 50
English NOTE If the red lamp continues to blink even after the charger has been attached, check to confirm that the battery has been fully inserted. Battery overheated. Unable to charge. Although charging will start once the battery has cooled down even when left in situ, the best practice is to remove the battery and allow it to cool down in a shaded, well-ventilated location before charging.
Page 51
– Do not block the air vent. Otherwise the interior will overheat, reducing the charger’s performance. – If the cooling fan is not operating, contact a HiKOKI Authorized Service Center for repairs. Disconnect the charger’s power cord from the receptacle.
Page 52
Remove the cord or plug from the power and then connect it again after 5 minutes or so. If this does not cause the pilot lamp to blink in red, please take the charger to the HiKOKI Authorized Service Center.
Page 53
– Do not block the air vent. Otherwise the interior will overheat, reducing the charger’s performance. – If the cooling fan is not operating, contact a HiKOKI Authorized Service Center for repairs. Disconnect the charger’s power cord from the receptacle.
English Regarding electric discharge in case of new batteries, etc. As the internal chemical substance of new batteries and batteries that have not been used for an extended period is not activated, the electric discharge might be low when using them the first and second time.
Page 55
○ Please use the designated attachments which are listed in the operations manual and HiKOKI’s catalog. Accidents or injuries could result from not doing so. ○ Make sure to firmly install the socket in the anvil. If the socket is not firmly installed it might come out and cause injuries.
English HOW TO USE Check the rotational direction The bit rotates clockwise (viewed from the rear side) by pushing the R-side of the pushing button. The L-side of the pushing button is pushed to turn the bit counterclockwise (See Fig. 14) (The marks are provided on the body).
Page 57
English WARNING When using the hook, hang up the power tool firmly not to drop accidentally. If the power tool is dropped, it may lead to an accident. CAUTION ○ When carrying the power tool with hooked to your waist belt, do not fit any bit to the tip of power tool.
Page 58
English Remaining battery indicator You can check the battery’s remaining capacity by pressing the remaining battery indicator switch to light the indicator lamp. (Fig. 17, Table 6) Remaining battery Remaining battery indicator lamp indicator switch Display panel Fig. 17 It is best to use the remaining battery indicator as a guide since there are slight differences such as ambient temperature and the condition of the battery.
Page 59
English NOTE Do not give a strong shock to the switch panel or break it. It may lead to a trouble. How to use the LED light While the trigger switch is pulled, the LED light will automatically light up the tip portion of the tool.
Page 60
English Tightening torque can be adjusted according to the type of work by combined use of the High / Low mode selector switch and the Auto stop mode selector switch. (Fig. 19) High / Low Auto stop mode mode selector selector switch switch Fig.
Page 61
English Auto stop mode selector switch (Fig. 21) Pressing the Auto stop mode selector switch toggles the mode. Auto stop mode Forward: Auto stop mode selector switch Reverse: Auto slow mode Fig. 21 Auto stop mode (Fig. 22, Table 8) Stops automatically after a preset time has elapsed.
Page 62
English Auto slow mode (Fig. 23, Table 9) Stops for a preset time and/or changes the speed automatically to a preset speed. Push the pushing button to the reverse (“L”) position, then press the Auto stop mode selector switch to select the setting. Auto stop mode selector switch Pushing button...
English OPERATIONAL CAUTIONS Resting the unit after continuous work The power tool is equipped with a temperature protection circuit to protect the motor. Continuous work may cause the temperature of the unit to rise, activating the temperature protection circuit and automatically stopping operation. If this happens, allow the power tool to cool before resuming use.
English Tightening conditions The tightening torque differs according to the torque ratio; class, and length of bolts even when bolts with the same size threads are used. The tightening torque also differs according to the condition of the surface of workpiece through which the bolts are to be tightened.
Page 65
English ○ Charging a USB device from a electrical outlet. (Fig. 24-a) ○ Charging a USB device and battery from an electrical outlet. (Fig. 24-b) Fig. 24 Connect the USB cable. (Fig. 25) Pull back the rubber cover and firmly plug in a commercially available USB cable (appropriate to the device being charged) into the USB port.
English MAINTENANCE AND INSPECTION WARNING Be sure the switch is in the OFF position, and pull out the battery before doing any inspection or maintenance. Inspecting the socket A worn or deformed hex. or a square-holed socket will not give an adequate tightness to the fitting between the nut or anvil, consequently resulting in loss of tightening torque.
TROUBLESHOOTING Use the inspections in the table below if the tool does not operate normally. If this does not remedy the problem, consult your dealer or the HiKOKI Authorized Service Center. Symptom Possible cause Remedy Tool doesn’t run...
Please install a multi volt type (WR36DH) other than that specified for battery. the tool. SELECTING ACCESSORIES Select accessories that are suited to a specific task. For details contact HiKOKI Authorized Service Center. BSL36..18.. BSL18.. UC18YSL3 UC18YFSL (14.4 V–18 V) (14.4 V–18V)
